  • Page 1 LIFEBOOK EasyGuide E Series English...
  • Page 2 Are there ..any technical problems or other questions which you would like to be clarified? Please contact: • your sales partner • your sales outlet Further information can be found in the "Safety" and "Warranty" manuals. The latest information on our products, tips, updates, etc., can be found on the internet under: http://www.fujitsu-siemens.com...
  • Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH A26391-K121-Z120-1-7619 Bestell-Nr./Order No.: Printed in the Federal Republic of Germany AG 1202...

  • Page 5: Lifebook E Series

    Introduction Index Important notes E Series Preparing the notebook LIFEBOOK for use Working with the notebook Security functions Operating manual Connecting external devices Settings in BIOS Setup Troubleshooting and tips Memory expansion Technical data December 2002 edition...
  • Page 6 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright  Fujitsu Siemens Computers GmbH 2002 All rights, including rights of translation, reproduction by printing, copying or similar methods, in part or in whole, are reserved.

  • Page 7: Table Of Contents

    Contents Introduction .............................1 Notational conventions ........................2 Important notes ..........................3 Safety ..............................3 Additional safety precautions for devices with wireless LAN/BLUETOOTH........5 Notes on installing and removing boards and modules ..............6 Manufacturer’s notes .........................7 Copyright-protected technology ....................7 Energy saving..........................7 Disposal and recycling.......................8 CE marking............................8 Radio frequencies for devices with wireless LAN / BLUETOOTH ............9 Storing the battery ...........................10 Transporting the notebook .......................10...
  • Page 8 Contents Optical drive ............................ 34 Installing and removing optical drive..................34 Handling CD/DVDs........................36 Manual removal (emergency removal) ..................38 Integrated 56k modem ........................39 Connecting notebook modem to telephone connection ............39 Wireless LAN/ BLUETOOTH......................40 Wireless network as per IEEE 802.11 standard ..............40 Operating system requirements ....................
  • Page 9 Contents Troubleshooting and tips......................69 You have forgotten your user and/or supervisor password............69 Installing new software ......................69 Restoring the hard disk contents under Windows ..............69 The notebook's date or time is incorrect ..................70 The LCD screen of the notebook remains blank ..............70 The LCD display panel is difficult to read .................70 The external monitor stays blank .....................70 The external monitor is blank or the image is unstable ............71...

  • Page 11: Introduction

    Introduction Your is a versatile and ergonomic notebook. Innovative technology and an ergonomic LIFEBOOK design make your notebook a reliable, convenient mobile PC. To make it easier to use the notebook for the first time, the operating system has been preinstalled on the hard disk.

  • Page 12: Notational Conventions

    Introduction Notational conventions The following symbols are used in this manual: Indicates information which is important for your health or for preventing physical damage. Failure to follow the instructions may lead to loss of data, invalidate your warranty, destroy the notebook, or endanger your life. Indicates important information which is required to use the system properly.

  • Page 13: Important Notes

    Important notes Here you will find essential safety information regarding your notebook. In addition, the manufacturer's notes contain helpful information about your notebook. Safety Pay attention to the information provided in the "Safety" and "Warranty" manuals and in the following security notes. Observe the sections in the manual marked with the symbol on the left.
  • Page 14 Important notes • All batteries containing pollutants are marked with one of the two symbols below (crossed-out garbage can). In addition, the marking is provided with the chemical symbol of the heavy metal decisive for the classification as a pollutant. Cadmium Mercury Lead...

  • Page 15: Additional Safety Precautions For Devices With Wireless Lan/Bluetooth

    With data traffic via a wireless connection, it is also possible for unauthorised third parties to receive data. The company Fujitsu Siemens Computers GmbH cannot be held responsible for radio or television faults arising from unauthorised changes made to this device. Fujitsu Siemens is, furthermore, not responsible for replacing and / or exchanging connector cables and devices which have not been specified by Fujitsu Siemens Computers GmbH.

