THE ABBOT
26,000 BTU INSERT SERIES
Installation and Operating Instructions
Installation in Masonry Chimney Only
MODELS:
ABBOT-30-PG-PREM, ABBOT-30-BL-PREM
ABBOT-30PG-DELUXE, ABBOT-30-BL-
DELUXE
IF THE INFORMATION IN THESE INSTRUCTIONS IS
NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE,
PERSONAL INJURY, OR DEATH.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance
Do not touch any electrical switch; do not use
any phone in your building
Immediately call your gas supplier from a
neighbour's phone. Follow gas supplier's
instructions
If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or gas
supplier.
WARNING: Improper installation, adjustment,
alteration, services or maintenance can cause injury
or property damage. Refer to this manual. For
assistance or additional information consult a
qualified installer, service agency or the gas
supplier.
PLEASE READ THIS MANUAL BEFORE INSTALLING OR USING THIS APPLIANCE.

Natural Gas

CERT # LC773211
WARNING
appliance.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
D
UE TO HIGH TEMPERATURES
THE APPLIANCE SHOULD BE
LOCATED OUT OF TRAFFIC AND
AWAY FROM FURNITURE AND
DRAPERIES
C
HILDREN AND ADULTS SHOULD
BE ALERTED TO THE HAZARDS
OF HIGH SURFACE
TEMPERATURE AND SHOULD
STAY AWAY TO AVOID BURNS OR
CLOTHING IGNITION
Y
OUNG CHILDREN SHOULD BE
SUPERVISED WHEN THEY ARE IN
THE SAME ROOM AS THE
APPLIANCE
C
LOTHING OR OTHER
FLAMMABLE MATERIAL SHOULD
NOT BE PLACED ON OR NEAR THE
APPLIANCE
KEEP THE ROOM AREA CLEAR AND
FREE FROM COMBUSTIBLE
,
MATERIALS
GASOLINE
OTHER FLAMMABLE VAPORS AND
.
LIQUIDS
,
.
.
.
.
,
AND
Page 1 of 48

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ABBOT-30-PG-PREM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sierra Flame ABBOT-30-PG-PREM

  • Page 1: Natural Gas

    THE ABBOT 26,000 BTU INSERT SERIES Natural Gas Installation and Operating Instructions Installation in Masonry Chimney Only MODELS: ABBOT-30-PG-PREM, ABBOT-30-BL-PREM ABBOT-30PG-DELUXE, ABBOT-30-BL- DELUXE CERT # LC773211 UE TO HIGH TEMPERATURES WARNING THE APPLIANCE SHOULD BE IF THE INFORMATION IN THESE INSTRUCTIONS IS...
  • Page 2 THE ABBOT 26,000 BTU SÉRIE INSERT AU GAZ NATUREL Manuel D’installation et Guide de l’utilisateur Installation dans la cheminée en maçonnerie MODELS: ABBOT-30-PG-PREM, ABBOT-30-BL-PREM ABBOT-30PG-DELUXE, ABBOT-30-BL-DELUXE CERT # LC773211 N RAISON DE TEMPERATURES AVERTISSEMENT ELEVEES APPAREIL DOIT ETRE ASSUREZ-VOUS DE BIEN SUIVRE LES INSTRUCTIONS PLACE HORS DE LA CIRCULATION DONNÉES DANS CETTE NOTICE POUR RÉDUIRE AU...
  • Page 3: Table Of Contents

    Table of Contents IMPORTANT SAFETY INFORMATION …………………………………………………………….. 4 - 5 INTRODUCTION ........................Specifications, Appliance Dimensions & Installation Codes ......... 6 - 7 Features, Remote Control Functions ..............8 - 10 Intended Use ......................11 General Safety ....................11 - 12 OPERATION ...........................
  • Page 4: Important Safety Information

