OCTAVIUS CONTROLS
Your Octavius tri-tone generator has 4 controls: LO OCT, HIGH OCT,
MASTER MIX and BOOST.
The LO OCT knob lets you set the volume of the lower octave signal
produced by the pedal.
The HIGH OCT knob controls the volume of the higher octave signal
produced by the pedal.
The balance between the levels of these 2 knobs is what creates your
particular octave-divided sound. Experiment with your mix, and you'll
be amazed at the variety of effects you'll get.
The MASTER MIX knob lets you set the overall volume of your low and
high octaves compared to your direct signal.
Use the BOOST knob to control the output of your octave-divided
sound. The boost function lets you dial in a solo level, whether the over-
drive circuit is activated or not.

TECHNICAL SPECIFICATIONS

Input Impedance@1KHz
Output Impedance@1KHZ
Power supply
Minimum Power supply Voltage
Maximum Power supply Voltage
Current Draw @ 9V DC
Maximum Input signal Vp/p
External connectors
Controls
Pedal size incl. knobs (W x H x D)
Weight
(excl. battery and packaging)
Higher than 1M ohm
Lower than 1K ohm
12V DC, 1250 mA external power
supply. Runs on 100/115/230V AC/50–
60Hz, dependent on country.
8,5V DC
12,5V DC
150 mA
2,7 Vp/p
Input Jack, Output Jack, 9-12V DC
Jack
LO OCT, HIGH OCT, MASTER MIX,
BOOST
100 x 55 x 120 mm
3,9 x 2,2 x 4,7 inch
0,350 kg / 12,3 oz
