SERVICE MANUAL
INTEGRATED COLOR TV / STEREO VIDEO
CASSETTE RECORDER
VERSION
There are 2 types for this model. Because, PCB and Parts are different each other.
VERSION
This manual is for VERSION "B" in the above List.
REVISION PUBLISHING 1
A
A51KSV43X07(M0)
B
A51KST93X31(VM0)
A
672-0226001 ~ 672-0628960
B
672-0712001 ~
S/M Code No.09-003-341-4S1
VX-S207
BASIC TAPE MECHANISM : OVD-6
CRT
PWB070
TM9437A
TM9433A
SERIAL
U
PWB010
TC9296A
TC9293A
S/M PARTS No.
09-003-341-4N1
09-003-341-4S1