    WARNING AVERTISSEMENT INSTALLER: Leave this manual with the INSTALLATEUR : Laissez cette notice avec appliance. l’appareil. CONSUMER: Retain this manual for future CONSOMMATEUR : Conservez cette notice reference. pour consultation ultérieure. WARNING • Read this owner’s manual carefully and completely before trying to assemble, operate or service this fireplace.
  • Page 5 Do not use this appliance if any part has Ne pas utiliser cet appareil s’il a été plongé, been under water. Immediately call a meme partiellement, dans l’eau. Appeler un qualified service technician to inspect the technician qualifié pour inspecter l’appareil et appliance and to replace any part of the remplacer toute partie du système de control system and any gas control which...
  • Page 6: Introduction

    1.0 INTRODUCTION 1.1 SPECIFICATIONS TABLE 1 ITEM NATURAL GAS (NG) DVI26000 INPUT: Hi 26,000 Btu/hr (7.62 kW) DVI26000 INPUT: Lo 20,000 Btu/hr (4.69 kW) MANIFOLD PRESSURE: Hi 3.5” w.c. (0.87 kPa) COLLECTEUR DE PRESSION: FORT MANIFOLD PRESSURE: Lo 1.7” w.c. (0.42 kPa) COLLECTEUR DE PRESSION: FAIBLE GAS INLET SUPPLY PRESSURE: Minimum: 5.0”...
  • Page 7 APPLIANCE DIMENSIONS Figure 1 RIGHT SIDE LEFT SIDE FRONT INSTALLATION CODES This appliance is a Direct Vent appliance which draws all combustion air from outside the building through an intake vent pipe. Installation must conform to local codes. In the absence of local codes, installation must conform to the National Fuel Gas Code, ANSI Z223.1, or the current CSA B149.
  • Page 8: Features, Remote Control Functions

    1.2 FEATURES Electronic Valve: Automatic DC valve with AC power adapter. Hand held remote control. Fan control Variable speed control: For units equipped with a fan control, adjust speed by remote control settings 1-6 Supreme Remote Control Functional Operation Matrix Initial Setup Installation of (2) AAA-size batteries will activate the setup mode.
  • Page 9 Press the UP or DOWN button to change the setting of P1 OFF. Press and release the SET button. Press the UP or DOWN button to change the setting of P2 ON. Press and release the SET button. Press the UP or DOWN button to change the setting of P2 OFF. Press and release the SET button. Press the UP or DOWN button to change the setting of the weekend (SS) P1 ON.
  • Page 10 The fan will run for 12 minutes after the unit is shut off in any mode. The fan may not be controlled during this period. Continuous Pilot The unit can be changed from Intermittent Pilot Ignition (IPI), to Continuous, or standing, pilot. To place the unit in continuous pilot mode, press and release the PROG/TIME and the FLAME MAIN buttons simultaneously.
  • Page 11: Intended Use

    1.3 INTENDED USE / USAGE PROPOSÉ This appliance is for use in a masonry chimney only. Cet appareil est utilisé dans une cheminée en maçonnerie. 1.4 GENERAL SAFETY / SÉCURITÉ GÉNÉRALE • Maintain adequate clearances around air openings into the combustion chamber. •...
  • Page 12 WARNING Hot while in operation. Do Not Touch. Severe burns may result. Keep children, clothing, furniture, gasoline and other liquids having flammable vapors away. Toddlers, young children and others may be susceptible to accidental contact burns. A physical barrier is recommended if there are at risk individuals in the house. To restrict access to a fireplace or stove install an adjustable safety gate to keep toddlers , young children and at risk individuals out of the room and away from hot surfaces.
  • Page 13: Operation

    2.0 OPERATION LIGHTING INSTRUCTIONS - for Intermittent Pilot FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. This appliance is equipped with an ignition device which automatically lights the pilot. Do not try to light the pilot by hand. BEFORE LIGHTING smell all around the appliance area for gas.
  • Page 14 INSTRUCTIONS LIGHTING - Pilote intermittent POUR PLUS DE SÉCURITÉ, LIRE AVANT D’ALLUMER AVERTISSEMENT: Quiconque ne respecte pas à la letter les instructions dans la présente notice risqué de déclencher un incendie ou une explosion entraînant des dommages, des blessures ou la mort. Cet appareil est équipé...
  • Page 15: Installation

