  • Page 1 ADSL2/2+ Router - 1 -...

  • Page 2: Copyright Statement

    All photos and product specifications mentioned in this manual are for references only. Upgrades of software and hardware may occur, and if there are changes, Tenda is not responsible for notifying in advance. If you would like to know more about our product information, please visit our website at www.tenda.cn.

  • Page 3: Table Of Contents

    ADSL2/2+ Router TABLE OF Contents CHAPTER 1 PRODUCT OVERVIEW..........- 6 - 1.1 Product Features..............- 7 - 1.2 Package Contents ..............- 8 - CHAPTER 2 HARDWARE DESCRIPTION ........- 10 - 2.1 Panel Layout................- 10 - 2.1.1 Front Panel ..............- 10 - 2.1.2 Back Panel ..............
  • Page 4 ADSL2/2+ Router 4.2.8 Security ..............- 72 - 4.2.9 Time Restriction............- 76 - 4.2.10 Quality of Service ............ - 78 - 4.2.11 Routing..............- 80 - 4.2.12 DNS ................. - 83 - 4.2.13 DSL................- 85 - 4.2.14 UPnP ................ - 86 - 4.2.15 Interface Grouping ...........
  • Page 5 ADSL2/2+ Router 4.7 Back to Wizard..............- 120 - APPENDIX 1..................- 121 - 1. Setting the IP of your PC manually........- 121 - 2. PC dial-up................- 122 - APPENDIX 2..................- 126 - 1. Troubleshooting ..............- 126 - 2. Verifying the Connection ............- 127 - 3.

  • Page 6: Chapter 1 Product Overview

    ADSL2/2+ Router Chapter 1 Product Overview Note: This user guide applies to W300D and W150D products. W300D is used as an example throughout this user guide for demonstration and explanation. The differences between the two products are: the former has 2 antennas and the maximum wireless rate it can reach is 300Mbps;...

  • Page 7: Product Features

    Tenda offers you easy installation and fast, shared internet access. In a word, with fast wireless speed and large coverage, W300D is the best choice for families, student dorms and small-sized enterprises, etc to access Internet wirelessly.

  • Page 8: Package Contents

    ADSL2/2+ Router Provides 4 LAN ports and the fourth LAN port can be used as a WAN port Supports ADSL （telephone line） and LAN （network cable） access ways Supports Firewall to prevent hacker attacks Supports WPA and the latest WPA2 encryption methods and security authentication agreement Supports Bridge, PPPoE, PPPoA, dynamic IP and static IP, etc broadband access methods etc...
  • Page 9 ADSL2/2+ Router Two RJ11 Telephone Lines One Quick Installation Guide One CD-ROM If any of the above listed items is missing or damaged, please contact your Tenda reseller for immediate replacement. - 9 -...

  • Page 10: Chapter 2 Hardware Description

    2.1.1 Front Panel W300D”s Front Panel There are 9 LED indicators on the front panel of W300D. You can judge whether the device is in correct working condition by checking the status of the indicators. The meanings of the indicators are described...
  • Page 11 ADSL2/2+ Router Green Flashing System functions correctly Packets being Flashing WLAN Green transferred Wireless is disabled Slow ADSL Link has not been Flashing established Fast ADSL Link being ADSL Green Flashing established ADSL Link has already Always On been established Unconnected Packets being...

  • Page 12: Back Panel

    ADSL2/2+ Router 2.1.2 Back Panel W300D’s Back Panel ON/OFF: Power Switch. Press it in to turn on the power and press it out to turn off the power. WPS/RESET：Hold and press it for 1 second to connect WPS, and 7 seconds to bring all settings back to factory defaults.

  • Page 13: Hardware Connection

    ADSL2/2+ Router 2.2 Hardware Connection Follow the diagram below to connect your network devices when using DSL uplink access mode (through telephone line). Follow the diagram below to connect your network devices when using Ethernet uplink access mode (through network cable). - 13 -...

  • Page 14: Chapter 3 Fast Configuration

    ADSL2/2+ Router Chapter 3 Fast configuration Since we are using computer to access Internet, we need to first configure the computer and then log on to router’s management interface (WEB UI) to configure the router through the configured computer. Select an appropriate way from the 2 options below to access your router depending on your network knowledge: log in to the router’s Web-based UI through “Setup Wizard”...
  • Page 15 ADSL2/2+ Router Click “Change adapter settings” on the left side of the window. Right click “Local Area Connection” and select “Properties”. - 15 -...
  • Page 16 ADSL2/2+ Router 4. Select” Internet Protocol Version 4(TCP/IPv4)"and then click “Properties”. Select “Obtain an IP address automatically” and “Obtain DNS server - 16 -...
  • Page 17 ADSL2/2+ Router address automatically”. Click “OK” to save the configurations. Note: Certainly you can set your IP manually, for detailed information ： please refer to appendix 1 B. Insert the provided CD-ROM in your PC’s drive: If your PC does not run the CD-ROM content automatically. Open it and icon, then follow the prompts.

