InnoMedia IP Phone P700 Series
User Guide
V1.0 June 2024
INNOMEDIA CONFIDENTIAL
This document contains proprietary information of InnoMedia Inc., and its receipt or possession
does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell
anything it may describe. It may not be reproduced, disclosed or used without specific written
authorization of InnoMedia Inc.
Advertisement
Table of Contents
Related Manuals for InnoMedia P700 Series
Summary of Contents for InnoMedia P700 Series
- Page 1 V1.0 June 2024 INNOMEDIA CONFIDENTIAL This document contains proprietary information of InnoMedia Inc., and its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. It may not be reproduced, disclosed or used without specific written...
-
Page 2: Table Of Contents
InnoMedia IP Phone P700 Series User Guide Table of Contents About this Phone........................... 9 1.1 Feature Highlights ........................9 1.1.1 P710 Features ........................9 1.1.2 P720 Features ......................10 1.1.3 P730 Features ........................ 10 Getting Started ..........................11 2.1 Package Contents ........................11 2.2 Phone Installation ........................ - Page 3 InnoMedia IP Phone P700 Series User Guide 3.7.3 Keep Call Logs on the Phone ..................28 3.7.4 Managing Call Logs ......................28 3.7.5 Peer-to-Peer Calls ......................29 3.7.6 Date & Time Settings ..................... 29 3.7.7 Time & Day Display Format ................... 30 3.8 Phonebook ..........................
- Page 4 InnoMedia IP Phone P700 Series User Guide 4.5.4 Dial Plan ......................... 50 4.5.5 Keypad Lock ........................56 4.5.6 VoIP Call Forwarding ..................... 57 4.5.7 Remote Control ......................57 4.5.8 Action URLs ........................59 4.5.9 Reboot Timing ....................... 60 4.5.10 Audio ..........................62 4.5.11 Ringtone ........................
- Page 5 InnoMedia IP Phone P700 Series User Guide Table of Figures Figure 1. Attaching the stand in two possible positions ..............11 Figure 2. Connect IP Phone to a DC12V Power Adapter ..............12 Figure 3. Connect IP Phone to a PoE switch port ................12 Figure 4.
- Page 6 InnoMedia IP Phone P700 Series User Guide Figure 34. Dial Plan 3 – Digit insertion ....................54 Figure 35. Dial Plan 4 – Digit replacement ..................55 Figure 36. Mixture of dial plan rules ....................55 Figure 37. Peer-to-peer calls ....................... 56 Figure 38.
- Page 7 InnoMedia IP Phone P700 Series User Guide Figure 70. Add a new trusted IP ......................83 Figure 71. Import Server X.509 Certificate ..................84 Figure 72. Import Device X.509 Certificate ..................84 Page 7 Copyright © 2024 InnoMedia All rights reserved.
- Page 8 InnoMedia IP Phone P700 Series User Guide About This Document This document provides details of the features available on the InnoMedia IP Phone P700 Series as well as feature descriptions and the configurations required. Revision History Date Version Notes June 2024...
-
Page 9: About This Phone
Integrated stand with 2 adjustable angles Secured remote diagnostics For the best HD voice quality, the entire network path from the InnoMedia IP Phone to the remote party must support wideband voice. Page 9 Copyright © 2024 InnoMedia All rights reserved. -
Page 10: P720 Features
InnoMedia IP Phone P700 Series User Guide 1.1.2 P720 Features 2.8” 240x320 color HD display with backlight 6 multi-functional line keys with up to 30 Paperless DSS keys Distraction-free Wideband HD voice quality with full-duplex speakerphone ... -
Page 11: Getting Started
InnoMedia IP Phone P700 Series User Guide ETTING TARTED 2.1 Package Contents The following components are included in the P700 IP Phone package. Item IP Phone Handset Network Cable Handset Cable Desk Stand DC12V Power Adapter Can be purchased separately... -
Page 12: Figure 2. Connect Ip Phone To A Dc12V Power Adapter
InnoMedia IP Phone P700 Series User Guide Connect the supplied Ethernet cable into the LAN port on the phone and connect the other end into your network router/switch. Figure 2. Connect IP Phone to a DC12V Power Adapter Connect to Power over Ethernet Switch Connect the supplied Ethernet cable into the LAN port on the phone and connect the other end into an IEEE 802.3af compliant PoE network Router/Switch. - Page 13 InnoMedia IP Phone P700 Series User Guide Connect to Wi-Fi Alternatively, the phone can use a Wi-Fi dongle connected to the USB port to access the network. The Wi-Fi dongle is an optional component. Contact your supplier if you wish to purchase a Wi-Fi dongle for your IP Phone device.
