SERVICE MANUAL
INTEGRATED COLOR TV / STEREO VIDEO
CASSETTE RECORDER
GENERAL
POWER REQUIREMENTS .................
POWER CONSUMPTION ...................
WEIGHT ..............................................
DIMENSIONS ......................................
TV SECTION
PICTURE TUBE ..................................
TUNER SYSTEM ................................
CHANNEL COVERAGE ......................
PROGRAM MEMORY .........................
TV SYSTEM ........................................
HORIZONTAL RESOLUTION ............
ANTENNA INPUT ...............................
VCR SECTION
OPERATING TEMPERATURE ...........
VIDEO RECORDING SYSTEM ..........
VX-S137
BASIC TAPE MECHANISM : OVD-6
SPECIFICATIONS
120V AC, 60Hz
91W
TYP 4W (power save mode)
13.5 kg (29.8 lbs.)
435 mm (W) x 370.5 mm (D) x
384.5 mm (H)
(17 1/4 x 14 5/8 x
15 1/4 in.)
208 mm (W) x 211 mm (H)
(8 1/4 x 8 3/8 in.)
335 mm (diagonal) (13 in.)
Frequency synthesized tuner
VHF: 2 to 13
UHF: 14 to 69
CATV: 5A, A-1 to A-5, A to W,
W+1 to W+84
181
M
230 lines
75 ohms, unbalanced
5°C to 40°C
Rotary 2 head helical scanning
system
S/M Code No. 09-004-344-3N1
VIDEO SIGNAL SYSTEM ................
VIDEO HEAD ...................................
USABLE CASSETTES .....................
TAPE SPEED ...................................
RECORDING/PLAYBACK TIME .....
VIDEO INPUT ...................................
VIDEO OUTPUT ..............................
VIDEO S/N .......................................
AUDIO INPUT ..................................
AUDIO OUTPUT ..............................
AUDIO TRACK .................................
FAST-FORWARD TIME ...................
REWIND TIME .................................
HI-FI DYNAMIC RANGE ..................
HI-FI FREQUENCY RESPONSE ....
HI-FI WOW AND FLUTTER .............
•
Design and specifications are subject to change without
notice.
U
NTSC color system, 525 lines, 60
fields
Azimuth 2 head
VHS video cassette
S-VHS video cassette (play back only)
SP: 33.35 mm/sec
LP: 16.67 mm/sec
SLP: 11.12 mm/sec
SP: 3 hours with T-180 tape
LP: 6 hours with T-180 tape
SLP: 9 hours with T-180 tape
1.0Vp-p, 75 ohm, unbalanced
1.0Vp-p, 75 ohm, unbalanced
53dB (nominal)
–8dBs, 50K ohm
–8dBs, less than 1K ohm
3 tracks (Hi-Fi sound 2 tracks, Normal
sound 1 track)
Approx. 2 minutes 15 seconds
with T-120 tape
Approx. 1 minute 48 seconds
with T-120 tape
More than 90dB
20Hz-20kHz
Less than 0.01%