  • Page 18: Logging On To Your Router Through Web Browser

    ADSL2/2+ Router 3.2Logging on to your router through Web browser Before entering the web browser, you need to verify the connectivity between the router and your computer. First, click the start menu on the lower left corner of your computer desktop.
  • Page 19 ADSL2/2+ Router Then, input “cmd” in the search programs and file texts box and press “enter’. Finally, Open the dos window and enter “ping 192.168.1.1”, and press Enter. If the screen displays the following results, it indicates your computer has already been connected to the router. Now the direct link between your computer and the router has been successfully established, which means you can log on to the router’s web-based utility.
  • Page 20 ADSL2/2+ Router Open the IE Browser as shown below. Input http://192.168.1.1 in the address field and press “Enter” to enter router’s management interface. The router’s management interface is displayed as below: - 20 -...

  • Page 21: Fast Internet Access

    ADSL2/2+ Router 3.3Fast Internet Access In previous section, we have explained how to log on to the router and in the following; we are going to illustrate how to configure the router quickly to let your PC access Internet. Now check whether you have the screen below, if not, please re-log on to the router’s management interface.
  • Page 22 ADSL2/2+ Router VPI/VCI PPPOE User name PPPOE Password VPI/VCI: Different areas and ISPs have different VPI/VCI. For the convenience of its users, the device has integrated many important VPI/VCI. Therefore, you only need to select your ISP and area and the device will provide you with an auto-matched VPI/VCI in accordance with your area.
  • Page 23 ADSL2/2+ Router wireless parameters. Please read the following: Key：It allows you to enter a password; only the users who know your password can be connected to your wireless network. For example, if you want to set the password to 88888888, follow the configurations as shown in the figure below: Note: 1.
  • Page 24 ADSL2/2+ Router “ ” “ ” ’ After all settings are finished and status shows “Connected”. Congratulations! You can access Internet now! - 24 -...
  • Page 25 ADSL2/2+ Router Launch a web browser; enter http://www.tenda.cn in the address field and Internet access will be successful as below: Now, try to use a wireless network adapter to search “tenda_051609”: First, click (network adapter connection icon) to search wireless...
  • Page 26 ADSL2/2+ Router Then click “tenda_051609”select “Connect” to go to the dialogue box below: Enter the key: 88888888 and click “OK”; system will automatically connects with your wireless network in a while. Advanced settings provide you more powerful functions such as filter, QoS and port range forwarding.

  • Page 27: Chapter 4 Advanced Settings

    ADSL2/2+ Router Chapter 4 Advanced Settings Enter the setup wizard screen below and then click “Advanced Settings” on the right top corner as shown in the figure below: After you enter the advanced settings screen, you can set the advanced settings for the router to satisfy your requirements.

  • Page 28: Device Information

    ADSL2/2+ Router 4.1 Device Information There are five submenus: Summary, WAN, Statistics, Route and ARP. Summary: It displays system information ， current status of WAN connection and Wireless as shown in the figure below: - 28 -...
  • Page 29 ADSL2/2+ Router WAN: Click this menu to display the WAN information of this routing modem: Interface, Description, Type, Igmp, NAT, Firewall, Status, IPv4 Address and vlanID as shown in the figure below: Statistics: It gathers the received and transmitted packets on LAN/WAN ports.
  • Page 30 ADSL2/2+ Router the device’s LAN ports as shown in the figure below: Note: eth0, eth1 and eth2 are respectively LAN port1, 2 and 3 of the device; and wl0 is a wireless port. Statistics—WAN: It displays the received and transmitted packets of the device’s WAN port as shown in the figure below: Statistics-xDSL: It displays statistic information of ADSL connection...
  • Page 31 ADSL2/2+ Router Route: displays routing table of the device as shown in the figure below: ARP: displays the device’s LAN ports, IP and MAC addresses of the PCs that are wirelessly connected as shown in the figure below: - 31 -...

  • Page 32: Advanced Setup

    ADSL2/2+ Router 4.2 Advanced Setup Advanced Setup: Consists of 14 submenus including Connection Mode/ Service/LAN/DHCP Setting/NAT/Security/Time Restriction/Quality Service/Routing/DNS/DSL/UPnP/ Interface Grouping and Multicast as shown in the figure below: 4.2.1 Connection mode Connection Mode This router supports two connection modes: DSL mode and Ethernet mode.
  • Page 33 ADSL2/2+ Router enter connection mode interface, click “Advanced Setup”---“Connection Mode”. Select a proper connection mode and then click the “Apply” button. 1. In DSL mode, you are required to configure parameters for ATM interface. To enter the ATM Interface page, click “Advanced Setup”---“Connection Mode”...

