Thermostat; User Name - DEFA SmartStart User And Installation Manual

SETTINGS

THERMOSTAT

It's possible to use the temperature sensor as an thermostat in the
compartment or the engine room. This function requires that the System
Control (9) is set to Separate Engine/Compartment.
The Thermostat settings can be found under Settings.
1 - Activate SmartStart™
2 - Press 1x Menu
3 - Press 6x Arrow down to go to Settings.
4 - Press 1x Ok
5 - Press 5x Arrow down to get to Thermostat
6 - Press 1x Arrow up and select Enable and Ok or press
arrow 1x to get to Configure. Select Ok
7 - Select max engine temperature Ok or Arrow down and Ok to select
Min. compartment temperature.
o
Max temp engine: (10-80 C). The thermostat turns off heating at the
set temperature. Re-connects at 5ºC below the set temperature.
Min temp cabin: Connects the compartment (cabin) temperature
when the temperature falls below the set temp. Disconnects at 2
degrees above the set temp.
8 - Set the temperature with Arrow up or down and press Ok to store the
selection or back without storing with the right button.
9 - Remember to activate the Thermostat by pressing Ok when the
display are showing Enable.
If you press the right key according to point 4, the setting process is
interrupted.

USER NAME

DEFA SmartStart™ allows you to store two different user profiles, which
may be appropriate when several people use the same vehicle. Default
values for user profiles are USER1 and USER2. This is how they are
changed:
User Name settings can be found under Settings.
1 - Activate SmartStart™
2 - Press 1x Menu
3 - Press 6x Arrow down to go to Settings.
4 - Press 1x Ok
5 - Press 6x Arrow down to get to User Name
6 - Press 1x Arrow down and select USER1 and select Ok to get
to Settings
7 - Browse with Arrow up/down to choose the letters, symbols or
figures in the black field. Go on to the next field with Ok and select the
next letter, symbol or figure. There are a total of 6 fields that can be
used to name a user.
If you press the right key according to point 4, the setting process is
interrupted.
1x 6x
1x
If you are using the temp. sensor as a interior thermostat, a temp. sen-
sor in the VU unit will control the Aut program for the engine heater.
1x
You can switch user under the menu Users.
To get there press 1x Menu , 1x Arrow down and 1x Ok.
Switch user by using Arrow up/down and press Ok to confirm.
Tip: Leave black a field and continue by pressing Ok.
10
?
1-12x
5x 1x
6x 1x
1x
2x
