InnoMedia IP Phone P7XX Series
Quick Installation Guide
Model P730 User Interface
Model P720 User Interface
Model P710 User Interface
Table 1 Message LED/Indicator light
LED Status
Description
Red, flashing
Incoming call, or call on-hold
Red, steady
Off-hook, or call in progress, or
SIP account registration failed
Table 2. Line LEDs
LED Status
Description
Red, flashing
Incoming call
Green, steady
Call in Progress
Green, flashing
Call on-hold
LED off
Line idle
Table 3. Other LEDs
Buttons
Description
Headset, Mute,
Red color when the corresponding function is enabled.
Speaker
Advertisement
Related Manuals for InnoMedia P7 Series
Summary of Contents for InnoMedia P7 Series
- Page 1 InnoMedia IP Phone P7XX Series Quick Installation Guide Model P730 User Interface Model P710 User Interface Model P720 User Interface Table 1 Message LED/Indicator light LED Status Description Red, flashing Incoming call, or call on-hold Red, steady Off-hook, or call in progress, or SIP account registration failed Table 2.
- Page 2 List of Packaged Items Configuration via Keypad Network Settings Item Press the Menu soft key and follow the sequence: System Settings > Advanced IP Phone enter password Settings > (Default: blank) > Network > LAN Port > IP. Handset Select from the following options: Network Cable •...