  • Page 34: Wan Service

    ADSL2/2+ Router 2. In Ethernet modes, you are required to configure parameters for Ethernet interface. To enter the ETH Interface page, click “Advanced Setup”---“Connection Mode” (Select Ethernet mode click “Apply”) “WAN Service”---“ETH Interface”. And then click the “Add” button to configure relevant parameters.
  • Page 35 ADSL2/2+ Router type EOA unchanged, and click the “Apply/Save” button. For details, refer to 4.2.1----1) ---“Connection Setting” to enter WAN service setup interface (page1) and then click the “Add” button there to select a WAN service type on page 2. Page 1 Page 2 Select PPP over Ethernet (PPPoE), modify the service description if...
  • Page 36 ADSL2/2+ Router Page 3 PPP User Name: User name for PPPoE dialup. It is provided by your ISP. PPP Password: The password provided by your ISP for PPPoE dialup. PPPoE Service Name: It is provided by your ISP. Do not fill it in if you don’t have it;...
  • Page 37 ADSL2/2+ Router PPP IP extension: The IP addresses of all packets including management packets that egress WAN port will be converted to the WAN port’s IP address once this feature is enabled. Enable PPP Debug Mode: This feature can be enabled only when supported by your ISP.
  • Page 38 ADSL2/2+ Router page 5 This page allows you to configure the DNS server’s IP address for the WAN port. We recommend you to keep the default values if you are not clear about it and click the “Next” button (on page 5) to enter the following page (page 6): - 38 -...
  • Page 39 ADSL2/2+ Router Page 6 This page displays the configuration information. After confirmation, please click “Apply/Save” to save it. You can access Internet once PPPoE dialup succeeds. IP over Ethernet When your ISP provides you an IP address or tells you that you only need to configure your PC to obtain an IP address automatically to access Internet, you need to select IP over Ethernet （...
  • Page 40 ADSL2/2+ Router Obtain an IP address automatically: WAN port will automatically obtain an IP address for accessing Internet from the ISP, if this feature is selected. Use the following Static IP address: select this feature if your ISP provides you an IP address. WAN IP Address: the IP address provided by your ISP for accessing Internet.
  • Page 41 ADSL2/2+ Router Page 1 Page 2 We recommend you to keep the default settings unchanged and click the “Next” button (on page 2) to enter the screen (page 3) below: - 41 -...
  • Page 42 ADSL2/2+ Router Page 3 This page allows you to configure the gateway address for WAN connection. We recommend you to keep the default values and click the “Next” button (on page 3) to enter the following page (page 4): Page 4 This page allows you to configure the DNS server’s IP address for the WAN port.
  • Page 43 ADSL2/2+ Router following page (page 5): Page 5 This page displays the configuration information. After confirmation, please click “Apply/Save” to save it. You can access Internet once the configured connection succeeds. Bridging If you want to use your PC or other devices to execute dialup or you do not want to share your broadband service with other users, you can first configure your router’s WAN service type as bridging and then use your PC or other devices for dialup connection.
  • Page 44 ADSL2/2+ Router Modify the service description if necessary and then click “Next”. This page displays the configuration information. After confirmation, please click “Apply/Save” to save it. - 44 -...
  • Page 45 ADSL2/2+ Router After successful configurations, use your PC or other devices to dialup and then you can access Internet. Note: When you need to configure several WAN connections (multiple PVCs), first configure the needed number of ATM interfaces and then follow the above corresponding configuration procedures.
  • Page 46 ADSL2/2+ Router Click “Connection Setting” to enter WAN service setup interface Click the “Add” button. Modify the Service description if necessary and click “next”. - 46 -...
  • Page 47 ADSL2/2+ Router PPP User Name: User name for PPPoA dialup. It is provided by your ISP. PPP Password: The password provided by your ISP for PPPoA dialup. Authentication Method: It is used by ISP to verify its clients during PPPoA dialup. Select “Auto” if you are not sure about it. Clone MAC：...
  • Page 48 ADSL2/2+ Router This page allows you to configure the gateway address for WAN connection. We recommend you to keep the default values and click the “Next” button to enter the following page: This page allows you to configure the DNS server’s IP address for the WAN port.
  • Page 49 ADSL2/2+ Router You can access Internet once PPPoA dialup succeeds. IPOA First, click “Advanced Setup”—“Connection Mode” (select DSL Mode and click “Apply”)----“WAN Service”---“ATM Interface” to enter ATM PVC Configuration interface; Then select PPPoA and click “Apply/Save” there as shown in the figure below: Click “Connection Setting”...
  • Page 50 ADSL2/2+ Router Click the “Add” button Modify the service description if necessary and then click the “Next” button: WAN IP Address: the IP address provided by your ISP for accessing Internet. WAN Subnet Mask: the subnet mask address provided by your - 50 -...
  • Page 51 ADSL2/2+ Router ISP for accessing Internet.· Enter the IP/ subnet mask provided by your ISP and click the “Next” button: We recommend you to keep the default settings unchanged and click the “Next” button: This page allows you to configure the gateway address for WAN connection.
  • Page 52 ADSL2/2+ Router This page allows you to configure the DNS server’s IP address for the WAN port. Enter the DNS server IP address provided by your ISP and click the “Next” button: This page displays the configuration information. After confirmation, please click “Apply/Save”...
  • Page 53 ADSL2/2+ Router You can access Internet once the configured connection succeeds. 2. WAN Configuration in Ethernet Mode In Ethernet mode, system supports PPP over Ethernet (PPPoE) and IP over Ethernet (IPoE). PPP over Ethernet (PPPoE) Click “Advanced Setup”—“WAN Service” –“Connection Setting” to enter WAN service setup interface (page 1) and then click the “Add”...
  • Page 54 ADSL2/2+ Router Page 2 Select PPP over Ethernet (PPPoE) on page 2, modify the service description if necessary and then click “Next” to enter page 3: Page 3 PPP User Name: User name for PPPoE dialup. It is provided by your ISP.
  • Page 55 ADSL2/2+ Router PPP Password: The password provided by your ISP for PPPoE dialup. PPPoE Service Name: It is provided by your ISP. Do not fill it in if you don’t have it; otherwise PPPoE dialup may fail Authentication Method: It is used by ISP to verify its clients during PPPoE dialup.
  • Page 56 ADSL2/2+ Router and then click the “Next” button to display the following screen: This page allows you to configure the gateway address for the WAN connection. We recommend you to keep the default values and click the “Next” button to enter the following page: This page allows you to configure the DNS server’s IP address for the WAN port.
  • Page 57 ADSL2/2+ Router This page displays the configuration information. After confirmation, please click “Apply/Save” to save it. You can access Internet once PPPoE dialup succeeds. IP over Ethernet When your ISP provides you an IP address or tells you that you only need to configure your PC to obtain an IP address automatically to access Internet, you need to select IP over Ethernet （IPoE）as the WAN service type.
  • Page 58 ADSL2/2+ Router Modify the service description if necessary and then click the “Next” button: Obtain an IP address automatically: WAN port will automatically obtain an IP address for accessing Internet from the ISP, if this feature is selected. Use the following Static IP address: select this feature if your ISP provides you an IP address.
  • Page 59 ADSL2/2+ Router WAN Subnet Mask: the subnet mask address provided by your ISP for accessing Internet. WAN gateway IP Address: the gateway IP address provided by your ISP for accessing Internet. Enter the IP/ subnet mask/gateway IP address provided by your ISP or select “Obtain an IP address automatically”...
  • Page 60 ADSL2/2+ Router This page allows you to configure the gateway address for WAN connection. We recommend you to keep the default values and click the “Next” button: This page allows you to configure the DNS server’s IP address for the WAN port.

