Input

The Input tab displays various source and frequency values at a glance.
The following table lists all items with a description.
L
ABEL
Input name
Signal
H-sync. freq.
V-sync. freq.
Video type
Sync type
Sync polarity
Scan type
Displays the Input Terminal that is presently being used
(see Default input select on page 74).
Displays the Source name of the signal presently being used.
Displays Horizontal frequency in KHz.
Displays Vertical frequency in Hz.
Displays Video type.
Displays Sync type.
Displays Sync polarity.
Displays Scan type.
