1.
Selection of auto backlight mode.
Press [UNIT] to select auto backlight function, the display will show an arrow
next to LIGHT , this means auto backlight function active, press [UNIT]
again, the display will not show the arrow next to LIGHT, this means the auto
backlight function is inactive, i.e. shut off backlight function.
2.
Selection of auto shut off mode.
Press [ZERO] to select auto shut off function, the display will show an arrow
next to A_OFF, this means auto shut off function active. Press [ZERO] again,
the display will not show an arrow next to A_OFF, this means the auto shut
off function is inactive.
3.
Return to weighing mode.
Press [ON/OFF] to turn the power off, press [ON/OFF] again to turn on the
power and the scale will return to normal weighing mode.
* Counting procedures(optional)
1.Press [ON/OFF] to turn on the scale.
Wait for "0" to appear on the display.
2.Start the Count Procedure
If necessary, press [ZERO] key to set the display to "0".
3. Place a given number of samples of an item on the pan (the Sample Size should
be either 10、20、50 or 100 pieces). The weight of these samples will show on the
display.
4. Press the [UNIT] key several times to put the scale in PCS mode.
5. Select the sample size (the same as you chose above) by pressing the [PCS] key.
(press it as many times as necessary to put it in the correct sample size ,the sample
size is the same as in step three =10、20、50or100.
6. Press the [UNIT] key, the display will show "selected pcs", then the scale will
remember the sample size you selected and show the starting sample size on the
display
(you can now remove the samples if you want to return the scale to 0)
7. Place the items that you want counted onto the tray and the total number of items
will show on the display.
8. Presses the [UNIT] key to exit the counting function and return to normal
weighing or you can press ON/OFF to turn the scale off to exit .
NOTE: the weight of unit sample > 10e.
i5500 COMPACT SCALE
My Weigh iBalance SERIES
INSTRUCTION MANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for My Weigh iBalance i5500
Summary of Contents for My Weigh iBalance i5500
- Page 1 Selection of auto backlight mode. i5500 COMPACT SCALE Press [UNIT] to select auto backlight function, the display will show an arrow next to LIGHT , this means auto backlight function active, press [UNIT] again, the display will not show the arrow next to LIGHT, this means the auto My Weigh iBalance SERIES backlight function is inactive, i.e.
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS SPECIFICATIONS All safety messages are identified by the following the words "WARNING" and "CAUTION". These words mean the following: Model number i5500 Capacity 100g Division 0.005g Platter / Tray 140×165mm Important information to alert you to a Net/gross weight... -
Page 3: Parts Description
PARTS DESCRIPTION CALIBRATION RIGHT SIDE When to calibrate AC adaptor Socket Calibration may be required when it is initially installed, if the scale/balance is moved to a substantial distance. This is necessary because the weight of a mass in one location is not necessarily the Weighing platform The arch face of platform is front. -
Page 4: Before Weighing
PREPARATION WEIGHING 1.Installing batteries/Connecting the AC adaptor Before weighing Whenever possible, please allow the balance to warm up for 10 minutes after first Batteries turning to power on, so that the balance will function. Properly and accurately. Battery Remove the battery compartment compartment cover and insert six batteries(R6P/LR6 /AAsize) into the battery compartment,...