-
Page 14: Phone User Interfaces - Keypad And Lcd
InnoMedia IP Phone P700 Series User Guide HONE NTERFACES EYPAD AND 3.1 Phone set - Keypad and LCD Figure 4. P710 Phone keypad overview Figure 5. P720 Phone keypad overview Page 14 Copyright © 2024 InnoMedia All rights reserved. -
Page 15: Figure 6. P730 Phone Keypad Overview
InnoMedia IP Phone P700 Series User Guide Figure 6. P730 Phone keypad overview ITEM DESCRIPTION LCD Screen Displays information about calls, messages, softkeys, time, date and other relevant data: Call information — caller ID, call duration Phone state icons such as DND, MIC mute etc. -
Page 16: Understanding Phone Icons And Status Indicators
InnoMedia IP Phone P700 Series User Guide Microphone Audio input. Volume Key Adjust audio output volume for handset, headset, speaker or ringer Keypad Input digits or alphabetical characters. Handset Audio input and output while in handset mode. Speaker Audio output while in Speakerphone mode Mute Key Mute the phone MIC (lights when active). - Page 17 InnoMedia IP Phone P700 Series User Guide Microphone is muted Network connect. (Only on P720 and P730) Voice encryption enabled Auto Answer enabled Handset mode during a call Speaker phone mode during a call Wi-Fi connected Phonebook contact Table 1. IP Phone LCD Display Page 17 Copyright ©...
-
Page 18: Configuring The Phone Through The Keypad And Lcd
Software Settings 3.3.2 Basic Network Settings As the phone powers up, the LCD shows InnoMedia Logo which means the IP Phone is in its “Initialization state.” During this period, if DHCP is enabled, the phone attempts to contact the network DHCP server to obtain the necessary network parameters (e.g., IP address, subnet mask,... -
Page 19: Configure The Wifi Settings
InnoMedia IP Phone P700 Series User Guide 3.3.4 Configure the WiFi Settings Alternatively, the phone can use a Wi-Fi dongle connected to the USB port to access the network. Figure 8. IP Phone USB port for Wi-Fi dongle Disconnect 13:10... -
Page 20: Figure 10. Ip Phone Connected To The Network Via The Wi-Fi Interface
InnoMedia IP Phone P700 Series User Guide 13:10 30-04 SUN Menu Figure 10. IP Phone connected to the network via the Wi-Fi interface Page 20 Copyright © 2024 InnoMedia All rights reserved. -
Page 21: Voip Account Registration
InnoMedia IP Phone P700 Series User Guide 3.4 VoIP Account Registration Your VoIP service provider should have provided you with phone account information. Press the Menu softkey and follow the sequence: System Settings > Advanced Settings > enter password (Default: blank) > SIP Accounts. -
Page 22: Using The Phone
InnoMedia IP Phone P700 Series User Guide 3.5 Using the Phone 3.5.1 Answering Calls 3.5.1.1 Basic answering calls All incoming calls will display in the Incoming Call window. To answer a call, do one of the following: To use the handset, pick up the handset. -
Page 23: Placing Calls
InnoMedia IP Phone P700 Series User Guide 3.5.3 Placing Calls 3.5.3.1 Basic Calling - dial a number You may place a call using the handset, speakerphone, or headset. Dial the number using the keypad, then choose one of the following methods to place a call: either pick up the handset or press the key. -
Page 24: Call Features
3.6.3 Setting up and handling three-way calls The P700 Series IP Phone allows a three-way call with two other parties with the IP Phone acting as the mixing entity. Typically, you will be on a call, hold the call, dial out to another party and then connect both remote parties with a three-way call session. -
Page 25: Transfer The Ongoing Call To Another Recipient
InnoMedia IP Phone P700 Series User Guide 4. If the three-way call is ongoing, press the End softkey to terminate the three-way call (i.e., disconnect both remote parties). 5. If one of the two remote parties is on hold, press the End softkey to terminate the active call shown on the LCD. -
