AmpliVox S602 Operating Instructions

http://www.ochimp.com
Thank you for purchasing
AmpliVox S602 - MITY- MEG MEGAPHONE.
We encourage you to visit our website www.ampli.com
to register your product for its warranty coverage, sign
up to receive our newsletter, download our catalog, and
learn more about the complete line of AmpliVox audio
visual products, including portable PA systems, and
lecterns.
OPERATING INSTRUCTIONS
 Batteries: Locate battery compartment latch on top of megaphone ( A ).
Open and insert 8 "C" size batteries (not included) into the battery
sleeves ( B ). Follow battery diagram on label ( C ) and sleeves for
battery direction.
 Battery Status: The megaphone has 3 LED's HIGH, MID, LOW, ( D )
that will tell you the current strength of the batteries. Note: Drained
batteries do not give sufficient sound volume. Replace the batteries
when LOW LED lights when trigger is squeezed. Remove batteries
when not in use for a long time.
 Talk: Make sure that the switch ( E ) is in the Off / Talk position. Place
mouth about one inch from microphone ( F ), squeeze trigger ( G ) and
speak. To increase volume, rotate volume control ( H ) left to right.
When you have a fresh set of batteries you may get "feedback" when
talking. To eliminate feedback you need to turn down the gain. Locate
the gain control ( I ) in the battery compartment. Turn until you do not
hear any feedback.
 Siren: To activate Siren, move switch ( E ) to the right. Siren will be
heard. There is no control of the volume.
 Whistle: To activate Whistle, move switch ( E ) to the left. Whistle will
be heard. There is no control of the volume.
 Property Label: Located on the bottom of the bell. Use marking pen to
write ownership name on megaphone.
 Rechargeable Battery Pack (not included): Optional S1405 Lithium-
ion battery pack with built-in wall charger. Replaces the 8 "C" size

batteries.

IF YOU HAVE ANY QUESTIONS OR
PROBLEMS PLEASE CALL OUR CUSTOMER
SERVICE DEPARTMENT AT 1-800-267-5486
http://www.ochimp.com
A
G
B
I
Optional Rechargeable
Battery Pack
For More Info
Click Here ===>
F
C
D
E
H
