  • Page 2 • Hobby Knife • Needle Nose Pliers • Wire Cutters • Multi Tool (AE Part #7494) • Soldering Iron • Calipers or a Precision Ruler Associated Electrics, Inc. Customer Service 26021 Commercentre Dr. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
  • Page 3 Each part in the foldout This symbols indicates a has a number assigned to it for ordering special note or instruction replacement parts. in the manual. Associated Electrics, Inc. Customer Service 26021 Commercentre Dr. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
  • Page 4 :: Shock Build - Bag A-AA - Step 1 31510 M2x4mm bhcs 6465 31325 Shock VCS3 shock VCS3 shock 31324 piston body VCS3 (#3) piston bushing 31330 31327 VCS3 shock VCS3 shock VCS3 shock shaft bottom cap o-ring :: Shock Build - Bag A-AA - Step 2 Shock oil 31324 (40wt)
  • Page 5 :: Shock Build - Bag A-AA - Step 4 3942 Silver spring 6475 (front) Shock spring cup spring cup 3941 Green Build four spring shocks (rear) :: Front Slipper Spool Build - Bag B-BB - Step 1 31173 31173 Slipper Slipper spool spool...
  • Page 6 :: Front Slipper Spool Build - Bag B-BB - Step 3 Press nut all Pre-compress spring Recheck screw the way in! periodically! 31166 Washer 3904 31166 2-56 mini Diff T-nut 6582 locknut Fully tighten thrust screw Diff thrust for slipper spool! Recheck screw tightness spring after initial run!!!
  • Page 7 :: Rear Differential Build - Bag B-BB - Step 2 6573 3906 Diff thrust 3906 D-drive washer D-drive ring ring 6574 5/64” diff thrust balls 31338 31338 TC6 diff 6573 TC6 diff outdrives Diff thrust Diff thrust outdrives (long) bolt (short) :: Rear Differential Build - Bag B-BB - Step 3 31400...
  • Page 8 :: Rear Differential Build - Bag B-BB - Step 5 Setting 31162 -1/8 Shim 5/64” hex wrench 31401 installed in diff bolt 10x15mm bearing -1/4 -3/4 Diff Setting: Diff Setting: Tighten thrust screw until Tighten thrust screw until -5/8 -3/8 spring is fully compressed.
  • Page 9 :: Turnbuckle Build - Bag D - Step 1 Servo Turnbuckle 1418 31305 0.825” Turnbuckle turnbuckle 29.55mm eyelet Camber Turnbuckle Front Rear 1403 1.65” turnbuckle 51.10m 51.50m Steering Turnbuckle 1405 1.875” turnbuckle 56.50mm :: Front Bulkhead Build - Bag E-EE - Step 1 31200 31280 25227...
  • Page 10 :: Rear Bulkhead Build - Bag E-EE - Step 1 31280 31221 Inner 31321 31200 hinge pin ballstud TC6 arm Wheelbase mount shim (1mm) (2 dot) 31322 25227 TC6 arm M4x8mm mount setscrew bushing Arm Mounts 31204 Rear 31200 Wheel Base Shims suspension Wheelbase Roll Center...
  • Page 11 :: Shock Tower Build - Bag E-EE - Step 1 2230 31541 31302 31250 31250 Body M3x6mm TC6 shock Shock Shock mounts fhcs 31310 tower (front) bushing bushing Do not tighten #31541 screws bearing all the way! Leave screws loose until bearing caps are attached to bulkheads! 31531 M3x6mm...
  • Page 12 :: Steering Bellcrank Build / Install - Bag F - Step 3 Use rear hole for standard position! Refer to page 23 for Ackermann chart Servo Saver Adjustment 31308 31308 TC6 steering TC6 steering bellcrank bellcrank 0.5mm post insert post insert :: Spur Gear Shaft Build - Bag G-GG - Step 1 31314 31331...