Page 26: Retrieving Voice Mail
InnoMedia IP Phone P700 Series User Guide To activate DND, press the DND softkey to lock all lines. To de-activate DND, press the DND softkey again (while the phone is in DND mode) to unlock all lines. PBX-5461... -
Page 27: Changing The Audio Output Volume
InnoMedia IP Phone P700 Series User Guide 3.6.8 Changing the audio output volume You may adjust the audio output volume while the phone is idle, ringing or during an ongoing call by pressing the left (-) or right (+) of the volume key . -
Page 28: Advanced Settings
InnoMedia IP Phone P700 Series User Guide 3.7 Advanced Settings 3.7.1 Call Forwarding to another person 1. Press the Menu softkey and follow the sequence: Function Settings > Call Forwarding. Choose among [Forward All Calls | Forward When Busy | Forward When No Answer] 2. -
Page 29: Peer-To-Peer Calls
InnoMedia IP Phone P700 Series User Guide o Save this call log to the Phonebook. Press to navigate and provide all the required settings. 3. Press the Save softkey when you are done. 3.7.5 Peer-to-Peer Calls The IP Phone supports ‘Peer-to-Peer’ calls. This feature is enabled by default. When the phone fails to register to the SIP server, it allows calls to be placed with another phone by dialing the IP address of the other phone provided they are both on the same network. -
Page 30: Time & Day Display Format
InnoMedia IP Phone P700 Series User Guide 3. Configure Daylight Savings. Press to enter daylight saving settings, choose among the [Auto | Enable | Disable] options. o Auto: depending on the time zone selected, the phone will automatically turn on/off the daylight savings settings. -
Page 31: Phonebook
InnoMedia IP Phone P700 Series User Guide 3.8 Phonebook The IP phone allows system administrators to provision (or configure via the web console) an enterprise phonebook to the phone. Additionally, end users are also able to manage personal phonebooks via the web console as well as on the phone set. -
Page 32: Web Management Console
InnoMedia IP Phone P700 Series User Guide ANAGEMENT ONSOLE In addition to the management of the IP Phone’s features through the keypad and LCD as described in the previous section, the IP Phone can also be managed via a Web browser. Once the IP Phone LAN Ethernet port (or Wi-Fi connection) is connected to the network, use a Web browser on the same network as that of IP Phone LAN interface to connect to the device as described below. -
Page 33: Network
InnoMedia IP Phone P700 Series User Guide 4.2 Network The Network section allows the configuration of the IP Phone’s network parameters. 4.2.1 LAN Port Connect LAN port of the IP Phone to the network. Figure 16. LAN Port IP Settings... -
Page 34: Pc Port
InnoMedia IP Phone P700 Series User Guide 4.2.2 PC Port Connect IP Phone PC port to a computer. Figure 17. PC Port Settings Field Name Description Switch Mode LAN: The computer obtains its IP address from the network to which IP Phone LAN port is connected. -
Page 35: Vlan Settings
InnoMedia IP Phone P700 Series User Guide Figure 19. OpenVPN VPN Settings Field Name Description VPN Type OpenVPN Upload VPN Upload the VPN configuration file which Configuration includes (1) the VPN config and, optionally, (2) the VPN client certificate and private key. -
Page 36: Qos Settings
InnoMedia IP Phone P700 Series User Guide Figure 21. Port Management Settings 4.2.6 QoS Settings Figure 22. QoS Settings QoS Settings Description SIP QoS Configure ToS (DSCP) values (in decimal) for SIP signaling and Voice media for Voice QoS prioritization of traffic in the network. -
Page 37: Lldp