    3.0 INSTALLATION 3.1 INSTALLATION & SAFETY NOTES / NOTES D'INSTALLATION ET DE SECURITE Read all instructions before starting installation and follow them carefully during installation to ensure maximum benefit and safety. Failure to follow these instructions will void your warranty and may present a fire hazard.
  • Page 16: Minimum Clearances

    3.3.1 MINIMUM CLEARANCES / DÉGAGEMENTS Figure 2 Minimum clearance from bottom front of fireplace to combustibles 12”(305mm) Distance minimale de l’avant en bas de la cheminée à combustibles 12” (305mm) Figure 3 Mantle Height Mantle Depth (X) from Floor (Y) 40"...
  • Page 17: Gas Line Installation

    Clearances are in accordance with local installation codes and the requirements of the gas supplier. **The mantel placement chart on the previous page illustrates the allowable mantel sizes and placements. The 1” incremental grid can be used to determine the allowable mantel size based on the elevation above the units upper trim.
  • Page 18: Digital On/Off Remote

    WARNING AVERTISSEMENT DO NOT USE AN OPEN FLAME TO TEST FOR GAS LEAKS NE PAS UTILISER UNE FLAMME DE TEST DE FUITES DE GAZ 3.3.3 DIGITAL ON/OFF REMOTE INSTALLATION This appliance comes with a remote hand held control unit only, see 1.2 Features section 3.3.4 DIRECT VENT INFORMATION The unit must be connected to listed 2-ply aluminium venting, 3”...
  • Page 19: Masonry Fireplace

    TYPICAL FLEX VENT INSTALLATIONS Terminal Vent Cap must be sealed to the Chimney top to prevent Figure 4 Use silicon to seal inlet leakage. pipe to terminal vent. Use mill pak to seal Terminal vent must be secured to the inlet exhaust to terminal vent.
  • Page 20 Figure 5 Reattach firmly with lock-in screws 3/. From the roof, pull the liners and fit the roof flashing in place. 4/. Fit the termination cap making sure that the exhaust liner is connected to the exhaust vent collar. Make sure the termination and venting are sealed from water penetration with an approved sealant. REMOVAL AND REINSTALLATION If the fireplace is removed at any time by disconnecting the slider on the top holding the intake and exhaust pipes, the gasket between the fireplace and the slider must be replaced with a new gasket #...
  • Page 21 USE OF COUPLERS – WITH FLEX PIPE In the event of a puncture of the vent pipe or if an extension is needed couplers may be used. High temperature sealant shall be applied to the ends of the coupler and then the coupler shall then be inserted into the flex vent.
  • Page 22 Figure 7 VENT RESTRICTOR INSTALLATION (continued) The restrictors are installed by removing the 2 screws on the ceiling of the firebox, place the desired restrictor in place and use the screws to fasten the restrictor to the firebox. You must first remove the firebox baffle (4 screws) before installing the desired restrictor.
  • Page 23 3.3.5 CERAMIC LOG INSTALLATION / PLACEMENT DES BÛCHES Burn medium positions are critical to the safe and clean operation of this appliance. Never add any other material into the firebox. Use only with burn medium supplied with this unit. Burn positions moyennes sont critiques pour le fonctionnement sûr et propre de cet appareil.
  • Page 24: Ceramic Log Installation

