SWITCHING BETWEEN TWO KEYBOARDS
KEYBOARD 1
MIXER
KEYBOARD 2

TECHNICAL SPECIFICATIONS

Input Impedance @ 1KHz with buffer OFF
Input Impedance @ 1KHz with buffer ON
Output Impedance @ 1KHz with buffer OFF
Output Impedance @ 1KHz with buffer ON
Power supply
Minimum Power supply Voltage
Maximum Power supply Voltage
Current Draw @ 9V DC
Maximum input signal Vp/p with buffer OFF
Maximum input signal Vp/p with buffer ON
Battery Type
Battery Life
External connectors
Controls
Pedal size incl. knobs (W x H x D)
Weight
(excl. battery and packaging)
3,5MOhm
862KOhm
>10MOhm
120Ohm
9V DC (T-Rex FuelTank)
8V DC
12, 5V DC
19mA
Input = Output. No limit
4Vp/p
9V battery 6F22
5 to 8 hours
Input left, Input right, Out(A) left /right
Out(B) left/right
On/Off - buffer
100 x 55 x 120 mm / 3,9 x 2,2 x 4,7 inch
0,335 kg / 11.8 oz