  • Page 16: Notes On Installing And Removing Boards And Modules

    Important notes Notes on installing and removing boards and modules Only qualified technicians should repair the device. Unauthorised opening or incorrect repair may greatly endanger the user (electric shock, fire risk). Boards with electrostatic sensitive devices (ESD) are identifiable by the label shown. When you handle boards fitted with ESDs, you must, under all circumstances, observe the following points: •...

  • Page 17: Manufacturer's Notes

    20 million tons of carbon dioxide into the atmosphere - the equivalent of 5 million automobiles. As an Energy Star Partner, Fujitsu Siemens Computers GmbH has determined that this product meets the Energy Star guidelines for energy efficiency.

  • Page 18: Disposal And Recycling

    Any components not reclaimed will be disposed of in an environmentally acceptable manner. Do not throw batteries or accumulators into the household waste. If you have any questions on disposal, please contact your local office, our hotline/help desk, or: Fujitsu Siemens Computers GmbH Recyclingcenter D-33106 Paderborn...

  • Page 19: Radio Frequencies For Devices With Wireless Lan / Bluetooth

    Important notes Radio frequencies for devices with wireless LAN / BLUETOOTH The following information represents the status of January 2002. Current information is available from the corresponding government office of your country (e.g. www.regtp.de). Frequencies Wireless network cards and adapters are intended for operation in the ISM (Industrial, Scientific, Medical) frequency range between 2.4 and 2.4835 GHz in accordance with the IEEE standard 802.11b.

  • Page 20: Storing The Battery

    Important notes Storing the battery If you do not use the batteries for long periods, remove them from the notebook. Never store the batteries in the unit. Store the battery in a fully charged state. The battery should be stored in a dry area at a temperature between 0°C and +30°C.

  • Page 21: Transporting The Notebook

    To protect against damaging jolts and bumps, use a notebook carrying case to transport your notebook. Fujitsu Siemens Computers offers a number of solutions for transporting your notebook. The current offering can be viewed on the Internet at http://www.e-shop2.de. •...

  • Page 23: Preparing The Notebook For Use

    Preparing the notebook for use Please take note of the information in the "Important notes" chapter. Before you can work with your notebook, you need to charge the battery and install and configure the delivered software. The operating system and drivers required are preinstalled. Upon delivery, the battery can be found in the battery compartment and is not charged.

  • Page 24: Connecting The Power Adapter

    Preparing the notebook for use Connecting the power adapter Please take note of the information in the section "Selecting a location". The power cable supplied conforms to the requirements of the country in which you purchased your notebook. Make sure that the power cable is approved for use in the country in which you intend to use it.
  • Page 25 Preparing the notebook for use Ê Slide the release button in direction of the arrow (1) and open the LCD screen (2). Ê Press the Suspend/Resume button to switch on the notebook (3). The power-on indicator on the notebook lights up. After switch-on a self-test (POST, Power On Self Test) is automatically carried out.

  • Page 27: Working With The Notebook

    Working with the notebook This chapter describes the basics for operating your notebook. Please see the "Connecting external devices" chapter for instructions on how to connect devices such as a mouse and a printer to the notebook. Please take note of the information in the "Important notes" chapter. Switching on the notebook Ê...

  • Page 28: Switching The Notebook Off

    Working with the notebook Switching the notebook off Ê Close all programmes and shut down your operating system (please see operating system manual). Ê If the notebook does not switch off automatically, press the Suspend/Resume button for approx. 3-4 seconds (1). Ê...

  • Page 29: Ports, Indicators And Operating Elements

    Working with the notebook Ports, indicators and operating elements Interior view 1 = Touchpad 4 = Security panel 2 = Closed cover switch 5 = Suspend/Resume button 3 = Display field A26391-K121-Z120-2-7619...

  • Page 30: Front

    Working with the notebook Front 1 = Built-in loudspeakers 3 = Connector for headphones / SPDIF 2 = Port for external microphone 4 = IEEE1394 FireWire connection Left side panel 1 = PC card slots 3 = Modem port 2 = Kensington Lock device 4 = Wireless LAN/ BLUETOOTH button A26391-K121-Z120-2-7619...