    CERAMIC LOG INSTALLATION (continued) Step 3: Place log number 2 at left side of fireplace parallel with the left side firebricks Step 4: Place log number 3 at right side of fireplace parallel with right side firebricks Page 24 of 48...
  • Page 25 CERAMIC LOG INSTALLATION (continued) Step 5: Place log number 4 onto placement pins in left side of firebox Step 6: Place log number 5 onto placement pins in right side of firebox with cutout portion towards the front Page 25 of 48...
  • Page 26 CERAMIC LOG INSTALLATION (continued) Step 7: Place log number 6 on top of logs 2 and 4, angled as shown below Step 8 Place log number 7 from right back firebox corner down onto pin in log 5 with cutout in log towards front of firebox Page 26 of 48...
  • Page 27 CERAMIC LOG INSTALLATION (continued) Step 9 Place log number 8 diagonally from pin in rear log 1 to bottom front of log 6 Step 10 Place log number 9 diagonally across log 8 and down onto cutout in log 7 Your fireplace logs are now in position and after door installation (see 3.3.7 page 24) your fireplace can be lit.
  • Page 28: Rock & Glass Installation

    3.3.6 Rock & Glass Installation / Rock & Installation de verre For use with Tasman DVI26,000RG Model only Step 1. Sprinkle burner pan with river glass. Make sure to cover the burner pan evenly. Step 2 Make sure that none of the glass falls into the pilot box area of the burner pan. This ensures no interference with the pilot assembly and ignition.
  • Page 29 Step 3 Place the ceramic rocks in a pattern that is pleasing to you. Install the door (see 3.3.7 page 24) Turn your fireplace on and wait approximately 10-15 minutes until the flames are a nice yellow colour. Note the flame pattern and in any low or high areas adjust the amount of river glass to correct gas flow, also move the ceramic rocks around so that they are not interfering with the flame pattern.
  • Page 30: Door Installation

    3.3.7 Door Installation Fit the bottom of the door into the lower door bracket, make sure the door is centered on the appliance. Push top of door onto the appliance and pull the 2 door lock bars forward and down into the door lock to secure the door in place.
  • Page 31: Initial Firing & Manifold Pressure

    3.3.8 INITIAL FIRING When lit for the first few times, the appliance may emit an odor resulting from evaporation of paint and lubricants used in the manufacturing process. Open a door or window for ventilation. Anyone with a respiratory condition may need to leave the room during the initial firings. It is normal for the appliance to expand and contract while it heats up or cools down whether this is from a cold start or a steady-state condition where the fan has come on or off.
  • Page 32: Altitude Adjustment

    Factory Setting Natural Gas – 50% Figure 11 Note: Burner in bottom of firebox removed for illustration purposes. Aeration adjustment is important for the correct functioning of the appliance. Carbon build up, flame lifting or any malfunction due to improper aeration adjustment during installation is not covered under the factory warranty.
  • Page 33: Fan & Gas Valve Access

    3.3.11 FAN & GAS VALVE ACCESSIBILITY / FAN & ACCESSIBILITÉ VANNE GAZ TURN THE MAIN GAS & POWER OFF TO FIREPLACE BEFORE COMMENCING ANY WORK ON THE INSERT THIS SHOULD BE DONE BY A LICENSED, CERTIFIED GAS INSTALLER TURN LE PRINCIPAL GAZ ET MISE HORS TENSION AU FOYER AVANT DE COMMENCER TOUT TRAVAIL SUR LA INSERT CELA DEVRAIT ETRE FAIT PAR UNE LICENCE, VOTRE FOURNISSEUR DE 1.
  • Page 34 Gas Shutoff Electronic Ignition System Gas Valve Fan Electrical Box Control Unit Fan and Power Cord 4/. Reinstallation of the unit is in reverse order. Make sure the gasket on the bottom of the vent slide is intact and the venting is secured tightly with the vent slide screws. Contact your dealer for replacement if there is any damage to the gasket.
  • Page 35: Maintenance

    4.0 MAINTENANCE 4.1 MAINTENANCE SAFETY WARNING AVERTISSEMENT TURN OFF THE GAS TO THE MAIN BURNER AND ALLOW THE HEATER TO COOL FOR UP TO 30 MINUTES BEFORE SERVICING. COUPEZ LE GAZ AU BRÛLEUR PRINCIPAL ET LAISSEZ L'APPAREIL REFROIDIR PENDANT JUSQU'À 30 MINUTES AVANT L'ENTRETIEN. Turn off the gas to the main burner and allow the heater to cool for up to 30 minutes before servicing.
  • Page 36: Burner & Pilot Cleaning

