4.1 Control/display board

4.1.1

Version with display:

3 digits
27 LEDs: 26 red, one bicolour (red and green)
9 buttons
Version without display:
26 LEDs: 25 red, one bicolour (red and green)
8 buttons
SOI/DT 2006-11 dmm
7/39
599 38 47 87
