RC Helicopter Instruction Manual
Main Features:
Single blade for more flexible, fast flight and better wind
resistance, fly outdoor or indoor.
Features gyroscopic stabilization technology for smooth, easy-to-
control flight.
Easy to install and repair.
Specifications, material in this brochure are for reference only, any
different please check with our website www.symatoys.com
2.4G
AGES 14+
Advertisement
Table of Contents
Related Manuals for SYMA F3 2.4G
Summary of Contents for SYMA F3 2.4G
- Page 1 AGES 14+ 2.4G RC Helicopter Instruction Manual Main Features: Single blade for more flexible, fast flight and better wind resistance, fly outdoor or indoor. Features gyroscopic stabilization technology for smooth, easy-to- control flight. Easy to install and repair. Specifications, material in this brochure are for reference only, any different please check with our website www.symatoys.com...
-
Page 2: Important Note
PREFACE Dear customer, Thank you for buying SYMA’s product. For your quickly grasp the operating performance of this product please read the instructions carefully and keep it. IMPORTANT NOTE 1.This not a general toys but a precision rc helicopter which is a combination of professional and technical as machinery, electronics, aerodynamics, and high-frequency transmitter. -
Page 3: Packing List
PACKING LIST Body frame Head cover Remote USB charging control wire Main blades (include tail blade) Charger case Li-Polymer batteries Battery installation Battery cover 4 X 1.5V ‘AA’batteries Unscrew and remove battery cover from RC unit. Insert 4 ‘AA’ batteries, noting polarity indicators. - Page 4 ASSEMBLY OF BATTERY TO HELICOPTER Insert fully charged battery into the socket and press tight. level surface Step one: Open the controller ,then controller ticking and indicator flashes quickly Step Two: Install the battery into the battery case , then set the helicopter on a level surface ,indicator will flash two times the first slow , then indicator becomes to Medium-speed flash.
- Page 5 REMOTE CONTROL KEYPAD AND lcd MANUAL Indicator light “B” Switch Antenna Hight/lLow speed mode button Right function lever Power ON/OFF (Direction lever) Left function lever (accelerator) Forward/backward Throttle lever fine-tuning fine-tuning "A" Switch Mode 1: Mode 1: Turn left/right Strifes left/right fine tuning fine tuning Mode 2: Turn left/right fine tuning Mode 2:...
- Page 6 HELICOPTER CONTROL ILLUSTRATION (MODE 1) Operation Direction Fine-tuning Operation Push the throttle up or down, While helicopter is descending, the helicopter flies up ward or push the fine-tuning button up. downward. While helicopter is ascending, push the fine-tuning button down, Push the direction control rod While helicopter moves forward, up or down, the helicopter flies...
- Page 7 HELICOPTER CONTROL ILLUSTRATION (MODE 2) Operation Direction Fine-tuning Operation While helicopter is descending, push Push the throttle up or down, the the fine-tuning button up. While helicopter flies upward or helicopter is ascending, push the downward. fine-tuning button down. Push the direction control rod up While helicopter moves forward, or down, the helicopter flies push the fine-tuning button down.
-
Page 8: Charging Battery
4. To avoid the battery short-circuit, please keep the charging battery on a horizontal surface and avoid dropping. 5. Please use the USB cable supplied by SYMA and change the aging battery. 6. To avoid the battery repeating the charging and discharging... - Page 9 DETAIL ILLUSTRATION Decoration cap Balance bar Main blade grip set Connecting buckle Main shaft base Connect buckle base Main blade Limited buckle Long connecting buckle Wobbler Steering engine pull rod Wobbler base Main shaft Main shaft pipe Main frame Main motor Main gear Steering engine arm Circuit board...
- Page 10 EXAMINING PROCESS Offering solutions Problem Cause 1.Charge the helicopter. 1.Helicopter’s battery is low. 2.Replace the remote controller’s batteries. 2.Controller’s batteries are low, the Helicopter 3.Turn off the helicopter and match the indicator will keep flashing. band again. not work 3.Failure to match the band from remote 4.Turn off helicopter and put it in a controller.
-
Page 11: Main Information
MAIN INFORMATION Main blade Diameter: 190 mm Body length: 230 mm Body width: 55 mm Body height: 90 mm Main motor size : Tail motor size: Battery: 3.7V / 150 mah Gyroscope : Lock gyro 230mm 190mm 90mm 55mm...
