Function Instruction - Modecom MC-2110 User Manual

MULTIMEDIA SPEAKER SYSTEM

Function Instruction

Front View of the Subwoofer
VOLUME CONTROL
Adjust the speaker system's volume, turn the volume control anti-
clockwise to minimum, adjusting the volume control to your de-
manding level.
Back View of the Subwoofer
1. AUDIO INPUT
Stereo signal input (2 RCA)
2. AUDIO OUTPUT
Stereo signal output (2 RCA)
3. BASS CONTROL
Turn the bass control anti-
clockwise to minimum, ad-
justing the bass control to
your demanding level
4. POWER CORD
5. POWER
Press the switch ON or OFF
6. FUSE
7. HEAT SINK
