Set Value Command; Data Range; Query Command; Response Message - BOXLIGHT Pro6500DP User Manual

D L P P r o j e c t o r — U s e
D L P P r o j e c t o r — U s e
D L P P r o j e c t o r — U s e

Set Value Command

ITEM
Brightness
Contrast
Color(Saturation)
Tint
Scaling
Color Temperature
Projection Mode
? : ASCII Data

Data Range

ITEM
Brightness
Contrast
Saturation
Tint
Scaling
Color Temperature
Projection Mode
Saturation and Tint is not available when Video Type(color space) change to "RGB"
Example 1. Adjust Brightness value to 100
Example 2. Adjust Color Temperature to Warm

Query Command

ITEM
Software Version
Power State
Input Select
Lamp Hours
Lamp1 Hours
Lamp2 Hours
Brightness
Contrast
Saturation
Tint
Aspect Ratio
Color Temperature
Projection Mode

Response message

ITEM
Software Version
Power State
Input Select
Lamp Hours
Lamp1 Hours
Lamp2 Hours
Brightness
Contrast
Saturation
Tint (Video)
Aspect Ratio
Color Temperature
Projection Mode
Example 1. Get Brightness value
Example 2. Get Color Temperature
r ' s M a n u a l
r ' s M a n u a l
r ' s M a n u a l
ASCII
~ s B ? CR
~ s C ? CR
~ s R ? CR
~ s N ? CR
~ s A ? CR
~ s T ? CR
~ s J ? CR
Set Data Range
0 ~ 100(default 50)
0 ~ 100(default 50)
0 ~ 100(default 50)
0 ~ 100 (default 50)
0: 4:3 1: 16:9 2: 15:93: Crop
4: Letterbox5: Native6: Normal
0:5000K1:6500K2:7800K3:8500K
4:9300K5:10500K6:High-Bright
0:Front 1:Rear+Ceiling 2:Rear
3:Ceiling
ASCII
~ q V CR
~ q P CR
~ q S CR
~ q L CR
~ q L 1 CR
~ q L 2 CR
~ q B CR
~ q C CR
~ q R CR
~ q N CR
~ q A CR
~ q T CR
~ q J CR
Response Message examples
DP3650-XXXX-DPXXX
On Off
Computer1 Computer2 Computer3 Component Video S-Video
2000,2000
2000
2000
0 ~ 100
0 ~ 100
0 ~ 100
0 ~ 100
4:3 16:9 15:9 Crop Letterbox Native Normal
5000K 6500K 7800K 8500K 9300K 10500K High-Bright
Front Rear+Ceiling Rear Ceiling
Send Command : ~qBCR
Send Command : ~qTCR
HEX
7Eh 73h 42h ?h 0Dh
7Eh 73h 43h ?h 0Dh
7Eh 73h 52h ?h 0Dh
7Eh 73h 4Eh ?h 0Dh
7Eh 73h 41h ?h 0Dh
7Eh 73h 54h ?h 0Dh
7Eh 73h 4Ah ?h 0Dh
Send Command : ~sB100CR
Send Command : ~sT2CR
HEX
7Eh 71h 56h 0Dh
7Eh 71h 50h 0Dh
7Eh 71h 53h 0Dh
7Eh 71h 4Ch 0Dh
7Eh 71h 4Ch 31h 0Dh
7Eh 71h 4Ch 32h 0Dh
7Eh 71h 42h 0Dh
7Eh 71h 43h 0Dh
7Eh 71h 52h 0Dh
7Eh 71h 4Eh 0Dh
7Eh 71h 41h 0Dh
7Eh 71h 54h 0Dh
7Eh 71h 4Ah 0Dh
Response : 100
Response : Warm
– 100 –
Source
All Source
All Source
All Source
All Source
All Source
All Source
All Source
