INSTALLATION AND OPERATION INSTRUCTIONS FOR WALL-MOUNT
AND BUILT-IN UNITS
WM-FML-26-3223-STL
WM-FML-34-4023-STL
WM-FML-48-5523-STL
WM-FML-60-6623-STL
WM-FML-72-7823-STL
WM-FML-88-9623-STL
SAFETY INFORMATION
WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sierra Flame WM-FML-26-3223-STL
Summary of Contents for Sierra Flame WM-FML-26-3223-STL
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR WALL-MOUNT AND BUILT-IN UNITS WM-FML-26-3223-STL WM-FML-34-4023-STL WM-FML-48-5523-STL WM-FML-60-6623-STL WM-FML-72-7823-STL WM-FML-88-9623-STL SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
The instructions included here will assure that you have many years of dependable and enjoyable service from your Serria Flame product. IMPORTANT INSTRUCTIONS............................3 UNPACKING AND TESTING APPLIANCE .......................4 GROUNDING APPLIANCE ............................4 LOCATING THE FIREPLACE .............................4 WM-FML-26-3223-STL..............................5 WM-FML-34-4023-STL..............................6 WM-FML-48-5523-STL..............................7 WM-FML-60-6623-STL..............................8 WM-FML-72-7823-STL..............................9 WM-FML-88-9623-STL ..............................10 REMOVING FRONT PANEL.............................11... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front of the heater; keep them away from sides and rear as well. 3. -
Page 4: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. There are two screws on each side to fix the front panel. Please see the figure right side. -
Page 5: Wm-Fml-26-3223-Stl
WM-FML-26-3223-STL Description Built-in or Wall Mount Appliance This appliance has been tested in Voltage 120V AC 60Hz accordance with the UL Standard 2021 Watts 1500W Max for fixed and location dedicated NO HEATER electric room appliances in the United MOTOR HEATER States and Canada. -
Page 6: Wm-Fml-34-4023-Stl
WM-FML-34-4023-STL This appliance has been tested in Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER Canada. -
Page 7: Wm-Fml-48-5523-Stl
WM-FML-48-5523-STL This appliance been tested Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER If you need assistance during installation, MOTOR HEATER please contact your local dealer. -
Page 8: Wm-Fml-60-6623-Stl
WM-FML-60-6623-STL This appliance been tested Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER If you need assistance during installation, MOTOR HEATER please contact your local dealer. -
Page 9: Wm-Fml-72-7823-Stl
WM-FML-72-7823-STL This appliance has been tested in Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and NO HEATER Canada. -
Page 10: Wm-Fml-88-9623-Stl
WM-FML-88-9623-STL This appliance been tested Description Built-in or Wall Mount Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER If you need assistance during installation, MOTOR HEATER please contact your local dealer. -
Page 11: Removing Front Panel
REMOVING FRONT PANEL Models WM-FML-26-3223-STL, WM-FML-34-4023-STL, WM-FML-48-5523-STL, WM- -FML-60-6623-STL each have 2 screws that secure the front panel in place. Models WM-FML- -72-7823-STL and WM-FML-88-9623-STL have four screws that secure the front panel in place. Two people are required for the installation process. -
Page 12: Installation-Wall Mount
Remove mounting plate from the back of the appliance by INSTALLATION-WALL MOUNT 1. Select a location that is not prone to moisture and is located at least 0.91 m or 3 feet away from combustible materials such as curtains or drapes, furniture, bedding, paper, etc. -
Page 13: Installation- Built-In
120 Volt grounded outlet. The rough wall opening size of the fireplace: W(“) D(“) H(“) 6 1/2 20 1/2 WM-FML-26-3223-STL 6 1/2 20 1/2 WM-FML-34-4023-STL 6 1/2 20 1/2 WM-FML-48-5523-STL 60 5/8 6 1/2... -
Page 14: Hard- Wire Installation
HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the household wiring. -
Page 15: Media Options
MEDIA OPTIONS The only media that comes with this version is ‘Clear decorative media’. Consumers may purchase optional decorative media if they choose. See dealer for more details. Clear DECORATIVE MEDIA INSTALLATION NOTE:Please unplug the power cord before you install the decorative media. Removing the front panel Remove the screws from both sides of the unit to take off the surround. -
Page 16: Operation
Operating with Touch Panel The unit can be controlled by either the touch panel controls which are located on the left side of the front panel or the remote control. ON/OFF Flame Timer Heater Indicator Power 1. Press “ ” to turn on and off the appliance. 2. -
Page 17: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and main power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button the buzzer inside the unit will beep once. -
Page 18: Installing Wall Thermostat
INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS NOTE: THE WALL THERMOSTAT WILL WOKE WHEN THE HEATER ON TEMP. SETTING. PLEASE REFER TO THE MANUAL CONTROL AND THE REMOTE CONTROL. Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. -
Page 19: Replacement Parts
REPLACEMENT PARTS PART NUMBER QTY. WM-FML-26- WM-FML-34- WM-FML-48- WM-FML-60- WM-FML-72- WM-FML-88- DESCRIPTION 3223-STL 4023-STL 5523-STL 6623-STL 7823-STL 9623-STL FIREPLACE BOX 301506 REMOTE RECEIVER 601095D CIRCUIT BOARD 601300C TOUCH PANEL TOP PANEL BLOWER AND HEATER 602082 ASSEMBLY 1070117 1070117 1070117 1070117 BACK BLACK PLASTIC GLASS 3117505 BLOWER MOUNT... -
Page 20: Exploded View
EXPLODED VIEW... -
Page 21: Truble Shooting
TRUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow... -
Page 22: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
