Roc Hobby MOTION RC Operating Manual

Multipurpose glider
Hide thumbs
Table of Contents

Advertisement

Quick Links

Email:info@motionrc.com
Http://www.motionrc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOTION RC and is the answer not in the manual?

Questions and answers

Related Manuals for Roc Hobby MOTION RC

Summary of Contents for Roc Hobby MOTION RC

  • Page 1 Email:info@motionrc.com Http://www.motionrc.com...
  • Page 2 Multipurpose Glider OPERATING MANUAL...
  • Page 3 WARNING WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and requires some basic mechanical ability.
  • Page 4 step1 Fix the main wing to the fuselage 1. Install the left main wing. 4. Slide in the left main wing util it is fully seated into the slot as shown in the First, guide the aileron servo cable through picture.
  • Page 5 step1 Fix the main wing to the fuselage 6. When sliding the wing spar into the wing, 9. Slide in the laminated board along the it should go in easily. DO NOT force two pre-notched slots inside the battery it or push it beyond the point when you feel hatch.
  • Page 6 step1 Fix the main wing to the fuselage 10. Secure the main wing using the 12. This board is installed incorrectly. pre-cut laminated board. 11. Insert the board into the leading slot on top of the fuselage. NOTE: the top side of the board is angled and will align with the slope of the fuselage.

  • Page 7: Installing The Elevator

    step2 Installing the elevator 1. Apply glue to the cutout area on the 4. Fit the horizontal stabilizer fully into on the bottom of the horizontal stabilizer. place, making sure there are no gaps. Use a brush or hobby stick to thoroughly cover the notch with a thin layer of glue.
  • Page 8 step3 Control surface Neutral Position setting 1. Connect the cables to the receiver. 2.2 Secure the linkage rod by tighten NEVER arm the ESC before you turn on the hex screw in the control connector. the transmitter to avoid any property or personal injury.
  • Page 9 step4 The back loading thrust alternative power setting 1. Install the propeller adaptor as the 4. Secure the propeller using the spinner. picture shows, making sure to install The spinner should be tight, but take care not the plastic collar on the adaptor shaft. to over tighten which will damage the prop.
  • Page 10 step4 The back loading thrust alternative power setting 7. Remove the propeller nut from the motor adaptor. 8. Remove the propeller from the motor adaptor. 9. remove the propeller backplate. page 8 For More Info Vist: www.motionrc.com...
  • Page 11 step4 The back loading thrust alternative power setting 10. Attach the foam nose to the front of the 11. Mount the back loading thrust assembly fuselage. to the fuselage with the propeller toward the front of the airplane. 10.1 12. Make sure the motor mount is completely inserted into the slot.
  • Page 12 step4 The back loading thrust alternative power setting 13. Remove the canopy hatch from the 16. Connect the ESC to the back motor, fuselage by lifting the hatch at the rear . and test the motor to make sure it is The canopy attaches with a magnet at rotating in the correct direction.
  • Page 13 Power configurations 1. Multiple purpose front motor & propeller 1 PC Head motor 1 PC ESC 1 PC Battery 4 PCS Servo Tx&Rx 2. Multiple purpose back loading thrust (top mount) 1 PC fuselage back motor 1 PC Head motor (the head / front motor stays in place at all times for proper CG) 1 PC ESC 1 PC Battery...

  • Page 14: Main Specification

    Main specification Specification Center Of Gravity(C.G.) Wingspan : 1600mm /63.0 in Length : 930mm /36.6 in Weight : 650g /22.9 oz CG Position : 42mm Battery : 11.1V 1100mAh Li-Po Battery : 20A Motor : A2208-KV1300 Wing Area : 24dm Wing Load : 36g/dm RC System...
  • Page 15 Main specification The suggested throws for the ROCHOBBY Multipurpose Glider are as follows: Low rate High rate Elevator - 10mm/0.4in up an down 15mm/0.6in up and down Rudder - 8mm/0.3in left and right 12mm/0.5in left and right Ailerons - 11mm/0.4in up and down 18mm/0.7in up and down Spare Parts List Item# Description...
  • Page 16 Spare Parts List MG-101 MG-102 MG-103 MG-104 MG-105 MG-106 MG-108 MG-107 MG-109 MG-110 MG-111 MG-112 MG-113 MG-114 MG-115 MG-116 page 14 For More Info Vist: www.motionrc.com...

  • Page 17: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Aircraft will not Lower throttle stick and throttle ESC is not armed. respond to the trim to lowest settings. Throttle channel is reversed. throttle but responds Reverse throttle channel on to other controls. transmitter. Extra propeller noise Damaged spinner, propeller.

  • Page 18: Flying Tips

    Flying Tips Range Check Your Radio System After final assembly, range check the radio system with the ROCHOBBY Multipurpose Glider. Refer to your specific transmitter instruction manual for range test information. Take off and landing tips 1. Take off using full power. 2.
