S
2.4G R/C Helicopter
Main characteristics
Die-cast structure is applied, makes the action of this helicopter more flexible with
stable flying performance.It can be flied indoor.
Built-in Gyro stabilizer can ensure accurate positioning in the air.
Modular design structure is applied, more simple for assembly and convenient for
maintenance.
The materials and specification mentioned in this instruction manual or the parts
inside this package is for reference only.Our company won't be responsible for any
adaption of the outer package.Nor shall we keep our customers informed in advance.
Any information updated or changed,please be subject to the website of Syma
flying model company.
Gyroscope System
36
AGES 14+
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SYMA S36
Summary of Contents for SYMA S36
- Page 1 Any information updated or changed,please be subject to the website of Syma flying model company.
- Page 2 PREFACE Dear customers: Hello! Thank you for purchasing our flying model.Please read this instruction manual carefully in order to master the skill required in order to master the skill more quickly and operate this product more safely.In the mean time, please well keep the original of this instruction manual for future reference.
- Page 3 BATTERY INSTALLATION AND CHARGING Battery Installation Unscrew and remove battery cover from R/C unit, insert 4 ‘AA’ Battery cover batteries, noting polarity indicators. Replace battery cover. 4×1.5V batteries Charging Helicopter ON/OFF Switch A. Remote control B. Computer charging charging Charge port Plug wire in helicopter WHEN CHARGING BE SURE TO TURN THE WITCH ON HELICOPTER TO “OFF”...
- Page 4 BATTERY LOADING FOR HELICOPTER AND READY TO FLY Hover up and down Turn left,turn right Learn how to hover (fly in place) first-once Pull the direction control lever to the left or to you’ve mastered this operation, flying is easy. the right, the helicopterwill turn to the left or Once you can hover, try moving up and down to the right.
- Page 5 Below are the parts available for your kindly selection.In order to facilitate our customers for placing an order, we specially offer all kinds of parts for your kindly selection.You can buy these parts via our local agent as well. S36-01A S36-01B S36-02A...
- Page 6 BREAKDOWN & DIAGRAM...
- Page 7 Number Product Name Quantity Number Product Name Quantity Balance bar Tail dangling Connetine backle Tail gearbox Spindle seat Tail motor Upper blade Tail blade Down blade Tripod Upper blade clip 2.0 Stainless steel tube Down blade clip 2.5 Stainless steel tube Main frame Stop collar Head fixing part...
- Page 8 MAIN PARAMETER Diameter of main rotor: 197mm Length of fuselage:240mm Width of fuselage: 45mm Height of fuselage: 110mm Code of main engine:M20x2 Code of negative engine: 6 Battery: 3.7V/150mAh Gyroscope: Tail-locking gyro 197mm 45mm 240mm...
