Aiwa VX-FT21 Service Manual

Aiwa VX-FT21 Service Manual

Integrated color tv/stereo video cassette recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL
INTEGRATED COLOR TV/STEREO
VIDEO CASSETTE RECORDER
POWER REQUIREMENTS ............
POWER CONSUMPTION ..............
WEIGHT .........................................
DIMENSIONS .................................
PICTURE TUBE .............................
TUNER SYSTEM ...........................
CHANNEL COVERAGE .................
TV SYSTEM ...................................
HORIZONTAL RESOLUTION .......
OPERATING TEMPERATURE ......
VIDEO RECORDING SYSTEM .....
VIDEO SIGNAL SYSTEM ..............
VIDEO HEAD .................................
USABLE CASSETTES ...................
SPECIFICATIONS
230V AC, 50Hz
82W
Standby 6W
Approx.26.5 kg (58.4 lbs.)
574 mm (W) x 489 mm (D) x
502 mm (H)
(22 5/8 x 19 3/8 x 19 7/8 in.)
21 in. (50.8 cm "V"), 90 degree
deflection
Frequency synthesized tuners
UHF: 21 to 69
I
240 lines
5°C to 40°C
Rotary 2 head helical scanning system
PAL colour signal, 625 lines, 50 fields
Double azimuth 6 heads
VHS video cassettes
S/M Code No. 09-00A-350-2N1
VX-FT21
BASIC TAPE MECHANISM : OVD-6S
TAPE SPEED ...................................
RECORDING/PLAYBACK TIME .....
VIDEO INPUT ...................................
VIDEO OUTPUT ..............................
VIDEO S/N .......................................
AUDIO INPUT ..................................
AUDIO OUTPUT ..............................
AUDIO TRACK .................................
•
Design and specifications are subject to change without
notice.
KL
PAL
SP: 23.39 mm/sec.
LP: 11.69 mm/sec.
NTSC (playback SP only)
33.35 mm/sec.
PAL
SP: 5 hours max. with E-300 tape
LP: 10 hours max. with E-300 tape
NTSC (playback SP only)
3 hours 30 minutes max. with T-210
tape
1.0Vp-p, 75 ohm, unbalanced
1.0Vp-p, 75 ohm, unbalanced
53dB (nominal)
SCART: –3.8 dBs, 50K ohm
RCA: –3.8 dBs, 50K ohm
SCART: –3.8 dBs less than 1K ohm
3 tracks (Hi-Fi sound 2 tracks,
Normal sound 1 track)
