Summary of Contents for Blue Seal Evolution GP514
- Page 1 I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L GAS GRIDDLE GP514 GP516 GP518 For use in GB & IE...
- Page 2 Moffat Limited PO Box 10001 Christchurch New Zealand (03) 389 1007 Fax: (03) 389 1276 WORLD-WIDE BRANCHES UNITED KINGDOM Blue Seal 67 Gravelly Business Park Gravelly Park Birmingham West Midlands B24 8TQ (121) 327 5575 Fax: (121) 327 9711 UNITED STATES...
-
Page 3: Table Of Contents
Contents Blue Seal Gas Griddle GP514 Gas Griddle, 600mm. GP516 Gas Griddle, 900mm. GP518 Gas Griddle, 1200mm. Introduction ..................... 2 Specifications ................... 3 Model Numbers Covered in this Specification General Gas Supply Requirements Gas Connection Dimensions ....................5 Installation ....................9... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your BLUE SEAL GAS GRIDDLE, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Blue Seal GAS GRIDDLE, there are two important things you can do. -
Page 5: Specifications
The Griddle is constructed as a hob unit and is available in 4 options, on Leg Stand (-LS), Bench Mount (-B), Cabinet Base (-CB) or with Refrigerated Base (RB) models (Not available for GP514 Models). -
Page 6: Gas Supply Requirements
Specifications Gas Supply Requirements - Australia / New Zealand Only: Natural Gas LP Gas (Propane) GP514 GP516 GP518 GP514 GP516 GP518 Input 53 MJ/hr 80 MJ/hr 108 MJ/hr 53 MJ/hr 80 MJ/hr 108 MJ/hr Rating (50,234 Btu) (75,825 Btu) (102,364 Btu) -
Page 7: Dimensions
Dimensions Dimensions for Bench Models = Rating Plate Location for this option. GP514 - B GP516 - B GP518 - B... - Page 8 Dimensions Dimensions for Cabinet Base Models = Rating Plate Location for GP514 - CB this option. GP516 - CB GP518 - CB...
- Page 9 Dimensions Dimensions for Leg Stand Models = Rating Plate Location for GP514 - LS this option. GP516 - LS GP518 - LS...
- Page 10 Dimensions Dimensions for Refrigeration Base Models = Rating Plate Location for this option. GP516 - RB GP518 - RB...
-
Page 11: Installation
Blue Seal Gas Griddles are designed to provide years of satisfactory service and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. -
Page 12: Clearances
Gas Connection NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY AN QUALIFIED PERSON. Blue Seal Gas Griddles do not require an electrical connection, as they function totally on the gas supply only. It is essential that the gas supply is correct for the appliance to be installed and that adequate supply pressure and volume is available. -
Page 13: Commissioning
Installation The regulator connections are " BSP female. The connection to the appliance is " BSP male. (Refer to the ‘Specifications’ section for the gas supply location dimensions). NOTE: A Manual Isolation Valve must be fitted to the individual appliance supply line. Correctly locate the appliance into its final operating position and using a spirit level, adjust the legs so that the unit is level and at the correct height. -
Page 14: Operation
/ operator. Blue Seal Gas Griddles have been designed to provide simplicity of operation and 100% safety protection. Improper operation is therefore almost impossible, however bad operation practices can reduce the life of the gas griddle and produce a poor quality product. -
Page 15: Lighting The Pilot Burner
Operation WARNING: 235°C URFACE TEMPERATURE OF THE GRIDDLE PLATE CAN REACH OVER WHEN THE APPLIANCE IS OPERATED AT FULL SETTING Lighting the Pilot Burner These griddles are fitted with a pilot as a standard option and flame failure protection, which is incorporated for each main burner, by way of a thermo-electric system. - Page 16 Operation Turning 'Off' the Main Burner / Pilot Turn the gas control knob clockwise to the pilot position. The main burner will extinguish and the pilot burner will remain alight. To turn 'OFF' the appliance completely, turn the gas control knob fully clockwise to the 'O' position, the pilot burner will extinguish.
-
Page 17: Cleaning And Maintenance
Cleaning and Maintenance AUTIO N Always turn off the gas supply before cleaning. This appliance is not water proof. Do Not use water jet spray to clean interior or exterior of this appliance. General Clean the griddle regularly. A clean appliance looks better, will last longer and will perform better. Carbonised grease on the surface or on the griddle plate will hinder the transfer of heat from the cooking surface to the food. -
Page 18: Daily Cleaning
Cleaning and Maintenance Daily Cleaning The grease drawer should be checked and emptied frequently to prevent overflow and spillage. Remove the grease drawer while still warm so that the grease is in a liquid state. Empty any grease from the drawer and wash thoroughly in the same manner as any cooking utensil. Clean the Control Panel with a damp cloth lightly moistened with a solution of mild detergent and water. -
Page 19: Periodic Maintenance
Cleaning and Maintenance a. Remove and clean the grease collection drawer frequently to prevent over spills. b. Clean the griddle surface thoroughly with the supplied scraper tool. c. Allow the plate to cool, then clean the plate with a scrubbing brush, a mild non-abrasive detergent and water. -
Page 20: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during the operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 21: Gas Conversion And Specifications
Gas Conversion and Specifications Conversion Procedure AUTIO N Ensure that the appliance is isolated from the gas supply before commencing servicing. NOTE: • These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. •... - Page 22 Gas Conversion and Specifications Refit the front control panel and tighten the 2 screws on the underside to secure the panel in place. Refit the control knobs to the front control panel. The control knobs are a push fit onto the shafts of the gas control valves.
- Page 23 Gas Conversion and Specifications Gas Regulator NOTE: The regulator supplied is convertible between Natural Gas and LPG, but it’s outlet pressure is fixed ex-factory and is NOT to be adjusted. NOTE, Pin rotated for Natural Gas NOTE, Pin rotated for LPG Fig 9 Ensure that the gas supply is turned ‘OFF’...
- Page 24 Gas Conversion and Specifications Commissioning Before leaving the converted installation; WARNING: NAKED FLAME O NOT USE A TO CHECK FOR GAS LEAKAGES Check all gas connections for leakages using soapy water or other gas detecting equipment. Check the following functions in accordance with the operating instructions specified in the ‘Operation’...
-
Page 25: Gas Specifications
Gas Conversion and Specifications Gas Specifications - Australia / New Zealand Only Natural Gas LP Gas (Propane) GP514 GP516 GP518 GP514 GP516 GP518 Main Burner Injector 3.60mm 3.00mm 2.85mm 2.10mm 1.80mm 1.70mm Pilot Burner Injector 0.41 0.25 Low Fire Adjustment 1 Turn 'Out' c.c.w. -
Page 26: Replacement Parts List
Knob Adaptor Eurosit. 227381 Gas Control Knob - 100°C to 290°C. 032360 Main Injector (Nat) 3.60mm (GP514 - Non-UK). 032340 Main Injector (Nat) 3.40mm (GP514 - UK only). 032300 Main Injector (Nat) 3.00mm (GP516). 032285 Main Injector (Nat) 2.85mm (GP518). 032210 Main Injector (LPG) 2.10mm... - Page 27 Replacement Parts List Gas Conversion Kits Gas Type to Convert to Models Australia / New Zealand Only UK Only Nat. Gas Nat. Gas Propane GP514 232025 232024 232025 232024 GP516 232033 232032 232033 232032 GP518 232037 232036 232037 232036 Accessories 228566 Griddle Scraper Tool.