    4.4 BURNER & PILOT CLEANING Periodic cleaning is necessary for proper operation. Refer to section 4.7, remove the burner, and check that the burner orifice is clean. Visually inspect the pilot. Brush or blow away any dust, lint, or foreign debris. If the pilot orifice is plugged, disassembly may be required to remove any foreign material from the orifice or tubing.
  • Page 37: Trouble Shooting

    5.0 TROUBLE SHOOTING SYMPTOM CORRECTIVE ACTION POSSIBLE CAUSE Pilot will not light after A. No spark at electrode (weak or not heat source for pilot ignition) repeated triggering of the remote control 1. Improper ignition 1. Align the electrode with 1/8” (3mm) gap to pilot hood 2.
  • Page 38 IV. Soot deposits 1. Air inlet blocked or restricted 1. Clean air inlets 2. Vent system is restricted or 2. Confirm venting & termination are those inadequate which are approved with the appliance 3. Logs are sooting up 3. Check manual for correct log placement Flame burns blue and lifts off burner 1.
  • Page 39: Replacement Parts

    6.0 REPLACEMENT PARTS When requesting service or replacement parts for your unit, please provide model name and serial number. All parts listed below may be ordered from an authorized dealer. Description Part# Door IMC121 Burner (Log Set) IMC113L Burner (Rock & Glass Set) IMC113R IMC001 Door Glass...
  • Page 40: Warranty

    SIERRA FLAME’S GAS FIREPLACE’S WARRANTY Your Sierra Flame gas fireplace is guaranteed to be free of defects in materials and workmanship for a period of 5 years from the date of purchase. This covers: combustion chambers, heat exchangers and burners as well as stainless steel parts against tarnishing.
  • Page 41 GARANTIE DU FOYER AU GAZ DE SIERRA FLAME Votre foyer au gaz Sierra Flame est garanti d'être exempt de défauts de matériaux et de fabrication pour une période de 5 ans à compter de la date d'achat. Cette garantie couvre: chambres de combustion, échangeurs de chaleur et brûleurs ainsi que des pièces en acier inoxydable contre le ternissement.
  • Page 42 (s), la réparation ou le remplacement ou non de même, ne seront pas couverts par cette garantie ni ne doit Sierra Flame assumer la responsabilité de même. En outre, Sierra Flame ne sera pas responsable des dommages accessoires, indirects ou conséquents, sauf dans les cas prévus par la loi, et en aucun cas, ils dépassent le prix d'achat original.
  • Page 43: Label Information

    8.0 LABEL INFORMATION Page 43 of 48...
  • Page 44 8.0 LABEL INFORMATION (continued) Sections of the venting system have not been installed. WARNING – Do not operate the appliance until all sections have been assembled and installed in accordance with the manufacturer’s instructions. Des sections du système d’évacuation n’ont pas été installées. AVERTISSEMENT - Ne pas utiliser l’appareil tant que toutes les sections n’ont pas été...
  • Page 45: Appendix A (Intermittent Pilot & Valve Kit)

    APPENDIX A (AMERICAN FLAME VALVE INFORMATION) Page 45 of 48...
  • Page 46 APPENDIX A (Continued) Page 46 of 48...
  • Page 47 APPENDIX A (Continued) Special Features on the AF-4000 System The AF-4000 Module can be powered two different ways. The first is a standard 110 volt AC to 6.0 volt DC adaptor. This adapter is connected to the AF-4000 Module by connecting the two 1/4” female terminals from the adapter to the two 1/4”...
  • Page 48 APPENDIX A (Continued) AF-4000 Wiring Diagram Sierra Flame 1503-7088 18th Ave., Burnaby, BC V3N 0A2 Page 48 of 48...