  • Page 61: Lan

    ADSL2/2+ Router clear about it and click the “Next” button: This page displays the configuration information. After confirmation, please click “Apply/Save” to save it. You can access Internet once the configured connection succeeds. 4.2.3 LAN You can change the IP address of the LAN port to match the requirement of the practical network environment.

  • Page 62: Dhcp Setting

    ADSL2/2+ Router IP Address: It is the Router’s LAN IP address. The default IP address is 192.168.1.1. Subnet Mask: It is the Router’s LAN subnet mask. You can modify it according to your needs. Enable IGMP Snooping: Check/uncheck to enable/disable the IGMP Snooping.
  • Page 63 ADSL2/2+ Router manually configuring IP address and other network parameters for multiple computers in LAN. Enable/ Disable DHCP Server: Click the corresponding button to enable/ disable the DHCP Server. Start IP: The point from which DHCP server starts IP address distribution.

  • Page 64: Nat

    ADSL2/2+ Router Hostname: The name of a PC or a network device that has successfully obtained an IP address from the DHCP server. MAC Address: The MAC address of a PC or a network device that has successfully obtained an IP address from the DHCP server.
  • Page 65 ADSL2/2+ Router To enter virtual server interface, click “NAT”-> “Virtual Server”. And then click the “Add” button to add rules for accessing the server. Use Interface: It indicates which WAN connection the configured rules are to be applied to. When there is only one configured WAN connection available, system will select it automatically.
  • Page 66 ADSL2/2+ Router drop-down list box. (2) Custom Service: allows you to define a service yourself. Server IP Address: The IP address of the server created on LAN side. External Port Start/ External Port End: The port range through which Internet users access the router’s LAN side server. Protocol: There are 3 options: TCP, UDP and TCP/UDP.
  • Page 67 ADSL2/2+ Router 2. Configuring Web server The screen appears as below after the above configuration is finished: Supposing that the IP address of PPP0 is 183.37.227.201, then the Internet user only needs to enter ftp ： //183.37.227.201 or http ： //183.37.227.201 in Web browser address field to access your FTP or Web server respectively.

  • Page 68: Port Triggering

    ADSL2/2+ Router 4.2.6 Port Triggering Some application programs or network business (such as network game, video conference, etc) can not work with simple NAT router due to the isolation caused by router’s built-in firewall. Therefore, proper configuration is needed. When application program initiates a connection toward the triggering port, all correspondingly open ports will be enabled to implement successful connection and service.
  • Page 69 ADSL2/2+ Router Use Interface: It indicates which WAN connection the configured rules are to be applied to. When there is only one configured WAN connection available, system will select it automatically. Application Name: There are two options available: (1) Select an application: allows you to select an existing application from the drop-down list box.
  • Page 70 ADSL2/2+ Router initiated by application programs succeed. For example, you have created a server on router’s LAN side that can automatically download material from Internet (via port: 9090) and share its data with other users. And you want Internet users to download data from your server (via port: 9999).

