- Page 1 I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l Gas Griddle GP8600G GPL8600G GP8900G...
- Page 2 Moffat Limited PO Box 10001 Christchurch New Zealand (03) 389 1007 Fax: (03) 389 1276 WORLD-WIDE BRANCHES UNITED KINGDOM Blue Seal 67 Gravelly Business Park Gravelly Park Birmingham West Midlands B24 8TQ (121) 327 5575 Fax: (121) 327 9711 UNITED STATES...
-
Page 3: Table Of Contents
Contents Waldorf Gas Griddle GP(L)8600G Gas Griddle, 600 mm. GP(L)8900G Gas Griddle, 900 mm. GP(L)8120G Gas Griddle, 1200 mm. Introduction ..................... 2 Specifications ................... 3 Model Numbers Covered in this Specification General Gas Supply Requirements Gas Connection Dimensions ....................5 Installation .................... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your WALDORF GAS GRIDDLE, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Waldorf GAS GRIDDLE, there are two important things you can do. -
Page 5: Specifications
The Griddle is constructed as a hob unit and is available in 4 options, on Leg Stand (-LS), Bench Mount (-B), Cabinet Base (-CB) or with Refrigerated Base (RB) models (Not available for GP8600G Models). -
Page 6: Gas Supply Requirements
Specifications Gas Supply Requirements - Australia /New Zealand Only: Natural Gas LP Gas (Propane) GP8600G GP8900G GP8120G GP8600G GP8900G GP8120G Input 53 MJ/hr 80 MJ/hr 108 MJ/hr 53 MJ/hr 80 MJ/hr 108 MJ/hr Rating (50,234 BTU) (75,825 BTU) (102,364 BTU) -
Page 7: Dimensions
Dimensions Bench Models = Rating Plate Location for GP(L)8600G - B this option. GP(L)8900G - B GP(L)8120G - B... - Page 8 Dimensions Cabinet Base Models = Rating Plate Location for GP(L)8600G - CB this option. GP(L)8900G - CB GP(L)8120G - CB...
- Page 9 Dimensions Leg Stand Models = Rating Plate Location for GP(L)8600G - LS this option. GP(L)8900G - LS GP(L)8120G - LS...
- Page 10 Dimensions Refrigeration Base Models = Rating Plate Location for this option. GP(L)8900G - RB GP(L)8120G - RB...
-
Page 11: Installation
Location Installation must allow for a sufficient flow of fresh air for the combustion air supply. Combustion Air Requirements: GP8600G GP8900G GP8120G Natural Gas (G20) 14 m... -
Page 12: Clearances
Installation Clearances NOTE: Only non-combustible materials can be used in close proximity to this appliance. Combustible Surface Non Combustible Surface Left / Right Hand Side 50mm Rear 50mm Assembly This model is delivered completely assembled. Ensure that the legs are securely attached. NOTE: •... -
Page 13: Gas Connection
Installation Gas Connection NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY AN QUALIFIED PERSON. Waldorf Gas Griddles do not require an electrical connection, as they function totally on the gas supply only. It is essential that the gas supply is correct for the appliance to be installed and that adequate supply pressure and volume is available. -
Page 14: Commissioning
Installation Check that the gas operating pressure is as shown in the ‘Specifications’ section. NOTE: The operating pressure is to be measured at the burner operating pressure test point outlet and with one griddle burner operating at the ‘High Flame’ setting. Turn off the mains gas supply and bleed the gas out of the appliance gas lines. -
Page 15: Operation
Operation Operation Guide AUTIO N • This appliance is for professional use and is only to be used by qualified people. • Only authorised service persons are to carry out installation, servicing or gas conversion operations. • Components having adjustments protected (e.g. -
Page 16: Lighting The Pilot Burner
Operation WARNING: 235°C URFACE TEMPERATURE OF THE GRIDDLE PLATE CAN REACH OVER WHEN THE APPLIANCE IS OPERATED AT FULL SETTING Lighting the Pilot Burner These griddles are fitted with a pilot as a standard option and flame failure protection, which is incorporated for each main burner, by way of a thermo-electric system. -