  • Page 31: Right Side Panel

    Working with the notebook Right side panel Optical drive: 1 = Removal lever 3 = Insert/Eject button 2 = Opening for manual ejection Back panel 1 = Serial port 6 = LAN connector 2 = Parallel port 7 = Video output 3 = External monitor connector 8 = USB ports 4 = Infrared interface...

  • Page 32: Display Field

    Working with the notebook Display field The meanings of the symbols are as follows: Power-on indicator • The indicator lights up: The notebook is on. • The indicator flashes (1 second on / 1 second off): The notebook is in Standby mode / Suspend to DRAM mode. •...
  • Page 33 Working with the notebook Battery indicator The charge state of the first battery is indicated in the status indicator panel. The charge state of the second battery is indicated in the status indicator panel. Indicates that the battery is 0%-25% charged. Indicates that the battery is 25%-50% charged.

  • Page 34: Indicators For External Drives

    Working with the notebook Indicators for external drives You can use the Port Replicator to connect external drives to your notebook. When an external floppy disk drive is connected, an additional symbol appears: Floppy disk indicator The floppy disk in the external floppy disk drive is being accessed. You must not remove the floppy disk from the floppy disk drive when this indicator is shown.
  • Page 35 Working with the notebook Caps Lock key The Caps Lock key activates uppercase mode (CapsLK indicator lit). The Caps Lock function causes all the characters you type to appear in uppercase. In the case of overlay keys, the character printed on the upper left of the key appears when that key is pressed.

  • Page 36: Key Combinations

    Working with the notebook Key combinations The following description of key combinations refers to functions when using Microsoft Windows. Some of the following key combinations may not function in other operating systems and with some device drivers. Other key combinations are described in the relevant manuals supplied with your application programmes.

  • Page 37: Touchpad And Touchpad Buttons

    Working with the notebook Carrying out a warm boot Ctrl This key combination triggers a reset and warm-boots the notebook. First hold down the [Ctrl] and [Alt] key, and then press the [Del] key. Under Windows 98, Windows 2000, Windows Me and Windows NT the Task Manager appears first. Then you must press all three keys again to re-boot.

  • Page 38: Lcd Display Panel

    LCD display panel Information on LCD monitor High-quality TFT monitors are installed in notebooks from Fujitsu Siemens Computers GmbH. The specification of the monitor resolution indicates how many pixels can be displayed. For example, "XGA" stands for 1024 x 768 pixels. Each pixel consists of three so-called subpixels of the colours red, green and blue.

  • Page 39: Battery

    Working with the notebook Adjusting the speed of the mouse pointer Under Windows you can change the speed of the mouse pointer under Start - Settings - Control Panel - Mouse and clicking on the Motion tab. Battery The battery is one of the most important components of your notebook. When not plugged into a mains outlet, the notebook runs on its built-in battery.

  • Page 40: Monitoring The Battery Charging Level

    Working with the notebook Monitoring the battery charging level The remaining battery charge is indicated by the battery symbol in the status indicator panel (see the section "Display field"). When you switch on the notebook, it takes a few seconds before the battery status is displayed.

  • Page 41: Using The Power-Management Features

    Working with the notebook Installing the battery Ê Position the battery at the edge of the casing (1). Ê Push the battery into the battery slot until you feel it locking into place (2). Using the power-management features The notebook uses less power when the power management features are enabled. You will then be able to work longer when using the battery before having to recharge it.

  • Page 42: Standby Mode

    Working with the notebook Standby mode Depending on the settings in the BIOS Setup and operating system - the computer switches into a standby mode - the computer switches off when the key combination is held down for more than four seconds.

  • Page 43: Operating Systems With Acpi (Windows 2000 And Windows Xp)

    Working with the notebook Operating systems with ACPI (Windows 2000 and Windows XP) If an operating system with ACPI (Advanced Configuration and Power Management Interface) is installed on your notebook, you can set the power management fetaures via the operating system (e.g.