  • Page 13: Right Side

    :: Spur Gear Hub / Belts Install - Bag G-GG - Step 1 31187 Front belt Front Belt 31188 Rear belt Rear Belt :: Spur Gear Hub / Belts Install - Bag G-GG - Step 2 31521 M2.5x8mm bhcs :: Front Slipper Spool Install - Bag G-GG - Step 1 Right Side Belt Tension Cam Position...
  • Page 14 :: Front Slipper Spool Install - Step 2 / Rear Differential Install - Bag G-GG - Step 1 Right Side Belt Tension Slide belt over Number diff pulley! 31185 31184 Diff bearing cam holder (mid-low) Use belt tension position 6 for Left Side standard setup.
  • Page 15 :: Steering Block Build / Install - Bag H - Step 1 31561 31233 Steering Axle crush blocks tube (HARD) 31404 31280 6x10mm Note side view bearing ballstud 31286 Aluminum ballstud washer (1mm) :: Steering Block Build / Install - Bag H - Step 2 31214 Caster block...
  • Page 16 :: Steering Block Build / Install - Bag H - Step 4 31112 31162 1/16” x 5/16” Axle shim dowel pins :: Steering Block Build / Install - Bag H - Step 5 31234 Clamping wheel hex 31222 Outer hinge pin 31511 M2x5mm 31510...
  • Page 17 :: Rear Hubs Build / Install - Bag H - Step 1 31281 ballstud 31286 Aluminum ballstud washer 31162 (2mm) Axle shim 31233 Axle crush 31562 tube Rear hub 31404 (0 deg) (HARD) 6x10mm bearing :: Rear Hubs Build / Install - Bag H - Step 2 31511 M2x5mm shcs...
  • Page 18 :: Shocks Install - Bag H - Step 1 31530 M3x5mm 31530 bhcs M3x5mm bhcs :: Bumper Build / Install - Bag I - Step 1 2230 4673 Body M2.5x4mm mounts 31316 bhcs TC6 bumper brace Transponder 31317 and screws TC6 foam not included! bumper...
  • Page 19 :: Pivoting Body Mounts Install - Bag I - Step 1 3897 3897 Pivoting body mounts Pivoting 1736 body mounts FT body clips (blue) 1736 FT body clips (blue) :: Battery Braces / Antenna Mount Install - Bag I - Step 1 31530 M3x5mm 31304...
  • Page 20 :: Anti-Roll Bars Build / Install - Bag J - Step 1 31500 8828 M3x2.5mm Anti roll 31269 set screw bar cups Anti roll bar pivot 31261 Build four 1.25mm 31269 anti-roll roll bar Anti roll bar mounts (black) bar pivot mount Front Anti Roll Bar...
  • Page 21 :: Servo Build / Install - Bag K - Step 1 31286 7336 7337 Aluminum Servo .250x.125x.015 ballstud washer spacer washer (1mm) (1mm) 31280 31280 ballstud ballstud 89007 89007 Servo Servo 31532 31532 horn ring horn ring M3x8mm M3x8mm 31246 9180 Use screw that was included bhcs...
  • Page 22 :: Electronics Install - Bag L - Step 2 31286 Aluminum ballstud washer (1mm) 31531 M3x6mm Gearing will depend on the bhcs motor and track size. Motor, pinion gear, and set screw are not included! :: Electronics Install - Bag L - Step 3 Use battery tape to secure battery into chassis.

  • Page 23: Tips For Beginners

    :: Tuning Tips Tips for Beginners: Before making any changes to the standard setup, make sure you can get around the track without crashing. Changes to your car will not be beneficial if you can’t stay on the track. Your goal is consistent laps. Once you can get around the track consistently, start tuning your car.

  • Page 24: Camber Link Position

    :: Tuning Tips Caster: Caster describes the angle of the kingpin from vertical while looking from the side of the car. Positive caster means the top of the kingpin leans rearward. Negative caster means the kingpin is leaning towards the front of the car. Since caster is measured at the wheel, it is affected by running any inclination in your inboard arm mount.
  • Page 25 :: Tuning Tips Kick-Up (front): Kick-up describes the angle of the front suspension arm, where the front mount is higher than the rear mount. Increasing kick-up will give more entry steering, as well as increasing caster at the wheel. Anti-Dive (front): Anti-dive is a front arm angle where the rear mount is higher than the front mount.