  • Page 71: Dmz Host

    ADSL2/2+ Router 4.2.7 DMZ Host Once a PC on a LAN is set as a DMZ host, it can implement network communication with Internet without limit. DMZ Host IP Address: the IP address of a PC to be set as a DMZ host.

  • Page 72: Security

    ADSL2/2+ Router Supposing that the router’s WAN IP address is 183.37.227.201, then the Internet user only needs to enter http：//183.37.227.201 in Web browser address field to access your Web server. 4.2.8 Security IP Filter IP filter function can block LAN PCs from communicating with Internet PCs by preventing specific IP addresses from accessing external network through router via specific a port number or range.
  • Page 73 ADSL2/2+ Router below to add filtering rules. Filter Name: Enter the defined filtering name. IP Version: Only Ipv4 is provided. Protocol: TCP/UDP; TCP; UDP; ICMP available for your option. Source IP address [/prefix length]: Enter the LAN IP address to be filtered.
  • Page 74 ADSL2/2+ Router the filtering function can also be implemented. For example: If you want to filter the PC at the IP address of 192.168.1.200 and make it unable to access Internet. Then follow the instructions below: First, click “Advanced Setup” → “Security” → “IP Filtering” to enter the IP filtering setup page and then click the “Add”...
  • Page 75 ADSL2/2+ Router download will be aborted. The ports that BT “seed” server frequently uses are in the range of 6900-8100 such as 6969， 8000 and 7373. Therefore, we can block this port range by creating proper rules to stop BT software from connecting the server.

  • Page 76: Time Restriction

    ADSL2/2+ Router and then click the “Add” there to enter the page below to configure needed parameters: URL Address: Enter the domain name that rejects LAN PCs access. Port Number: It indicates the port used by Web server, 80 by default. Then click the “Apply/Save”...
  • Page 77 ADSL2/2+ Router For example: If you want the PC at the MAC address of aa:bb:cc:dd:ee:ff to access Internet on Saturday and Sunday only, then follow the instructions below: Click “Advanced Setup” “Security” “Time Restriction” to enter the screen above and then click the “Add” button there to enter the screen below to configure needed parameters: User Name: Enter the defined user name by you.

  • Page 78: Quality Of Service

    ADSL2/2+ Router automatically added by system. Other MAC Address: The MAC address whose Internet access time you want to restrict. Enter it manually. Start Blocking Time (hh:mm) / Blocking Time (hh:mm): The time range during which Internet access is blocked. After configuration is finished, click the “Apply/Save”...
  • Page 79 ADSL2/2+ Router Queue Configuration Click “Advanced Setup”-> “Quality of Service”-> “Queue config” to display the configured QoS rule. Click “Add” to enter the following screen to add rules. Name: The name of the configured rule. Enable: Enable/Disable the rule. - 79 -...

  • Page 80: Routing

    ADSL2/2+ Router Interface: The interface that needs to configure priority. Precedence: Set a priority for the selected interface. Click “Save/Apply” to save the settings. 4.2.11 Routing Default Gateway Gateway is the path for sending packets when your computer is communicating with computers on other networks. When there are multiple WAN connections, the gateway must be specified, otherwise, your computer may not be able to communicate with computers on other networks.
  • Page 81 ADSL2/2+ Router Select the WAN connection that you want to set as the gateway and click “Apply/Save” to save the settings. The settings will be effective after the system reboot. Static Route Static Route is a special route. When you use proper static routing in networks, you can reduce routing selection problems and the forwarding rate of the data packets.
  • Page 82 ADSL2/2+ Router Click “Apply/Save” to display the current configured static route information. IP version: It is used to indicate that the IP belongs to IPv4. Destination IP address/prefix length: to identify the destination IP address or network that the data is sending to. Prefix length together with the destination IP address are used to identify the destination network.

  • Page 83: Dns

    ADSL2/2+ Router packets are sending to. Metric: the number of the routers that the data packets go through (optional). Apply /Save：Complete the settings. Note: Destination IP address cannot be at the same net segment with the IP addresses of the router’s WAN or LAN port. We recommend using the default settings if there is no special requirement, for inappropriate or incorrect route setting would cause network malfunction.
  • Page 84 ADSL2/2+ Router Note: After saving the settings, you need to reboot the router to bring the new configuration into effect. Please keep the default settings if there is no special requirement for incorrect DNS settings will cause the LAN computer to be unable to access the Internet via the domain name.

  • Page 85: Dsl

    ADSL2/2+ Router Dynamic DNS Provider: Select your DDNS provider. Hostname: The domain name registered at the corresponding DDNS website. Interface: WAN connection interface Username: Enter the username that you use to register from the DDNS provider Password: Enter the password that you use to register from the DDNS provider Click “Apply/Save”...

  • Page 86: Upnp

    ADSL2/2+ Router Click the checkbox to enable corresponding modulation modes, and then click “Apply/Save” to complete the settings. Note: If you are not familiar with the ADSL modulation modes, please use the default settings. 4.2.14 UPnP With UPnP (Universal Plug and Play) function, the host in LAN can request the Router to carry specific port forwarding, thus the external host can access the internal host for resources.

