AMS SERIES
Item ref: 130.034UK, 130.035UK
AERIAL DISTRIBUTION

User Manual

AMPLIFIERS WITH DC PASS
CAUTION
Please read through this manual carefully before use. This product is strictly for indoor
use only, please install this product in dry and cool environment and keep out of the
reach of children and pets.
INTRODUCTION:
Thank you for choosing this Mercury AMS series distribution amplifier. It is designed to amplify weak
FM/DAB/TV signals from the aerial and distribute them to multiple outputs, ideal for use with passive
indoor aerials or to distribute the analogue RF2 signal from a satellite receiver.