  • Page 44: Optical Drive

    Working with the notebook Optical drive Your notebook is delivered with an optical drive. Depending on the model, your notebook is equipped with a CR-ROM drive, a CD-RW drive, a DVD-ROM drive or a combo drive (CD- RW/DVD). This product contains an LED classified as a CLASS 1 LASER, and may therefore not be opened.
  • Page 45 Working with the notebook Ê Pull out the eject lever in the direction of the arrow. Ê Pull the eject lever (1) in the direction of the arrow up to the stop. Ê The drive is ejected from the bay. Ê...

  • Page 46: Handling Cd/Dvds

    Working with the notebook Installing optical drive Ê Insert the drive, contacts first, into the bay. Ê Push the disk drive into the bay until you feel it locking into place. Handling CD/DVDs Avoid touching the surface of a CD/DVD. Handle CDs/DVDs only by their edges! Always store CDs/DVDs in their cases.
  • Page 47 Working with the notebook Inserting or removing a CD/DVD The notebook must be switched on. Ê Push the insert/eject button (1). The drive tray will open. Ê Pull the drive tray all the way out (2). Ê Place the CD/DVD in the drive tray with the label facing upwards. Ê...

  • Page 48: Manual Removal (Emergency Removal)

    Working with the notebook Manual removal (emergency removal) In the event of a power failure or damage to the drive it may be necessary to manually remove the CD/DVD. Ê Switch the notebook off. Ê Press a pen or a piece of wire (e.g. a paperclip) firmly into the opening (1). The drive tray is unlocked.

  • Page 49: Integrated 56K Modem

    Working with the notebook Integrated 56k modem The integrated 56k modem supports data communication applications, such as: • Modem operation: High-speed downloads at up to 56,000 bit/s (V.90 / V.92). • Fax mode: Transmitting and receiving at up to 14,400 bit/s The modem has been inspected in agreement with the guideline TBR-21.

  • Page 50: Wireless Lan/ Bluetooth

    Working with the notebook Wireless LAN/ BLUETOOTH Depending on the device variant, wireless LAN/ BLUETOOTH may be integrated in your notebook. Ê Press the wireless LAN/BLUETOOTH key to establish the wireless network connection. Ê Press the wireless LAN/BLUETOOTH key to end the wireless network connection. Details are contained in the online help for your wireless LAN/BLUETOOTH software.

  • Page 51: Infrastructure Mode

    Working with the notebook Adhoc mode A wireless LAN in the adhoc mode, also called peer-to-peer mode, consists of a single closed cell. Adhoc wireless networks result when a workgroup comes together with its systems and would like to interconnect these for data exchange. Any number of systems can be added to this type of network and can leave it again.

  • Page 52: Pc Card Slots

    Working with the notebook PC card slots Two PC card slots (CardBus or PCMCIA) enable the notebook to operate two type I or type II PC cards or one type III PC card. Make sure that foreign objects do not fall into the PC card slot. Working with PC cards Consult the documentation supplied by the PC card's manufacturer and follow the instructions provided.
  • Page 53 Working with the notebook Consult the documentation supplied with the PC card for information on how to install the necessary device drivers. For further information refer to the information files (e.g. *.TXT, *.DOC, *.WRI or *.HLP) provided on the PC card driver diskette or the information in the operating system manual. You can push the PC card slot eject buttons into the notebook casing.

  • Page 54: Loudspeakers

    Working with the notebook Loudspeakers Two loudspeakers (1) are installed in your notebook. The internal loudspeakers switch off when you attach headphones or external loudspeakers to the audio jack. A26391-K121-Z120-2-7619...

  • Page 55: Security Functions

    Security functions Your notebook enables you to protect your system and personal data in a number of ways against unauthorised access. By combining these options, you can achieve maximum protection for your system. In this chapter you will learn which security functions your notebook is equipped with, which advantages these functions offer you and how to configure and use them.

  • Page 56: Bios Password Protection

    Security functions BIOS password protection You can protect you personal data from unauthorised access with various passwords. By combining these different options, you can achieve maximum protection for your system. Password protection for the BIOS setup With the Supervisor password you prevent unauthorised opening of the BIOS Setup, and with it access to important system settings.