  • Page 87: Interface Grouping

    ADSL2/2+ Router Select “Enable UPnP” and then click “Apply/Save” to save the settings. Note: 1. Because the security of current UPnP version has not been guaranteed, please close it when you do not need it. 2. Only the application programs that support UPnP protocol can use this function.
  • Page 88 ADSL2/2+ Router Group Name：The name of the configuration rule. WAN Interface used in the grouping: WAN connection that needs to be grouped. Available LAN Interfaces: Interfaces that can be grouped. Grouped LAN Interfaces: LAN interface that needs to connect with specified WAN interface Example: Your ADSL line supports two groups of PVC;...
  • Page 89 ADSL2/2+ Router Click “Save/Apply” to save the settings. Note: After completing the settings, reboot the router to bring the router settings into effect. After setting the interface grouping, the gateway IP address the default - 89 -...

  • Page 90: Multicast

    ADSL2/2+ Router grouping uses is 192.168.1.1, and then the second grouping uses 192.168.2.1 as the gateway IP address, and the others follow by analogy. 4.2.16 Multicast IGMP Configuration Click “Advanced Setup”-> “Multicast” to enter the IGMP Configuration screen. You can configure IGMP parameters on this screen, if you are not clear about the IGMP, we recommend using the default configuration.

  • Page 91: Basic Setting

    ADSL2/2+ Router Bridge” and “Station Info”. 4.3.1 Basic Setting Enable Wireless: check/uncheck to enable/disable the wireless function. Wireless Mode: b/g/n Mixed Mode: By default, system is in this mode. Therefore, your network adapter can connect to the router’s wireless network no matter which standard it complies with: 802.11b, 802.11g or 802.11n.
  • Page 92 ADSL2/2+ Router devices that adopts 2T2R can reach up to 300Mbps ). b/g Mixed Mode: If this mode is selected, then wireless adapters in use must support 802.11b or 802.11g mode. g Mode：If this mode is selected, then wireless adapters in use must support 802.11g mode.
  • Page 93 ADSL2/2+ Router Step1: Click icon on bottom right corner as shown in the above figure to display “Currently connected to”. Step2: Click “Open Network and Sharing Center” to enter the configuration interface below. - 93 -...
  • Page 94 ADSL2/2+ Router Step3: Click “Manage Wireless Network” to enter the page below: Step4: Click the “Add” button on the page above to enter “Manually connect to a wireless network” and select “Manually create a network profile” on the page below: - 94 -...
  • Page 95 ADSL2/2+ Router Step5: Enter the required wireless network information on the page below, and then click “Next”. Network name: It is the name of the wireless network to add (SSID). Security type: It is authentication method of the wireless network. Security key: It is the security key of the wireless network.
  • Page 96 ADSL2/2+ Router Step6: Click the “Close” button and you have finished the operations manually adding wireless network. - 96 -...
  • Page 97 ADSL2/2+ Router Step7: Now, you can go to check the added wireless network on the page below by clicking “Manage wireless network”. BSSID：BSS is a special Ad-hoc LAN application. A wireless network consists of, at least, an AP that is connected to wired network and several wireless workstations, which is called BSS (Basic Service Set).
  • Page 98 ADSL2/2+ Router certain channel. If two transmission signals are using the same channel, then mutual interference will be caused to decrease communication efficiency. There are 13 channels (1 to 13) for your option. Thus, to avoid interferences, you are recommended to choose the channel that is different from that of another SSID.

  • Page 99: Security Setting

    ADSL2/2+ Router 4.3.2 Security Setting WPS Setup: Wi-Fi protected setting (WPS) can create encrypted connection between wireless network clients and the router simply and quickly. Without selecting an encryption mode and configuring a key, you only need to enter the correct PIN code or select the “Push Button”...

  • Page 100: Mac Filter

    ADSL2/2+ Router PIN: To use PIN, you must know wireless client’s PIN code and input it in its text box, then save this configuration. Meanwhile, use the same PIN code in the client for connection. Enable WPS: check/uncheck to enable/disable the WPS function. It is enabled by default.
  • Page 101 ADSL2/2+ Router Disabled: Select it to disable MAC filter function. Allow: only allows clients in the MAC address list to access your wireless network. Deny: only prohibits clients in the MAC address list from accessing your wireless network. Add: to add a MAC address, click the “Add” button. To delete an added MAC address, first check the “Remove”...
  • Page 102 ADSL2/2+ Router Then click the “Apply/Save” button on the above screen to save the parameter. Select “Allow” on the page below: Example 2: If you want to prohibit the PC with MAC address of 00:c2:a5:67:d4:23 only from accessing your wireless network, then follow the instructions below: Enter the Wireless--MAC filter page and click the “Add”...

