- Page 1 InnoMedia MTA 3368 IP VideoPhone Version 1.05 QuickStart Guide H.323, SIP and MGCP...
-
Page 2: Usage Environment
IP network. II. Usage Environment Design to suit both residential and enterprise environment, the InnoMedia MTA 3368 IP VideoPhone achieves best performance when it is being deployed in a broadband network with the following conditions: QoS LAN or cable modem connections... - Page 3 IV. Setting up MTA 3368 IP VideoPhone Below is an illustration of the overall setup of the MTA 3368 IP VideoPhone. Ethernet Power Supply Switch/ Hub Figure 1.1 Overall connection A. Connecting IP VideoPhone 1. Connect up the accessories, which include the CCD camera, telephone handset and cord to the videophone main body.
- Page 4 5. Switch on the videophone. During boot up, the ring indicator will be lighted up in green and a series of diagnostics will be conducted by the videophone 6. Once the boot-up process is successfully completed and the videophone is ready, the ring indicator light goes off and the orange power light changes to green.
- Page 5 FQDN Manually enter the Domain Name or IP address assigned e.g. Videophone@innomedia.com EndPoint ID Manually enter the assigned setting, whose formats include phone number or username or customized ID e.g. aaln/1 MGCP variant Depending on the MGCP Call Agent type, select between Telcordia and MGCP 1.0/NCS variant...
- Page 6 H.323 , SIP and MGCP optional Settings Fields Remarks Menu Password Default Password is 8888, for subsequent PW changes Go to Settings -> System page Enter new password in Menu Password settings or Leave the settings blank to disable the feature GK Password The feature supports MD5, RAS authentication.
- Page 7 Example: To configure the system settings: Press <SETUP> button or for Settings, then press to enter the System menu Case 1 - DHCP mode or PPPoE mode 0.0.0.0 Netmask 0.0.0.0 Default GW 0.0.0.0 Network BW 128 kbps Case 2 – Static IP mode 192.168.0.1 (virtual) or 202.79.82.122 (real) Netmask 255.255.255.0...
- Page 8 V. Quick Feature References Figure 1.3 InnoMedia MTA 3368 IP VideoPhone main body A. Key Panel User Interface Hard Keys Functions 1. Direct Dialing • Enter either the IP address or the phone number to call, then <CALL> press <CALL>...
-
Page 9: Call History
Navigation Menu [H.323] The following chart is an overview of the Navigation Menu of the MTA 3368 IP VideoPhone [H.323] Call History Phonebook Incoming ➥ ➥ Scroll on existing list Scroll on existing list Down ➥ Down ➥ Scroll on existing list ➥... - Page 10 B. Navigation Menu [SIP] The following chart is an overview of the Navigation Menu of the MTA 3368 IP VideoPhone [SIP] Call History Phonebook Incoming ➥ Scroll on existing list ➥ Scroll on existing list Down ➥ Down ➥ Scroll on existing list ➥...
- Page 11 C. Navigation Menu [MGCP] The following chart is an overview of the Navigation Menu of the MTA 3368 IP VideoPhone [MGCP] Call History Phonebook Incoming ➥ ➥ Scroll on existing list Scroll on existing list Down ➥ Down ➥ Scroll on existing list ➥...
-
Page 12: Making Calls
H,S,M Method 1b - Direct Dial (via phone number or ext. to a Gatekeeper) MTA 3368 IP VideoPhone is require to register to a H.323 gatekeeper/ SIP Call Agent for direct dialling of phone number or extension number 1. Enter the phone number/ extension number of the remote videophone, then press <CALL>. - Page 13 H,S, M Method 2 – Phonebook 1. Press <CALL> or press to access the PhoneBook. Scroll to the name of the person you wish to call using the Up and Down function keys (F1 and F2). Once the name of the person whom you wish to call is selected, press <CALL>...
- Page 14 Audio mute Press <MUTE> to block your voice from being transmitted if you do not wish to be heard by the remote user. iii) Privacy mode Pressing <PRIVACY> blocks your image from being transmitted so that the remote user sees only a blue screen. Brightness &...
- Page 15 D. Summary of Features / Functions Videoconferencing 4” TFT Colour LCD High frame rate - max at 30 fps CIF resolution (352 x 288 pixels) QCIF resolution (176 x 144 pixels) Privacy mode to block local image, i.e. no local view for remote party •...
