KD-4x4CSA
KD-8x8CSA
4/8 Inputs to 4/8 Outputs HDMI Matrix Switchers
with Audio De-embedding of Analog L/R
Balanced/Unbalanced & Digital Coaxial Audio,
supports Ultra HD/4K & HDCP 2.2
Operating Instructions
KD-4x4CSA
KD-8x8CSA
The Experts in Digital Video Technology and Solutions
™
Advertisement
Related Manuals for Key Digital KD-4x4CSA
Summary of Contents for Key Digital KD-4x4CSA
- Page 1 ® develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where KD-4x4CSA high-end video and control are important. Key Digital ® is at the forefront of the video industry for Home Theater Retailers, Custom Installers, System Integrators, Broadcasters, Manufacturers, and Consumers.
-
Page 2: Table Of Contents
About KD-4x4CSA/KD-8x8CSA ........ -
Page 3: Application Example
Application Example Quick Setup Guide Step 1: Find a safe and convenient location to mount or place KD-4x4CSA/KD-8x8CSA unit › Step 2: Begin with the KD-4x4CSA/KD-8x8CSA unit and all input/output devices turned off with › HDMI power cables removed RJ45... -
Page 4: Connections, Buttons And Leds
Pass-Through Pass-Though Rear Panel Connections: Multi-Channel PCM MUTE MUTE All connections to the KD-4x4CSA/KD-8x8CSA are found on the rear panel of the units. Refer to the illustrations below for port assignments while making connections. Dolby DTS MUTE Pass-Though Serial IR... -
Page 5: Settings And Adjustments
Matrix Switching Resetting to Factory Default The Key Digital IR Remote is required to change the selected input to an output of the KD- To reset your KD-4x4CSA unit to factory default, please follow these steps: 4x4CSA/KD-8x8CSA unit. Please press the following sequence on the Key Digital IR Remote to Press and hold the Output 1 button and the Output 4 button on the front panel for 10 »... -
Page 6: Communication Protocol
Communication Protocol The KD-4x4CSA/KD-8x8CSA allows control over serial interface for bi-directional communication. -- Audio Output Setup Commands: xx = [01-04,A], [E=Enable, D=Disable] -- SPO xx AA E/D : Enable/Disable External Analog Audio Output In addition to RS-232, the serial interface may also be accessed using a TCP/IP connection -- SPO xx DA E/D : Enable/Disable External Digital Audio Output (Default IP address is 192.168.0.239 with default port 23). -
Page 7: Specifications
Wired IR: modulated IR signal input, 0-5V TTL or -10to +10V, 3.5mm mono female connector with › 1. Read and follow all instructions. signal on tip 2. Heed all warnings. Power: External Power Supply – (KD-4x4CSA) 12V/2A, (KD-8x8CSA) 12V/5A › 3. Do not use this device near water. General: 4. Clean only with dry cloth. -
Page 8: How To Contact Key Digital
