READ AND SAVE THESE INSTRUCTIONS
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
BAHAMA BREEZES
Damp Location
Ceiling Fan Owner's Manual
Model Numbers
TB344AP00
TB344CW00
Antique Pewter
Colonial White
TB344BBR00
TB344DBZ00
Brushed Brass
Distressed Bronze
Net Weight:
19.0
Lbs.
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
Part No. F40BP728900001
Form No. BP7289-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAHAMA BREEZES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tommy Bahama BAHAMA BREEZES

Summary of Contents for Tommy Bahama BAHAMA BREEZES

  • Page 1 BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 1 READ AND SAVE THESE INSTRUCTIONS XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX BAHAMA BREEZES Damp Location Ceiling Fan Owner's Manual Model Numbers TB344AP00 TB344CW00 Antique Pewter Colonial White TB344BBR00 TB344DBZ00 Brushed Brass Distressed Bronze Net Weight: 19.0 Lbs.

  • Page 2: Safety Instructions

    NOTE: This fan is suitable for use with solid-state speed controls. WARNING: To avoid fire, shock or injury, do not use a Tommy Bahama or any other brand of control not specifically approved for this fan.

  • Page 3: Unpacking Instructions

    BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 3 THIS FAN IS SUITABLE FOR DAMP LOCATIONS SUCH AS COVERED PORCHES, COVERED PATIOS, AND COVERED DECKS... ANYWHERE THERE IS A ROOF OVERHEAD. This Manual Is Designed to Make it as Easy as Possible for You to...

  • Page 4: Electrical Requirements

    BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 4 h. One loose parts bag containing: 12. Eleven 10-32 x 3/4Ó oval head 1. One 5/16-18 x 1/4Ó setscrew screws 2. One 5/32Ó hex wrench 13. Twenty-one 10-32 x 5/16Ó Phillips pan head screws 3.

  • Page 5: How To Assemble Your Ceiling Fan

    Tommy Bahama Wall Control, approved by a licensed electrician. Model No. TBSW02. Use only this Tommy Bahama Wall Control or a listed general use on/off wall switch. The Tommy Bahama TB344 Series Ceiling Fan is designed to be operat-...
  • Page 6 BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 6 8. Reinstall the hanger ball on the WARNING downrod (Figure 4) as follows. It is critical that the clevis pin in the Route the motor leads through the motor coupling is properly installed hanger ball and slide the hanger and the setscrew securely tightened.
  • Page 7 BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 7 NOTE: Some fan blades are thicker recessed holes in the motor hub. Loosely tighten the screws at this than others and require longer screws. If a bag of screws and wash- time.

  • Page 8: How To Hang Your Ceiling Fan

    BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 8 18. Position the switch housing cover 1. Securely attach the hanger brack- on the switch housing and secure et to the outlet box using the two using two 8-32 x 3/8Ó pan head screws supplied with the outlet screws (supplied) (Figure 8).

  • Page 9: How To Wire Your Ceiling Fan

    BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 9 How to Wire Your Ceiling Fan If you feel that you do not have WARNING enough electrical wiring knowledge Turning off wall switch is not suffi- experience, have your cient. To avoid possible electrical installed by a licensed electrician.
  • Page 10 BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 10 FAN SWITCH LISTED OUTLET BOX GENERAL PURPOSE BLACK FAN WIRE ON-OFF WALL LIGHT GREEN WIRE BLACK SWITCHES BLACK SWITCH (GROUND) (HOT) FROM HANGER TO 120 BRACKET VOLT WHITE SUPPLY WHT. GROUND...

  • Page 11: Using Your Ceiling Fan

    BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 11 LISTED OUTLET BOX GENERAL BLACK FAN WIRE PURPOSE ON/OFF GREEN WIRE BLACK BLACK WALL SWITCH (GROUND) (HOT) FROM HANGER TO 120 BRACKET VOLT WHITE SUPPLY WHT. GROUND WIRE GROUND GROUND BLUE...

  • Page 12: Attaching Light Kit

    This product is designed to use only those parts supplied with this product To install a Tommy Bahama accesso- and/or any accessories designated ry light kit, remove the two screws specifically for use with this product by securing the switch housing cover on Emerson Electric Co.

  • Page 13: Troubleshooting

    BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 13 WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. Trouble Shooting TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not 1.Fuse or circuit breaker 1.

  • Page 14: How To Order Repair Parts

    BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 14 Repair Parts Before discarding packaging material, be certain all parts have been removed. HOW TO ORDER REPAIR PARTS WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: • PART NUMBER • NAME OF ITEM •...
  • Page 15 BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 15 Repair Parts Listing Part Numbers Model No. Model No. Model No. Model No. Description TB344AP00 TB344BBR00 TB344CW00 TB344DBZ00 Hanger Pack, Consisting of: 761655-42 761655-85 761655-40 761655-41 Hanger Bracket — — —...

  • Page 16: Limited Warranty

    BP7289 Tommy Bahama TB344 2/26/09 10:11 AM Page 16 LIMITED WARRANTY What The Warranty Covers: This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and materials. You must be the original purchaser or user of the product to be covered.

This manual is also suitable for:

Bahama breezes tb344ap00Bahama breezes tb344cw00Bahama breezes tb344bbr00Bahama breezes tb344dbz00

Table of Contents