  • Page 57: Brief Overview Of The Security Functions

    Security functions Brief overview of the security functions Security function Type of protection Preparation Kensington Lock Mechanical Mount and lock Kensington MicroSaver (accessory) Security panel Hardware password protection Install the programs provided with Supervisor and User and specify the numeric password.

  • Page 58: Using Kensington Lock

    Security functions Using Kensington Lock With the Kensington MicroSaver, a sturdy steel cable, you can protect your notebook from theft. For this reason your notebook is equipped with a device for the Kensington MicroSaver. The Kensington MicroSaver is available as an accessory. Ê...

  • Page 59: Configuring And Using Security Panel

    Security functions Configuring and using Security Panel a = Security panel Configuring Security Panel When you put your notebook into operation for the first time, the Security Panel is not activated yet. Assign the necessary passwords with the programs FJSECS.EXE (Supervisor password) and FJSECU.EXE (User password).
  • Page 60 Security functions To set the passwords, proceed in the following order: Assigning the supervisor password The setup programme can be found under Start - AddOn. Ê Double-click on the symbol to start the setup programme for FJSECS.EXE. The programme starts. Ê...

  • Page 61: Assigning The User Password

    Security functions Assigning the user password The setup programme can be found under Start - AddOn. Ê Double-click on the symbol to start the setup programme for FJSECU.EXE. The programme starts. Ê Enter the programme name FJSECU.EXE under Start - Run. Ê...
  • Page 62 Security functions Changing or removing security password After you have installed the programs FJSECS.EXE and FJSECU.EXE, you will find the entry Security control under Start - Programs. Here you can change or completely remove your user password. In this case follow the instructions of the programme. A26391-K121-Z120-2-7619...

  • Page 63: Configuring Password Protection In Bios Setup

    Security functions Configuring password protection in BIOS Setup Before using the various options of password protection for your data security in the BIOS Setup, please note the following hints: • Please keep in mind your passwords in any case, as you will not be able to access your BIOS Setup and/or your system any longer, if you forget both the user password and the supervisor password.

  • Page 64: Password Protection Of Operating System

    Security functions Change supervisor or user password Ê When changing the password, proceed exactly as for password assignment. You can only change the supervisor password when you have logged into the BIOS Setup with the supervisor password. Cancelling passwords To cancel a password (without setting a new password) run the following steps: Ê...

  • Page 65: Password Protection For Hard Disk

    Security functions Password protection for hard disk The had disk password prevents unauthorised access to the hard disk drives and is checked internally each time the system is booted. The condition for this is that you have assigned at least the supervisor password. Activating hard disk protection Ê...

  • Page 66: Configuring And Using Smartcard Reader

    Security functions Configuring and using SmartCard reader a + b = SmartCard reader a = PC card slot with SmartCard Interface b = SmartCard holder c = SmartCard Installing and removing SmartCard holder To use the SmartCard reader, you must install a SmartCard holder in your notebook. The SmartCard holder is contained in the "Mobile Secure IT Suite", which is either included with your notebook or is available as an accessory depending on the configuration.

  • Page 67: Driver Installation

    Security functions Driver installation The inserted SmartCard holder is detected by Windows as new hardware and the driver for the chip is searched for. The driver is provided on the "Security Drivers & Tools" CD, which is also included with the "Mobile Secure IT Suite". Ê...

  • Page 68: Application Examples

    Security functions Change SmartCard PIN To change your PIN you must have already booted your system (with the SmartCard and the current PIN). Ê Pull the SmartCard out of the SmartCard holder and reinsert the SmartCard when requested to do so. The window with the request for the PIN entry opens.
  • Page 69 Security functions SmartCard for creating user profiles With the Smarty software you can assign individual rights for different users within a network with the same basic installation under Windows 2000 and Windows NT. You save these individual user profiles on the SmartCards of the individual users with Smarty. As a result, each user finds his/her individual configuration at any workstation within the network simply by inserting his/her SmartCard.

