Technical Specifications - T-Rex REPLICA User Manual

TECHNICAL SPECIFICATIONS

Input Impedance@1KHz
Output Impedance@1KHZ
Power Supply
Minimum Power supply Voltage
Maximum Power supply Voltage
Current Draw @ 12V DC
Maximum Input signal Vp/p
External Connectors
Controls
Pedal size incl. knobs (W x H x D)
Weight
(excl. battery and packaging)
Higher than 1 M ohm
Lower than 1 K ohm
External 12V DC, -1250 mA power sup-
ply. Runs on 100/115/230V AC/50-60Hz
depending on the country
10,8V DC
12,5V DC
113mA
1,7Vp/p
Input Jack. Output Jack, Direct Jack, 12V
AC/DC jack, Midi (5 pole female Din Plug)
Echo, Repeat, Tempo, Level, Brown, Sub-
division, On/Off, Tap Tempo, Input Level
100 x 55 x 120 mm / 3,9 x 2,2 x 4,7 inch
0,380 kg / 13.4 oz
