KD-HD16x16ProK
Key Digital
®
, led by digital video pioneer Mike Tsinberg,
develops and manufactures high quality, cutting-edge
16 Inputs to 16 Outputs HDBaseT/HDMI via Single
technology solutions for virtually all applications where
CAT5e/6 Matrix Switcher, supports Ultra HD/4K,
high quality video imaging is important. Key Digital
®
includes 16 HDBaseT/HDMI Receiver Extenders
is at the forefront of the video industry for Home Theater
Retailers, Custom Installers, System Integrators,
Operating Instructions
Broadcasters, Manufacturers, and Consumers.
The Experts in Digital Video Technology and Solutions
™
Key Digital
®
Systems
::
521 East 3rd Street
::
Mount Vernon, NY 10553
Phone
:
914.667.9700
Fax
:
914.668.8666
Web
:
www.keydigital.com
Advertisement
Table of Contents
Related Manuals for Key Digital KD-HD16x16ProK
Summary of Contents for Key Digital KD-HD16x16ProK
- Page 1 16 Inputs to 16 Outputs HDBaseT/HDMI via Single technology solutions for virtually all applications where CAT5e/6 Matrix Switcher, supports Ultra HD/4K, high quality video imaging is important. Key Digital ® includes 16 HDBaseT/HDMI Receiver Extenders is at the forefront of the video industry for Home Theater...
-
Page 2: Table Of Contents
RS-232 and TCP/IP Commands ..........10 Signal Extension: › Regular Mode: Up to 400 ft. @ 4K/60/30/24, 1080p/60/24, 1080i, 720p using Key Digital ® »... -
Page 3: Quick Setup Guide
3. Connect display devices via the RJ45 outputs and included KD-X16x16RX extenders. Mounting: 4. Connect power to the KD-HD16x16ProK as well as to all other input and output devices and turn them on. Rack mount: Secure the rack ears to each side of the KD-HD16x16ProK with the supplied 5. -
Page 4: Connections, Buttons And Leds
Connections, Buttons and LEDs Front Panel Connections: Rear Panel Connections: LCD Screen Outputs All connections to the KD-HD16x16ProK are found on the rear panel of the unit. Refer to the illustrations below for port assignments while making connections: Control Buttons Optical IR Inputs 16 output buttons on the top-right of the front panel ›... - Page 5 Example: To set output 16 to input 05, press OUT 1, OUT 6, IN 0, IN 5 or OUT 1, OUT 6, IN 5 The KD-HD16x16ProK has a built-in library of 15 EDID settings and the ability to copy EDID data (note: “OUT 0”...
-
Page 6: Extending Control Signals
› Connect the 3.5mm cable from your powered IR connecting block or master controller, › Each extender has an IR sensor to send IR control signals back to the KD-HD16x16ProK › to the “IR In” port. 3 Pin Dip Switch Connect your IR emitter to the “IR Out”... -
Page 7: Rs-232 And Tcp/Ip Commands
RS-232 and TCP/IP Commands Network Setup (TCP/IP Port) The KD-HD16x16ProK provides access to all functions when used with an RS-232 control system. SPCETIPA xxx.xxx.xxx.xxx Set IP Address xxx.xxx.xxx.xxx; xxx = 000 ~ 255 Connection protocol is as follows: Example: SPCETIPA 192.168.000.239... -
Page 8: Firmware Update
Factory Reset ‘SPCDF’: Reset the unit to factory default settings. TCP/IP Settings The KD-HD16x16ProK does not support DHCP. TCP/IP settings can only be changed via IP. Follow the Network Setup commands above to configure your unit’s network settings. Default TCP/IP Settings: IP Address: 192.168.0.239... -
Page 9: Specifications
KD-HD16x16ProK Dimensions: 17” x 13.3” x 5.1”, Weight: 16.5 lbs » Damage to the power supply or power plug » KD-HD16x16ProK Shipping Dimensions: 22.8” x 19.4” x 9.2”, Weight: 25 lbs » Exposure to rain or moisture » KD-X16x16Rx Dimensions: 5.9” x 3.1” x 0.9”, Weight: 0.6 lbs »... -
Page 10: How To Contact Key Digital
® Phone: 914-667-9700 › E-mail: tech@keydigital.com › Repairs and Warranty Service Should your product require warranty service or repair, please obtain a Key Digital ® Return Material Authorization (RMA) number by contacting us at: Phone: 914-667-9700 › E-mail: rma@keydigital.com ›...