  • Page 70: Troubleshooting

    Security functions Troubleshooting Security panel You have forgotten your password or passwords. If you have forgotten the user password, you can reset the forgotten user password and specify a new user password with the supervisor password. If the Security panel is active and you have forgotten both the user password and the supervisor password, then contact our help desk.

  • Page 71: Connecting External Devices

    Connecting external devices Under all circumstances, please observe the safety notes provided in the "Important notes" chapter. Read the documentation on the external device before connecting it. Do not connect or disconnect cables during a thunderstorm. Do not pull on the cable when disconnecting a cable. Always take hold of the actual plug. Adhere to the order described in the following when you connect external devices to the notebook or separate them from the notebook: Connecting devices to notebook...

  • Page 72: Ports

    Connecting external devices Ports Connections on the left side 1 = Modem port 2 = Wireless LAN/ BLUETOOTH button Ports on the front 1 = Port for external microphone 3 = IEEE1394 FireWire connection 2 = Connector for headphones / SPDIF A26391-K121-Z120-2-7619...
  • Page 73 Connecting external devices Connections on the rear 1 = Serial port 6 = LAN connector 2 = Parallel port 7 = Video output 3 = External monitor connector 8 = USB ports 4 = Infrared interface 9 = Port for power adapter 5 = Connection for an external mouse and/or keyboard Some of the external devices require special drivers (see the operating system and...

  • Page 74: Connecting An External Monitor

    Connecting external devices Connecting an external monitor An external monitor can be connected to the notebook. • Using the [Fn] + [F10] key combination you can switch back and forth between the external monitor and the LCD screen. • If your notebook is equipped with a TFT monitor, you can display the same picture on the external monitor and the LCD screen simultaneously.

  • Page 75: Connecting Usb Devices

    Connecting external devices Connecting USB devices On the USB ports you can connect external devices that also have a USB port (e.g. a printer, a scanner or a modem). USB devices are hot-pluggable. This allows cables from USB devices to be connected and disconnected with the system switched on.

  • Page 77: Settings In Bios Setup

    Settings in BIOS Setup In BIOS Setup you can set the system functions and the hardware configuration of the notebook. The settings can only be changed via the keyboard. When it is delivered, the notebook is set to factory default settings. You can change these settings in BIOS Setup.

  • Page 78: Exiting Bios Setup

    Settings in BIOS Setup Exiting BIOS Setup To exit BIOS Setup, select the Exit menu from the menu bar. You can then decide which settings you want to save. The Exit menu offers the following options. You must mark the required option and activate it with the Enter key. Exit Saving Changes Select Exit Saving Changes and Yes to save the current settings and exit the BIOS Setup.

  • Page 79: Troubleshooting And Tips

    Troubleshooting and tips Take note of the hints in the "Connecting external devices" chapter, when you connect or disconnect cables. If a fault occurs in your notebook, try to eliminate it with the measures described in this chapter. If you fail to correct the problem, proceed as follows: Ê...

  • Page 80: The Notebook's Date Or Time Is Incorrect

    Troubleshooting and tips The notebook's date or time is incorrect Ê Double-click on the clock in the task bar and adjust the time. Ê Set the time and/or date in the BIOS Setup menu Startup. If the date and time are repeatedly incorrect when you switch on the notebook, the buffer battery that supplies the internal clock is dead.

  • Page 81: The External Monitor Is Blank Or The Image Is Unstable

    Troubleshooting and tips The external monitor's power cable or data cable is not connected properly. Ê Switch off the external monitor and the notebook. Ê Check whether the power cable is plugged properly into the external monitor and into the power socket.

  • Page 82: The Notebook Stops Working

    Troubleshooting and tips The notebook stops working If the notebook stops working, this may have the following reasons: The notebook is in Standby or Suspend mode. Ê Reactivate the notebook by pressing a key (Standby mode) or by switching it back on (Suspend mode).

  • Page 83: The Printer Does Not Print

    Troubleshooting and tips The printer does not print Ê Make sure that the printer is switched on and is on-line (see the manuals supplied with the printer). Ê Check that the cable connecting the notebook and the printer is connected properly. Ê...