Page 17: Re-Setting The Overtemp Device
Operation Re-Setting the Overtemp Device (All UK and Optional Non-UK Models). This griddle is fitted with an overtemp device which isolates the gas supply to the burners should the gas control system or thermostat malfunction, thus preventing overheating of the griddle. If the pilot fails to ignite after several attempts, ensure that the overtemp is checked to ensure that it has not tripped. -
Page 18: Cleaning And Maintenance
Cleaning and Maintenance AUTIO N Always turn off the gas supply before cleaning. This appliance is not water proof. Do Not use water jet spray to clean interior or exterior of this appliance. General Clean the griddle regularly. A clean appliance looks better, will last longer and will perform better. Carbonised grease on the surface or on the griddle plate will hinder the transfer of heat from the cooking surface to the food. -
Page 19: Daily Cleaning
Cleaning and Maintenance Daily Cleaning The grease drawer should be checked and emptied frequently to prevent overflow and spillage. Remove the grease drawer while still warm so that the grease is in a liquid state. Empty any grease from the drawer and wash thoroughly in the same manner as any cooking utensil. Clean the Control Panel with a damp cloth lightly moistened with a solution of mild detergent and water. - Page 20 Cleaning and Maintenance a. Occasionally bleach the plate with vinegar when cold. b. Dry the griddle thoroughly with a dry cloth and polish with a soft dry cloth. c. The griddle should be switched on briefly to ensure that the griddle plate becomes dry. Griddle Cooking Area a.
-
Page 21: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during the operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 22: Gas Conversion And Specifications
Gas Conversion and Specifications Conversion Procedure AUTIO N Ensure that the appliance is isolated from the gas supply before commencing servicing. NOTE: • These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. •... - Page 23 Gas Conversion and Specifications Refit the front control panel and tighten the 2 screws on the underside to secure the panel in place. Refit the control knobs to the front control panel. The control knobs are a push fit onto the shafts of the gas control valves.
- Page 24 Gas Conversion and Specifications Gas Regulator NOTE: The regulator supplied is convertible between Natural Gas and LPG, but it’s outlet pressure is fixed ex-factory and is NOT to be adjusted. NOTE, Pin rotated for Natural Gas NOTE, Pin rotated for LPG Fig 10 Ensure that the gas supply is turned ‘OFF’...
- Page 25 Gas Conversion and Specifications Commissioning Before leaving the converted installation; WARNING: NAKED FLAME O NOT USE A TO CHECK FOR GAS LEAKAGES Check all gas connections for leakages using soapy water or other gas detecting equipment. Check the following functions in accordance with the operating instructions specified in the ‘Operation’...
-
Page 26: Gas Specifications
Gas Conversion and Specifications Gas Specifications - Australia / New Zealand Only Natural Gas LP Gas (Propane) GP8600G GP8900G GP8120G GP8600G GP8900G GP8120G Main Burner Injector 3.60mm 3.00mm 2.85mm 2.10mm 1.80mm 1.70mm Pilot Burner Injector 0.41 0.25 Low Fire Adjustment... -
Page 27: Replacement Parts List
Gas Control Knob - 100°C to 290°C. 032360 Main Injector (Nat) Ø 3.60mm (GP8600G - Non-UK). 032340 Main Injector (Nat) Ø 3.40mm (GP8600G - UK only). 032300 Main Injector (Nat) Ø 3.00mm (GP8900G). 032285 Main Injector (Nat) Ø 2.85mm (GP8120G). - Page 28 Replacement Parts List Gas Conversion Kits Gas Type to Convert to Models Australia / New Zealand Only UK Only Nat. Gas Nat. Gas GP8600G 232025 232024 232029 232028 GP8900G 232033 232032 232033 232032 GP8120G 232037 232036 232037 232036 Accessories 228566 Griddle Scraper Tool.