  • Page 103: Wireless Bridge

    ADSL2/2+ Router Then click the “Apply/Save” button on the above screen to save the parameter. Select “Deny” on the page below: 4.3.4 Wireless Bridge Wireless Distribution System is used to extend the existing wireless signal coverage. Wireless bridge includes 2 modes: 1.
  • Page 104 In the above figure, two W300Ds are used to enlarge wireless signal coverage. W300D-2 is configured as a wireless access point to establish a wireless bridge with W300D-1. In the meantime, the AP function reserved in W300D-2 enables PC3 and PC4 to communicate with W300D-2 and access Internet through wireless network adapters.
  • Page 105 ADSL2/2+ Router In the above figure, two W300Ds are used to enlarge wireless signal coverage. W300D-2 is configured as a wireless bridge to establish a wireless bridge with W300D-1. W300D-2, here, does not have the AP function, thus, PC3 and PC4 can communicate with W300D-2 and access Internet only through wired network adapters instead of wireless ones.

  • Page 106: Station Info

    ADSL2/2+ Router You only need to check the wireless network that you want to bridge with and click the “Apply/Save” button. And system will automatically establish wireless bridge with the remote device for you. Disabled: To disable wireless bridge function, select this option. Note: To use the wireless bridge function, both devices must support the function.
  • Page 107 ADSL2/2+ Router the router’s interfaces. When a connection is successfully established, its status displays a “PASS”, otherwise it displays a “FAIL” click ". To enter the page below, click the “Diagnostics” tab on the left navigation menu column: If you are not clear about the test result, please click “Help” for more details.

  • Page 108: Management

    4.5.1 System log System log records the running status of W300D, such as ADSL dial-up procedure and data packets records and so on. To view the log, please follow the steps below.

  • Page 109: 2Tr-069 Client

    4.5.2TR-069 client TR-069 client is used to implement remote centralized management over the W300D from the Internet (Note: to use this function, there must be a remote centralized manager), the configuration steps are as follows: 1. Click “TR-069 client” to enter the “TR-069 client – Configuration”...
  • Page 110 ADSL2/2+ Router screen. 2. Click “Enable” to open the function. The default is disabled. 3. Enter the Inform Interval, which is 300, ACS URL (the domain name - 110 -...
  • Page 111 ADSL2/2+ Router of the Auto-Configure Server), ACS User name, ACS Password and WAN Interface used by TR-069 client as the picture below. 4. Disable “Display SOAP messages on serial console”, and uncheck “Connection Request Authentication”, then click” Apply/Save”. - 111 -...

  • Page 112: Internet Time

    ADSL2/2+ Router 4.5.3 Internet Time Internet time synchronization is used to update the router’s system time so that the router’s system time accords with the Internet time. The default setting selects “Automatically synchronize with Internet time servers”, as shown in the picture below. Note: NTP time server is used to update the time.
  • Page 113 ADSL2/2+ Router 2. Enter the router’s current login password in the old password textbox. 3. Enter the password you wish to set in the new password and confirm password textboxes. - 113 -...
  • Page 114 ADSL2/2+ Router 4. After clicking Apply/Save, the login dialog will pop up. 5. Enter the new password you have set to re-enter the router’s setup wizard screen. - 114 -...

  • Page 115: Backup

    ADSL2/2+ Router 4.5.5 Backup With backup settings, you can back up your router’s configuration. The steps are as follows: 1. Click “Backup” to enter the “Settings—Backup” screen. 2. Click the “Backup settings” button, and click “Save” on the appearing “File Download” dialog to export the router’s configuration file. 4.5.6 Update This function enables you to import the previous backup file with ease.
  • Page 116 ADSL2/2+ Router screen. 2. Click “Browse” to select the file you want to import. 3. Click “Update settings” to import the configuration and the device will reboot. - 116 -...

  • Page 117: Restore Default

    ADSL2/2+ Router 4.5.7 Restore default If you have made some illegal operation on the device, you will be unable to access the Internet. This feature enables you to restore the device to factory default settings. Click “Restore Default” to display the “Tools -- Restore Default Settings”...

  • Page 118: Update Software

    ADSL2/2+ Router 4.5.8 Update Software Update Software enables you to upgrade the device to improve its system stability. The upgrade steps are as follows: 1. Click “Update Software” to display the “Tools -- Update Software” screen. 2. Click the “Browse” button to select the upgrade file and then click “Update Software”.

  • Page 119: Reboot

    ADSL2/2+ Router 3. After clicking the “Update Software”, it comes to the upgrade screen. The progress takes about 2 minutes. 4.5.9 Reboot To reboot the router, click “Management”----“Reboot” to enter the page below, and then click the “Reboot” button there. - 119 -...

  • Page 120: Exit

    ADSL2/2+ Router 4.6 Exit Select the Exit menu and click Ok on the appearing dialog to log out from the router’s web-based utility. 4.7 Back to Wizard Click Back to Wizard menu, you will come back to the router’s setup wizard screen as shown in the screen below: - 120 -...

  • Page 121: Setting The Ip Of Your Pc Manually

    ADSL2/2+ Router Appendix 1 1. Setting the IP of your PC manually Choose “Use the following IP address”, and enter the IP address: 192.168.1.xxx. (xxx ranges 2~254), Subnet mask : 255.255.255.0, Gateway: 192.168.1.1, DNS Server: can enter your local DNS server address (consult your local ISP) or set the Router as DNS proxy server.