InnoMedia IP Phone P700 Series User Guide 4.2.8 LLDP Enable/Disable the use of LLDP (Link Layer Discovery Protocol) and configure the interval (in seconds) at which the phone sends LLDP requests. Figure 24. LLDP Settings 4.2.9 CDP Enable/Disable the use of CDP (Cisco Discovery Protocol) and configure the interval (in secs) at which the phone sends CDP packets. -
Page 38: Wi-Fi Settings
InnoMedia IP Phone P700 Series User Guide 4.2.12 Wi-Fi Settings Prior to using a Wi-Fi dongle with the IP Phone, the Wi-Fi settings must be configured. This can be done through the WEB GUI when the LAN port is connected to the network and the phone's IP address is obtained from the Ethernet (LAN port). -
Page 39: Sip Account
InnoMedia IP Phone P700 Series User Guide 4.3 SIP Account For all SIP Account Settings, descriptions of both the Basic and Advanced settings are described in the Note sidebar on the right of the page. 4.3.1 Basic Figure 29. SIP Account-Basic Settings... - Page 40 InnoMedia IP Phone P700 Series User Guide Authentication SIP user account name used for SIP Name authentication (if blank, 'Username' is used instead for authentication). Password SIP Account password, provided by the VoIP service provider. Label Account Label to show on the IP Phone's display.
-
Page 41: Advanced
InnoMedia IP Phone P700 Series User Guide 4.3.2 Advanced Figure 30. SIP Account – Advanced Settings SIP Account- Description Advanced Account Select SIP Account to use. RPort Enable/Disable use of rport (response port number) in the SIP Via header. Send Port in... - Page 42 InnoMedia IP Phone P700 Series User Guide Anonymous Call Enable/Disable whether phone rejects Rejection anonymous incoming calls. Use Session Enable/Disable use of session refresh Timer timer. The phone will send a SIP INVITE to refresh the session during a call if this configuration is enabled.
- Page 43 InnoMedia IP Phone P700 Series User Guide encryption if remote party does not support it), Compulsory (call cannot proceed without encryption). Page 43 Copyright © 2024 InnoMedia All rights reserved.
-
Page 44: Dss Keys
InnoMedia IP Phone P700 Series User Guide 4.4 DSS Keys 4.4.1 Paperless Program Keys The number of program keys available depends on the number of lines which the IP Phone supports. Each line can accommodate 4 keys. Therefore, the P710, P720 and P730 models can support 12, 24 and 72 program keys respectively. - Page 45 InnoMedia IP Phone P700 Series User Guide Phone Status Call state for which the Softkey display and order is to be customized. Display Order Customize the display and order of Softkeys that appear in a specified call state. Page 45...
-
Page 46: Settings
InnoMedia IP Phone P700 Series User Guide 4.5 Settings 4.5.1 Basic Item Description Backlight Configure the IP Phone’s Display Backlight settings to either always off, or on, or on with a backlight timeout. Ringtone Select type of ringtone. Upload Ringtone Upload a user-specified ringtone. - Page 47 InnoMedia IP Phone P700 Series User Guide Auto Redial If Auto Redial is enabled, choose interval Interval at which Auto Redial occurs (in secs). Number of Auto If Auto Redial is enabled, number of Redials times for which Auto Redial occurs.
- Page 48 InnoMedia IP Phone P700 Series User Guide Voicemail Enable/Disable SUBSCRIBE to the PBX’s Subscription Voicemail feature. Play Voicemail Enable/Disable use of Voicemail Tone Tone when voicemail is waiting. Display Missed Enable/Disable Display of Missed Calls. Calls DND Softkey Configure whether to use a Softkey for...
- Page 49 InnoMedia IP Phone P700 Series User Guide call if there is no answer from the remote user. Pound Send Configure the character to use in dialed Method strings when the 'pound' key is pressed. [ # | %23 ] Caller ID Source Configure whether to use the SIP From or PAI header as the Caller ID Source.
