MAM01V
4G READY WIDEBAND MASTHEAD
AMPLIFIER
SPECIFICATION:
Power:
Frequency range:
Gain:
Noise:
Impedance:
Max output level:
Dimensions & weight:
INTRODUCTION:
Thank you for choosing this Mercury masthead amplifier. It is designed to amplify weak FM/DAB/TV
signals. Supplied in an IP44 rated casing for outdoor installation.
-
F-type connectors for secure connections.
-
Integrated LTE signal filter avoids interference and channel loss from 4G mobile signals
-
Fully shielded design for minimum signal interference.
-
Maximum output limiter prevents overloading the receiver unit.
-
Variable gain control allows fine adjustment of the signal level.
-
Wideband frequency response, compatible with FM, DAB, analogue and digital TV reception
(DVB-T, ISDB-T, DMB-T, ATSC)
12Vdc, 50mA
27 – 790MHz
15-30dB
<4.5dB
75Ω
100dBuV
110 x 105 x 52mm, 180g
Item ref: 130.039UK
User Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mercury MAM01V
Summary of Contents for Mercury MAM01V
-
Page 1: User Manual
Dimensions & weight: 110 x 105 x 52mm, 180g INTRODUCTION: Thank you for choosing this Mercury masthead amplifier. It is designed to amplify weak FM/DAB/TV signals. Supplied in an IP44 rated casing for outdoor installation. F-type connectors for secure connections. - Page 2 INSTALLATION: Before installing, to avoid danger of electric shock, please ensure that all equipment is turned off and disconnected from the mains supply. This amplifier requires 12Vdc power to operate, the output of the amplifier needs to be connected to masthead amplifier power supply (130.060UK or 130.061UK) or to a TV receiver that has 12Vdc power supply on its input.
