Technical Specifications - T-Rex ToneBug Series User Manual

5 STEPS TO WORLD OF EFFECTS
Using your ToneBug Chorus + Flanger
Insert a 9V alkaline battery or connect to an electrical outlet using the
T-Rex Fuel Tank power supply (not included).
Plug your guitar into the INPUT jack, and run a lead from the OUTPUT
jack into your amp.
Use the Chorus/Flanger switch to choose which effect you want.
Use the RATE knob to set the speed of your modulation, and the
DEPTH knob to choose how "heavy" you want the chorused or
flanged effect to be.
Then use the LEVEL knob to set your overall output volume – and go!

TECHNICAL SPECIFICATIONS:

Input Impedance @ 1KHz
Output Impedance @ 1KHz
Power supply
Minimum Power supply Voltage
Maximum Power supply Voltage
Current Draw @ 9V DC
Maximum input signal Vp/p
Battery Type
Battery Life
External connectors
Controls
Depth
Width
Height
Weight (excl. battery)
Higher than 1 M Ohm
Lower than 1 K Ohm
9V DC
8V DC
12,5V DC
75 mA
2,5 Vp/p
9V battery 6F22 Alkaline
0,5 to 1 Hours
Input Jack. Output Jack, 9V DC Jack (center
pin negative)
On/Off, Rate, Flanger, Depth, Chorus
120 mm
78 mm
60 mm
0,404 Kg