-
Page 50: Time Settings
InnoMedia IP Phone P700 Series User Guide 4.5.3 Time Settings Item Description Set Time Mode Choose method for System Time synchronization or manual configuration. [SNTP | SIP Server | Manual] SNTP Server Choose either a pre-configured SNTP server or configure manually. - Page 51 InnoMedia IP Phone P700 Series User Guide Dial Plan Description Send Key Enable/Disable use of Send Key. If enabled, choose the key (* or #) to terminate a digit sequence and dial out digits immediately. Dial length Enable/Disable use of a maximum number of digits the IP Phone can dial out.
-
Page 52: Figure 32. Dial Plan 1 - Digitmap Example
InnoMedia IP Phone P700 Series User Guide “Inter Digit Timeout” timer expires. For a digitmap built up of multiple subrules based on the syntax above, the IP Phone will attempt to find the shortest possible match to any subrule and dial out immediately. -
Page 53: Figure 33. Dial Plan 2 - Digit Insertion
InnoMedia IP Phone P700 Series User Guide Index Index for this Dial Plan (non- configurable). Up to 255 Dial Plans can be supported. Description Textual description of the Dial Plan. Only used for “Peer-to-Peer” calling – Enter peer IP address to use; otherwise input 127.0.0.1. -
Page 54: Figure 34. Dial Plan 3 - Digit Insertion
InnoMedia IP Phone P700 Series User Guide Use Digit Deletion to delete any (continuous) set of digits from a dialed number. For example, delete the first 2 digits from the dialed pattern “891xxxx”. Therefore, if the user dials 8913456, the IP Phone deletes the first 2 digits, and sends out 13456. -
Page 55: Figure 35. Dial Plan 4 - Digit Replacement
InnoMedia IP Phone P700 Series User Guide Figure 35. Dial Plan 4 – Digit replacement 4.5.4.5 Dial Plan Example To summarize, a set of four rules has been configured to the Dial Plan in the figure below. Therefore, multiple rules can be set up with, in this example, a mix of Digitmaps (rule 1), Digit Insertion (rule 2), Digit Deletion (rule 3) and Digit Insertion &... -
Page 56: Keypad Lock
InnoMedia IP Phone P700 Series User Guide Figure 37. Peer-to-peer calls 4.5.5 Keypad Lock Figure 38. Keypad Lock Dial Plan Description Keypad Lock Disable or choose between different types of Keypad Lock functionality. [ Disable | Lock Menu | Lock Function | Lock All | Lock &... -
Page 57: Voip Call Forwarding
InnoMedia IP Phone P700 Series User Guide Emergency Number(s) can be dialed even when the keypad is locked. Allow BYE at End If disabled, phone will ring (instead of of Emergency Call terminating the call) if the local user attempts to hang up the phone during an Emergency Call. - Page 58 InnoMedia IP Phone P700 Series User Guide which are allowed to control the phone remotely. Multiple IP addresses can be entered separated by a comma “,”. Alternatively, input “any” to allow any hosts to control the phone. The Remote Control feature allows the PC controller to send commands to the IP Phone to perform certain actions.