  • Page 122: Pc Dial-Up

    ADSL2/2+ Router 2. PC dial-up When working in bridging mode, W300D connects with internet via dial-up software (the third party software). With multiple built-in VPI/VCI, there is no need for any configuration and only an installed dial-up program will enable access to internet. Different ISP may use different dial-up software.
  • Page 123 ADSL2/2+ Router Enter “Network and Sharing Center” and select “Set up a new connection or network” as below: Choose “Connect to the Internet” and click “Next” on the page below: - 123 -...
  • Page 124 ADSL2/2+ Router Select “Dialup” on the appearing page below: Enter User name and password provided by your ISP on the page below: - 124 -...
  • Page 125 ADSL2/2+ Router And then click “Connect”. If you get the screen below in a while, then you can access Internet. - 125 -...

  • Page 126: Troubleshooting

    ADSL2/2+ Router Appendix 2 1. Troubleshooting Trouble Case Troubleshooting Power ● Check if the power adapter is connected properly. ● Check if the power adapter is matched. ● Check if the ADSL cable connection is OK. ADSL LINK ● Make sure the telephone line is OK with your phone.

  • Page 127: Verifying The Connection

    ADSL2/2+ Router 2. Verifying the Connection First, click the start menu on the left bottom corner of your computer desktop. Then, input “cmd” in the search programs and file texts box and press “enter’. Finally, Open the dos window and enter “ping 192.168.1.1”, and press Enter.
  • Page 128 ADSL2/2+ Router Now the direct link between your computer and the router has been successfully established, which means you can log on to the router’s web-based utility. If the screen shows as below, it indicates the connection hasn’t been established. Then please check the previous settings, the power of the Router, and the cables between the Router and the computer.

  • Page 129: Faq

    Q: How do I judge whether ADSL connection is OK? A: After the hardware is connected correctly, when the connection is OK, the “ADSL-LINK” indicator of W300D will be always on; otherwise, it will be flashing. Flashing indicates the connection is troubled or wrong.
  • Page 130 A: Contact the technical engineer for support or after-sales service engineer. Note: Please download the upgrade packets from the Tenda website. Q: How do I restore my device to factory default value? A: There is a reset button on the Router. Follow the steps below to restore the device: 1) Keep the device in running status.
  • Page 131 ADSL2/2+ Router A: 1) The walls in the house are main obstacles. Because wireless LAN adopts wireless microwave frequency range, the signals received by wireless receiving devices behind the obstacles will be rather weak. 2) Physical obstacles not only hold up the wireless signals but also absorb the electromagnetic power.

  • Page 132: Vpi/Vci List

    ADSL2/2+ Router 2) Modify channels to reduce wireless disturbance. Note: When you set your wireless transmitting channel, keep above 5 channels far away from other wireless signal channels. 3) Keep the wireless Router far away from household appliances to reduce the disturbance of the signals. 4) If the antenna of wireless Router is detachable, you can change it for a higher gain one to enhance wireless signals.
  • Page 133 ADSL2/2+ Router Columbia - ETB PPPoE LLC Costa Rica - ICE 1483 Routed IP LLC Denmark-Cybercity, Tiscali PPPoA VC-MUX France (1) PPPoE LLC France (2) PPPoE LLC France (3) PPPoA VC-MUX Germany PPPoE LLC Hungary - Sci-Network PPPoE LLC Iceland - Islandssimi PPPoA VC-MUX Iceland - Siminn PPPoA VC-MUX...
  • Page 134 ADSL2/2+ Router Saudi Arabia (2) PPPoE LLC 1483 Bridged Saudi Arabia (3) Saudi Arabia (4) 1483 Routed IP LLC 1483 Bridged Saudi Arabia (5) Saudi Arabia (6) 1483 Routed IP LLC Spain - Albura, Tiscali PPPoA VC-MUX Spain - Colt Telecom, Ola PPPoA VC-MUX Internet Spain - EresMas, Retevision...
  • Page 135 ADSL2/2+ Router 1483 Bridged United States - August.net (1) 1483 Bridged United States - August.net (2) United States - BellSouth PPPoE LLC United States - CenturyTel (1) PPPoE LLC 1483 Bridged United States - CenturyTel (2) United States - Coqui.net PPPoA LLC United States - Covad PPPoE LLC...
  • Page 136 ADSL2/2+ Router United States – South Western 1483 Bridged Bell United States - Sprint (1) PPPoALLC United States - Sprint (2) PPPoE LLC United States SureWest 1483 Bridged LLC Communications(1) Snap United States SureWest PPPoE LLC Communications(2) United States SureWest PPPoA LLC Communications(3) United States - Toast.Net...

  • Page 137: Appendix 3: Regulatory Information

    ADSL2/2+ Router Appendix 3: Regulatory Information Eu Declaration or Declaration of Conformity Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD declares that this device complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
  • Page 138 ADSL2/2+ Router To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices).

  • Page 139: Appendix 4 Contact Information

    Visit us online for information on the latest products and updates to your existing products at: http://www.tenda.cn If you experience problems with any Tenda product, you can call us at: TEL: (86)0755-27657180 27653089 Don’t wish to call? You can e-mail us at: Email: support@tenda.com.cn...

This manual is also suitable for:

W150d

Table of Contents
