- Page 1 ALLIANCE 800 TREADMILL OWNER’S MANUAL Model Name ALL800 Serial Number Purchase Date Write down for future reference. Keys Technical Service, (888) 340-0482 KEYS Fitness Products, LP P.O. Box 551239 Dallas, TX 75239-1239 Part# 15-0131...
-
Page 2: Table Of Contents
Table of Contents Information Table of Contents Specification Sheet Important Safety Information Before You Start Warm Up Exercises Assembly, Moving Instructions Power Requirements Console Functions and Descriptions Program and Operating Instructions Program Descriptions and Profiles Belt Adjustments and Tension Change to MPH or Km/H Maintenance Instructions Troubleshooting Guide Error Messages... -
Page 3: Specification Sheet
Specification Sheet Horsepower (Continuous) Display Type Electronics Pre-Set Programs Semi-Custom Programs Power Incline Roller Diameter Cushioned Deck Speed Range Belt Size Side Hand Rails Foot Print Folded Foot Print Warranty Motor Warranty Parts Warranty Labor Warranty Frame 2.0hp 4 Window LCD Push Button 0-12% 1.9”... -
Page 4: Important Safety Information
This treadmill has a user maximum capacity of 250 pounds. The treadmill should only be used on a level surface and is intended for indoor use only. The tread- mill should not be placed in a garage, patio, or near water and should never be used while you are wet. -
Page 5: Before You Start
Remember to take the time to perform the stretching exercises provided to avoid injury. Do not stand on the walking belt while pressing the Power button or Start/Stop button. Always adjust the speed of the treadmill in small increments as this treadmill is capable of high speeds. -
Page 6: Warm Up Exercises
Warm Up Exercises EXERCISE GUIDELINES WARNING! Before beginning this or any exercise program, you should consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. Warming up prepares the body for the exercise by increasing circulation, supplying more oxygen to the muscles and raising body temperature. -
Page 7: Assembly, Moving Instructions
Using extreme caution, move the treadmill to the desired location. To set the treadmill down, place one foot on the center of the base crossbar and carefully lower treadmill onto base in resting position. -
Page 8: Power Requirements
This treadmill can be seriously damaged by sudden voltage changes in your home’s electrical power. Voltage spikes, surges, and noise interference can result from weather conditions or from other appliances being turned on or off. To reduce the possibility of treadmill damage, always use a surge protector (not included) with your treadmill. -
Page 9: Console Functions And Descriptions
Console Functions and Descriptions There are four display windows on the control panel to provide feedback information. TIME WINDOW TIME: Indicates elapsed time after pressing start in minutes and seconds (0-99 minutes, 0-59 seconds) INTERVAL TIME: Indicates countdown in seconds to the next interval starting at 5 seconds and counting to 0 seconds SPEED WINDOW SPEED: Indicates MPH (miles per hour) or KMH (kilometer per hour) in .1 increments... -
Page 10: Program And Operating Instructions 10
Program and Operating Instructions QUICK START / MANUAL MODE Plug into a surge protector outlet. Attach the Red Safety Key on to the treadmill console. Stand on the treadmill and straddle belt. Attach safety key clip to your clothes. Press POWER button. There will be an eight (8) second delay after pressing the POWER button before data can be entered. -
Page 11: Program And Operating Instructions 10
Press POWER button. There will be an eight (8) second delay before data can be entered. The TIME window will flash. There are three (3) pre-set and six (6) semi-custom pre-set programs on the ALL800. The treadmill includes FAT BURN, CARDIO, and WARM-UP programs. To select the program press the MODE button until desired program is illuminated on console. -
Page 12: Program Descriptions And Profiles
1 2 3 4 5 6 7 8 9 1 0 The Warm Up Program is designed to gradually increase the treadmill Speed and Elevation in the first segment (warm up) and gradually decrease the treadmill Speed and Elevation in the last segment (cool down). -
Page 13: Belt Adjustments And Tension
WALKING BELT IS SHIFTING TO THE LEFT (Diagram 1) First, turn treadmill on to run at 1 mph. Using the hex key provided, turn the left rear roller adjustment bolt ¼ turn in the clockwise direction. Next, run the treadmill at 2.5 mph. -
Page 14: Change Miles Per Hour To Kilometers Per Hour
All treadmills are calibrated at the factory for British Units (miles per hour). To change the display to read in kilometers, follow the steps described here: 1) Turn power OFF on the console. (Do not unplug treadmill) Attach the magnet safety key to the con- sole. -
Page 15: Maintenance Instructions
CLEANING Routine cleaning of your Keys Fitness treadmill will extend the life of your treadmill. WARNING! To prevent electrical shock, be sure the power to the treadmill is OFF and the unit unplugged from the wall electrical outlet before attempting any cleaning or maintenance. -
Page 16: Troubleshooting Guide
(Refer to “Power Requirements” on page 8) 3 Check the circuit breaker located on the front of the treadmill. If the switch protrudes, it has tripped. Wait five minutes and then press the switch back in. -
Page 17: Error Messages
Safety Interlock Error Messages SI 1 - Safety key missing, replace and try again. SI 2 - Over voltage protection trip. Notify Keys Fitness Technical Service. SI 3 - Tilt Switch Trip. Notify Keys Fitness Technical Service. Other Error Messages E11 - Lack of speed feedback data from belt motor. -
Page 18: Calibration Sequence
Calibration Sequence our treadmill is equipped with a software package that will perform a calibration sequence unique to your specific model number. Please perform the following steps to calibrate the KEYS ALLIANCE 800 TREADMILL. 1. Unplug power cord from outlet strip. -
Page 19: Parts And Diagrams
Parts & Diagrams Please review the following drawing below to familiarize yourself with the listed parts. This man- ual covers several treadmills, so the one pictured below may not be identical to your particular model. L e f t S i d e E x t r u s i o n R a i l R i g h t S i d e E x t r u s i o n R a i l T r e a d m i l l B e l t F r o n t R o l l e r A s s e m b l y... -
Page 20: Warranty Registration (Mail In Form)
Keys. Keys reserves the right to change manufacturers of any part to cover any existing warranty. To obtain warranty service, you must contact a Keys authorized service technician or Keys Fitness at our phone numbers located in this manual. Any parts determined to be defective must be returned to Keys to obtain warranty service.