-
Page 59: Action Urls
InnoMedia IP Phone P700 Series User Guide key=HEADSET Press Headset button key=RD Press Redial key=UP/DOWN/L Press Navigation key EFT/RIGHT key=AutoP Activate provisioning key=DNDOn Enable DND key=DNDOff Disable DND 4.5.8 Action URLs This feature is mainly used in the CTI (computer telephony integration) environments, where an Action URL allows the IP Phone to report its status to a PC controller under defined conditions. -
Page 60: Reboot Timing
InnoMedia IP Phone P700 Series User Guide $active_user The current active SIP user. This macro is only valid when the phone makes or receives a call. $active_host The SIP Server or PBX SIP URI to which the active SIP account registers. This macro is only valid when the phone makes or receives a call. -
Page 61: Figure 42. Scheduled Reboot Settings
InnoMedia IP Phone P700 Series User Guide Figure 42. Scheduled Reboot Settings Page 61 Copyright © 2024 InnoMedia All rights reserved. -
Page 62: Audio
InnoMedia IP Phone P700 Series User Guide 4.5.10 Audio Figure 43. Audio Codec and Related settings Audio Settings Description Select Country Configure Country to provide country- specific call progress tones. Ringer Volume Configure Ringer Volume (0-9). Handset Volume Configure Handset Volume (1-9). -
Page 63: Ringtone
InnoMedia IP Phone P700 Series User Guide OPUS Options Configure Options for the Opus codec. Choose (a) Payload Type, (b) Narrowband (NB) vs Wideband (WB) mode, (c) Variable Bit Rate (VBR) vs Constant Bit Rate (CBR). Telephone-Event Configure Payload Type to use for... -
Page 64: Blf Settings
InnoMedia IP Phone P700 Series User Guide 4.5.12 BLF Settings Configure parameters for BLF (Busy Lamp Field) groups. Note: This is the Broadsoft BLF group feature. 'Add a New Group' to assign a new BLF group to specific accounts and 'All Users->Add a New Contact' to add users to the BLF group. -
Page 65: Network Connectivity Detection
InnoMedia IP Phone P700 Series User Guide Interval If 'Periodic' is enabled, configure time interval between TR-069 provisioning cycles. 4.5.14 Network Connectivity Detection Figure 47. Network Connectivity Detection Settings Features Description Network This network monitoring check assumes Monitoring/ regular re-INVITEs are sent by the SIP Network Monitor server during a call. -
Page 66: Ems Settings
InnoMedia IP Phone P700 Series User Guide 4.5.15 EMS Settings Figure 48. EMS Settings EMS Settings Description Enable EMS Enable/Disable use of InnoMedia EMS (Element Management System) for device management. Device Type Configure EMS Device Type applicable for the IP Phone. -
Page 67: Snmp Settings
InnoMedia IP Phone P700 Series User Guide Enable Enable/Disable use of Bidirectional VQM Bidirectional (Voice Quality Measurement). This feature, in conjunction with test-agent based VQM, allows voice quality measurements to be performed by the EMS server for both the EMS-to-DUT and DUT-to-EMS directions during a loopback call. -
Page 68: Figure 50. Snmpv3 User Settings
InnoMedia IP Phone P700 Series User Guide SNMP Trap Sink Configure Port to use for the SNMP Trap Port Receiver. Public SNMP Configure Read-only SNMPv2c Community Community String. Name Private SNMP Configure Read-write SNMPv2c Community Community String. Name Enable SNMPv3 Enable/Disable use of SNMPv3. -
Page 69: User Agent Define
InnoMedia IP Phone P700 Series User Guide 4.5.17 User Agent Define Figure 51. User Agent Header Settings User Agent Description User agent Determine the parameters (Vendor, Model, Firmware version, MAC) to include in the SIP & HTTP User-Agent header and in which order. Select the... -
Page 70: Phonebook
InnoMedia IP Phone P700 Series User Guide 4.6 Phonebook 4.6.1 Personal Phonebook Figure 53. Personal Phonebook Settings Personal Description Phonebook Add a New Configure contact information and Contact associated account/groups. Note: Name and number fields cannot be all empty. Edit Click on the contact you wish to edit. -
Page 71: Group
InnoMedia IP Phone P700 Series User Guide 4.6.2 Group Figure 54. Group Settings Group Description Add a New Group Configure Description, Group Name, and associated Ringtone. Group Name field cannot be empty. Edit Click on the group name you wish to edit. -
Page 72: Figure 55. Network Phonebook - Ldap Settings
