Summary of Contents for DEFA SmartStart
- Page 1 SmartStart ™ User and installation guide www.defa.com...
-
Page 2: Table Of Contents
CONTENTS SMARTSTART™ ABOUT THE USER GUIDE FUNCTIONS DISPLAY SYMBOLS DISPLAY MAIN SCREEN SETTINGS CLOCK DATE FACTORY SETTINGS 5 OR 7 DAY WEEK HEATING SYSTEM SYSTEM CONTROL THERMOSTAT USER NAME AUTOMATIC KEYLOCK LIGHT TEMPERATURE UNITS TEMPERATURE CALIBRATION LANGUAGE SERIAL NUMBER ACCESSORIES... -
Page 3: Smartstart
6). The start sequence can be found at the head of the page in the user guide. The example below shows the meaning of the buttons and how you find the Settings menu from the opening screen in SmartStart™. ? represents the starting point for where the explanations begin for each setting. -
Page 4: Functions
SMARTSTART ™ FUNCTIONS SmartStart™ consists of two units – The hand-held remote control (RC) and vehi- cle unit (VU). All communication between the units is initiated by RC. In addition to the key pad lock and “Back light”, all of the settings and data are stored in the VU. -
Page 5: Symbols
... Is NOT turned on at the programmed Pickup time I or II Heating is de-activated and remains de-activated. Aut and Aut show that SmartStart™ has been set to control the engine and compartment heaters independently. E.g. that the engine heater will start at another time than the compart- ment heater (16). -
Page 6: Display
DISPLAY MAIN SCREEN SUB-MENU... -
Page 7: Settings
SmartStart™ then goes to Month. 8 - Browse with Arrow up/down to the correct month and accept with Ok. SmartStart™ then goes to Year. Browse with Arrow up/down to the correct year and accept with Ok. The date is then set. -
Page 8: Factory Settings
SETTINGS 1-12x FACTORY SETTINGS This is where you select the Factory Settings (default) for SmartStart™ Pickup times. It is only the relevant user (USER1 or USER2) Settings that are returned to default. The Factory Settings can be found under Settings. -
Page 9: Heating System
1-12x HEATING SYSTEMS DEFA WarmUp is an electrically powered system and Smartstart™ is factory set with Electric as default. SmartStart™ is ready to also control other fuel powered systems, either in conjunction with DEFA WarmUp or independently. The Heating System settings can be found under Settings. -
Page 10: Thermostat
This function requires that the System Control (9) is set to Separate Engine/Compartment. The Thermostat settings can be found under Settings. 1 - Activate SmartStart™ 2 - Press 1x Menu 3 - Press 6x Arrow down to go to Settings. -
Page 11: Automatic Keylock
The keypad is opened by pressing the right button twice in one second. The Keylock settings can be found under Settings. 1 - Activate SmartStart™ 2 - Press 1x Menu 3 - Press 6x Arrow down to go to Settings. -
Page 12: Temperature Units
TEMPERATURE UNITS Select display in Celsius or Fahrenheit degrees. The temperature format can be found under Settings. 1 - Activate SmartStart™ 2 - Press 1x Menu 3 - Press 6x Arrow down to go to Settings. 4 - Press 1x Ok... -
Page 13: Language
LANGUAGE English is the default language. This is how you change the language. The Language setting can be found under Settings. 1 - Activate SmartStart™ 2 - Press 1x Menu 3 - Press 6x Arrow down to go to Settings. -
Page 14: Accessories
If you activate/set a Next Pickup date, will the pickup times in between be deactivate. After the future date SmartStart™ will use the normal heating program again. -
Page 15: Heating Program
Choosing program mode, the next actual pickup time I 08:00 or On and Off modes overrule your standard programmed settings. II 16:00 shows in the display. In this mode SmartStart™ will use the settings under heating program and repeat this weekly. To set Oversleep - (Available when using electric heating) If you do not weekly program, see page 8. -
Page 16: Separate Connection Times
HEATING PROGRAM SEPARATE CONNECTION TIMES ( Page 9 – System control) Set Separate connecting times at Settings /System control (Page 9) To access this function you need to install an extra relay and some cables (Connecting diagram at page 22). This function make it possible to set different connecting times for the Engine- and Cabin heater. -
Page 17: Date Controlled Connection Times
This function is available at Accessories/Calendar. (Page 14) and is called Next Pickup time. With this function you can set a future pickup time minimum one day ahead. If you do sow DEFA WarmUp will NOT start before this pickup time. After this pickup time SmartStart™ will return to and follow your original heating programs. -
Page 18: Special Settings
SPECIAL SETTINGS CONTROLLING FUEL SYSTEMS In addition to controlling DEFA WarmUp, SmartStart™ can also be set to control fuel-based car heating systems. Either with DEFA WarmUp (Combined) or separately. SmartStart™ can only start on system at a time, electric or fuel. -
Page 19: Technical Information
Radio test complies with ETSI EN 300 220-1:2000-09 cles as walls, other vehicles, etc. Only moving to one side, or Emissions test performed in accordance with EN 301489-1 specifications in order to meet requirement in accordance with 2004/104/EC. holding SmartStart™ straight up and down towards the vehicle may enable contact to be established. HEATING PROGRAM AUTO Common settings Engine- &... -
Page 20: Parts
TECHNICAL INFORMATION PARTS #418100 #418103 Art.no. Part name #418100 SmartStart™ hand-held unit. (Spare part no: #418100) #418103 Lithium 6V (Spare part no: #418103) #418101 Unit fitted in vehicle. (Spare part no: #418101) #418072 Wiring loom connected between C (VU) and DEFA battery charger and/or relay for controlling fuel-based heating systems. -
Page 21: Mounting
Attach with the enclosed cable ties. D* Only necessary for remote control of fuel heating. In the case of DEFA WarmUp the ignition signal is detected by the fall in current when the car is started. The antenna end MUST NOT be fitted in the en- gine compartment. -
Page 22: Connection Diagram / Relay
Attach with the enclosed cable ties. *Blue : Only necessary for remote control of fuel heating. In the case of DEFA WarmUp the ignition signal is detected by the fall in current when the car is started. The antenna end MUST NOT be fitted in the engine compartment. -
Page 23: Support
2 is named ”Mary” is has to be named ”Mary” on both RCs. CONTACT If you have to contact technical support it is an advantage if SmartStart™ works, so that you can find the Unit number and HW-SW version number in advance. You will find this in the menu System Status (1). Press the left button under the work Menu (2). - Page 24 DEFA AS Blingsmoveien 30 N-3540 Nesbyen Norway ( +47 32 06 77 00 7 +47 32 06 77 01 defa.automotive@defa.com www.defa.com 1920267 GB E21 - CE 260413...
