INSTALLATION AND OPERATION INSTRUCTIONS FOR
VISTA-BI-12 UNITS
VISTA-BI-50-12
VISTA-BI-60-12
VISTA-BI-72-12
SAFETY INFORMATION
WARNING
If the information in these
instructions are not followed exactly,
a fire or explosion may result causing
property damage, personal injury or
loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISTA-BI-50-12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sierra Flame VISTA-BI-50-12

Summary of Contents for Sierra Flame VISTA-BI-50-12

  • Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR VISTA-BI-12 UNITS VISTA-BI-50-12 VISTA-BI-60-12 VISTA-BI-72-12 SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: Table Of Contents

    Amantii product. IMPORTANT INSTRUCTIONS............................3 UNPACKING AND TESTING APPLIANCE .......................4 GROUNDING APPLIANCE ............................4 LOCATING THE FIREPLACE .............................4 VISTA-BI-50-12................................5 VISTA-BI-60-12................................6 VISTA-BI-72-12................................7 INSTALLATION................................8 HARD- WIRE INSTALLATION ...........................9 Media Options ................................10 OPERATION................................11...

  • Page 3: Important Instructions

    IMPORTANT INSTRUCTIONS Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front of the heater; keep them away from sides and rear as well.

  • Page 4: Unpacking And Testing Appliance

    UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. GROUNDING APPLIANCE This appliance is for use on 120 Volts.

  • Page 5: Vista-Bi-50-12

    VISTA-BI-50-12 This appliance has been tested in accordance with the UL Standard Model Number VISTA-BI-50-12 2021 for fixed and location dedicated Voltage 120V AC 60Hz electric room appliances in the United Watts 1500W Max States and Canada. If you need...

  • Page 6: Vista-Bi-60-12

    VISTA-BI-60-12 This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States and NO HEATER Canada. If you need assistance during MOTOR HEATER installation, please contact your local Appliance Width...

  • Page 7: Vista-Bi-72-12

    VISTA-BI-72-12 This appliance has been tested in Description Built-in Appliance accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated electric Watts 1500W Max room appliances in the United States NO HEATER and Canada. If you need assistance MOTOR HEATER during installation, please contact your Appliance Width...

  • Page 8: Installation

    Note: The optional trim can be pull out directly from the unit. It will need two person to do it. The rough wall opening size of the fireplace. W(＂) D(＂) H(＂) VISTA-BI-50-12 VISTA-BI-60-12 73 1/2 VISTA-BI-72-12 4. Insert the fireplace into the wall opening.

  • Page 9: Hard- Wire Installation

    HARD- WIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring.

  • Page 10: Media Options

    Media Options Shipped with salt,sable and 11 pieces log set. Fire Glass Media-Log Installation 1. Take off the front clear glass. There is a bracket which hold the front glass.It is show as below. Unscrew the screw and take off the bracket. Turn around and insert to the gap.

  • Page 11: Operation

    OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1. The main power ON/OFF switch in position O, the fireplace is OFF. 2.
  • Page 12 REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and mains power switch located on the bottom left hand side is at position I. When operating the remote make sure you point the remote to the centre of the fireplace and make sure each time you press the button.

  • Page 13: Installing Wall Thermostat

    INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING(24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. Turn off circuit breaker. 2. Remove cover plate located on the left side of appliance. Pull the wire out and cut the inside thermostat.

  • Page 14: Replacement Parts

    REPLACEMENT PARTS This list contains replacement parts DESCRIPTION VISTA-BI-50-12 VISTA-BI-60-12 VISTA-BI-72-12 602030C 602030C 602030C BLOWER AND HEATER ASSEMBLY FIREPLACE BOX 10104010 10104010 10104010 SWITCH 601032B 601032B 601032B CONTROL PANEL 601097 601097 601097 CIRCUIT BOARD 10101201C 10101201C 10101201C FLAME MOTOR 3057503...

  • Page 15: Exploded View

    EXPLODED VIEW...

  • Page 16: Trouble Shooting

    TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns Appliance...

  • Page 17: Service History

    SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...

  • Page 18: Warranty

    Should a product or part covered by this limited warranty be proven to be defective, in material or workmanship, and during the one (1) year limited warranty period, Sierra Flame will replace such defective product or part without charge. If Sierra Flame is unable to replace such product, or if replacement is not commercially practicable or cannot be timely done, in its sole discretion Sierra Flame may, in lieu of replacement, choose to refund the purchase price for such product or part.

This manual is also suitable for:

Vista-bi-60-12Vista-bi-72-12
