BACK TO BASSICS
The Sweeper has everything you need to get the full range of classic
bass chorus sounds – using just a few simple controls.
DEPTH controls the amount of chorus effect. Turn it down for a subtle
chorus, crank it up for that great full sweep.
Use the RATE control to set the speed of your sweep. A fast rate com-
bined with a low depth level gives you a light shimmering sound, while
the slower rate and higher depth creates a dramatic chorus effect.
VOLUME controls the overall output of The Sweeper, and the INPUT
LEVEL on the side of the unit helps you avoid overdrive distortion by
turning down the input signal. If the red overload light comes on, the
input level is too high.
Note: If you're in the studio or have a stereo live setup, try using The
Sweeper's stereo outputs for a truly mind-blowing stereo chorus!

TECHNICAL SPECIFICATIONS

Input Impedance@1KHz
Output Impedance@1KHZ
Power supply
Minimum Power supply Voltage
Maximum Power supply Voltage
Current Draw @ 9V DC
Maximum Input signal Vp/p
Battery Type
Battery Life
External connectors
Controls
Depth
Width
Height
Weight (excl. battery)
470 KOhm
35 Ohm
9V DC (Power tool 9)
8,5V DC
12,5V DC
90 mA
Adjustable
9 V battery 6F22
30 - 60 min.
Input Jack. Output Jack, 9V DC
Jack
On/Off, Depth, Volume, Rate
120 mm
100 mm
55 mm
0,430 kg