  • Page 85: Memory Expansion

    Memory expansion The notebook must be switched off when installing/removing the memory modules, it must not be in Suspend mode. Install only memory expansions that satisfy the requirements and rules governing safety, RFI and electromagnetic compatibility and relating to telecommunications terminal equipment (see the "Important notes"...
  • Page 86 Memory expansion Ê Remove the screw (1). Ê Lift the cover off the notebook in the direction of the arrow (2). Removing memory modules Ê Carefully push the two mounting clips outwards (1). The memory module will flap upward (2). Ê...
  • Page 87 Memory expansion Installing memory modules Ê Insert the memory module, contacts first, into the slot (1). Ê Carefully push the memory module downwards until you feel it latch into place (2). Mounting the cover Ê Place the cover on its mounting location (1). Ê...

  • Page 89: Technical Data

    Technical data Notebook Processor: µFCPGA2 Intel Northwood from 1.4 GHz Chipset: Intel Brookdale-M (Intel 845MP) Main memory: Maximum 1024 Mbyte DDR 266 SO DIMM 2 slots for 128/256/512 Mbyte modules • Possible modules: CD-ROM drive, 24X speed • DVD drive, 8/20x (CD-ROM) •...
  • Page 90 Technical data Input devices Keyboard: 88 keys Touchpad: 3 keys Slots PC Card slots (CardBus/PCMCIA): PCMCIA 2 x Type I/II or I x Type III, PC card controller OZ711E1 with SmartCard support Ports Parallel port: 25-pin female connector, ECP capable Port for external monitor: Socket, 15-pin (analogue RGB) Port for external keyboard/mouse:...

  • Page 91: Battery

    Technical data Battery Rated voltage: 14.4 V (lithium ion)/Addl. battery: 10.8 V (lithium ion) Rated capacity: 54.7 Wh Charge time: Approx. 3 hours (BatteryMark 4.01) Operating time: 14.1' XGA TFT: approx. 3 hours Power adapter Primary • Rated voltage: 100 V or 240 V (automatic) •...

  • Page 93: Index

    Index 56k modem 39 BLUETOOTH 40 BLUETOOTH button 62 Board 6 Buffer battery, load 70 Acoustic warnings 73 ACPI 33 changing settings 33 Activating hard disk protection 55 CapsLK indicator 23 Alt Gr key 25 CardBus, see PC card see PC card Anti-theft protection 48 CD/DVD Application examples, SmartCard 58...
  • Page 94 Index Eject button, PC card 42 IEEE1394 (FireWire), connecting Electromagnetic compatibility 8 devices 65 Emergency removal, CD/DVD 38 Important notes 3 Energy consumption 31 Indicators 19 Energy saving 7 CapsLK 23 Energy saving functions 7, 31 charging indicator 22 Standby mode 32 floppy disk indicator 24 Enter key 24 hard disk drive indicator 23...
  • Page 95 Index LAN port 21, 63 No picture 71 LCD screen Notational conventions 2 cleaning 11 Notebook increasing the brightness 26, 28 before you travel 10 is blank 70 cleaning 11 notes 28 disconnecting devices 61 opening 17 not starting 71 reducing the brightness 26, 28 operating 17 reflected glare 70...
  • Page 96 Index Packing material 13 Safety 3 Parallel port 21, 63, 64 Screen brightness Password error alarm 51 decreasing 26, 28 Password protection 46 increasing 26, 28 BIOS password 46 Screen too bright 70 Hard disk 46, 55 Scroll indicator 23 Operating system 46 Security Drivers &...
  • Page 97 Index Suspend mode, terminating 72 Travel, notebook 10 Suspend/Resume button 17, 19, 32 Troubleshooting 69 S-Video Out, switching on/off 26 Synchronisation, screen display 28 System configuration 67 USB devices System settings, BIOS Setup 67 connecting 65 software 65 USB port 21, 63, 65 Technical data 79 connecting devices 65 audio 79...