InnoMedia IP Phone P700 Series User Guide Figure 55. Network Phonebook – LDAP Settings LDAP Description LDAP Name Filter Configure Filter by Name to use for contacts on LDAP server. LDAP Number Configure Filter by Number to use for Filter contacts on LDAP server. -
Page 73: Figure 56 Network Phonebook - Huawei Ec6.X
InnoMedia IP Phone P700 Series User Guide Username Authentication Username for LDAP server. Password Authentication Password for LDAP server. Query Request Configure maximum number of query Limit results required. LDAP Name Configure Attributes for the Required Attributes Name. LDAP Number... -
Page 74: Blacklist
InnoMedia IP Phone P700 Series User Guide Phonebook Phonebook search timeout. Search Timeout 4.6.3.3 UC2.X Figure 57. Network Phonebook – Huawei UC2.X UC2.X Description Phonebook Phonebook server IP address. Server Address Phonebook Phonebook server port. Server Port Phonebook Binding account to get phonebook from Bound Account server. -
Page 75: Make Outgoing Call
InnoMedia IP Phone P700 Series User Guide 4.6.5 Make Outgoing Call The IP Phone can make an adhoc call from this page. Figure 59. Make Outgoing Call from the GUI 4.7 Maintenance 4.7.1 HTTP Upgrade & File Upload/Downloads Figure 60. HTTP Upgrade... -
Page 76: Tftp Upgrade
InnoMedia IP Phone P700 Series User Guide configuration will be uploaded to the phone. XML Personal Click 'Download' to download the IP Phonebook Phone's current personal phonebook in XML format. Or, 'Select File', choose an XML personal phonebook file, and then click 'Upload' and the phonebook will be uploaded to the phone. -
Page 77: Ftp Upgrade
InnoMedia IP Phone P700 Series User Guide Figure 61. TFTP Upgrade Page TFTP Upgrade Description Server IP Configure TFTP Server IP. File Name Configure TFTP File Name. Note: It is not necessary to provide a File Name for Backup operations. -
Page 78: Auto Provisioning
InnoMedia IP Phone P700 Series User Guide Username Configure Authentication Username for the FTP Server. Password Configure Authentication Password for the FTP Server. Software Upgrade Firmware through an FTP Upgrade Server. Configuration Update Configuration from FTP Server, or Backup Configuration to FTP Server. - Page 79 InnoMedia IP Phone P700 Series User Guide PNP Active Enable/Disable request to server to obtain a URL for upgrade. PNP Interval Configure Interval at which PNP is used. Auto Provision Enable/Disable Auto-Provisioning. DHCP Option Enable/Disable use of DHCP Options for Provisioning.
-
Page 80: Figure 64. Auto Provisioning - 2
InnoMedia IP Phone P700 Series User Guide Figure 64. Auto Provisioning - 2 Auto Provisioning Description Auto Download Enable/Disable download of DSS DSS Keys (Paperless Program Key) configuration Auto Download Enable/Disable download of Enterprise Enterprise Phonebook during Auto-Provisioning Phonebook Auto Download... -
Page 81: Log
InnoMedia IP Phone P700 Series User Guide Time to Display If 'Display Auto Provision Option on Auto Provision Reboot' is enabled, configure Time Option on Reboot Interval for which the IP Phone displays this option when booting. Disable the Enable/Disable whether phone phone while functionality is disabled while booting. -
Page 82: Default Settings
InnoMedia IP Phone P700 Series User Guide Description Disable/Call/SIP/ Select type of Log required and Debugging Level for Call Logs. [ Error Level | Warning Level | Record Level | Debugging Level ] Send Log to Enable/Disable sending of Logs to Server Server. -
Page 83: Security
InnoMedia IP Phone P700 Series User Guide 4.8 Security 4.8.1 Password Figure 68. Configure Admin/User ID and Password to access the device management console Administrator/User Configure the Username and Password for Administrator and User access levels. Administrator level access provides the capability to modify both Administrator and User credentials. -
Page 84: Server Auth Certificates
InnoMedia IP Phone P700 Series User Guide 4.8.3 Server Auth Certificates Figure 71. Import Server X.509 Certificate Import up to 5 Root CA certificates that can sign server certificates for HTTPS and/or SIP TLS server authentication. Click 'Only Accept Server Auth Certificates' to enforce server authentication. The format of the Server Auth Certificate files must be *.pem and *.crt and the maximum file size is...
