- Page 1 ALLIANCE 900/920-OB TREADMILL OWNER’S MANUAL Model Name ALL900/ALL920-OB Serial Number Purchase Date Write down for future reference. Keys Technical Service, (888) 340-0482 KEYS Fitness Products, LP P.O. Box 551239 Dallas, TX 75239-1239 Part# 15-0121...
-
Page 2: Table Of Contents
Information Table of Contents Specification Sheet Important Safety Information Before You Start Warm Up Exercises Assembly, Instructions Power Requirements Console Functions and Descriptions Program and Operating Instructions Program Descriptions and Profiles Belt Adjustments and Tension Change to MPH or Km/H Troubleshooting Guide Parts and Diagrams Warranty Registration (Mail In Form) -
Page 3: Specification Sheet
Specification Sheet Horsepower (Continuous) Display Type Electronics Speed & Incline Toggle Switches Pre-Set Programs Semi-Custom Programs User Programs Heart Rate Funcation Power Incline Roller Diameter Cushioned Deck Speed Range Walking Belt Side Hand Rails Foot Print Folded Foot Print User Capacity Warranty Motor Warranty Deck Belt Warranty Parts... -
Page 4: Important Safety Information
The treadmills have a user maximum capacity of 350 pounds/ALL900, and 400 pounds/ALL920-OB. The treadmill should only be used on a level surface and is intended for indoor use only. The tread- mill should not be placed in a garage, patio, or near water and should never be used while you are wet. -
Page 5: Before You Start
Remember to take the time to perform the stretching exercises provided to avoid injury. Do not stand on the walking belt while pressing the Power button or Start/Stop button. Always adjust the speed of the treadmill in small increments as this treadmill is capable of high speeds. -
Page 6: Warm Up Exercises
Warm Up Exercises EXERCISE GUIDELINES WARNING! Before beginning this or any exercise program, you should consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. Warming up prepares the body for the exercise by increasing circulation, supplying more oxygen to the muscles and raising body temperature. -
Page 7: Assembly Instructions
SUGGESTED YOU ALWAYS USE THE AID OF A SECOND PERSON WHEN MOVING THE TREADMILL. With the treadmill in the folded locked position (safety latch is engaged), grasp the handrails and place one foot on the base as shown in the photo below. Next, with a firm grasp on handrails, place one foot on the center of the base crossbar and carefully tilt the treadmill back until it rolls freely on the wheels. -
Page 8: Power Requirements
This treadmill can be seriously damaged by sudden voltage changes in your home’s electrical power. Voltage spikes, surges, and noise interference can result from weather conditions or from other appliances being turned on or off. To reduce the possibility of treadmill damage, always use a surge protector (not included) with your treadmill. -
Page 9: Console Functions And Descriptions
In Program mode, the treadmill will display the name of the program selected This is shown on the left hand side of the window. In Manual mode, the LAP counter will appear in the top center of the window, counting each 1/4 mile lap in sequence of completion (1, 2, 3, etc.) -
Page 10: Program And Operating Instructions
ENTER QUICK START / MANUAL MODE Plug into a surge protector outlet. Attach the Red Safety Key on to the treadmill console. Stand on the treadmill and straddle belt. Attach safety key clip to your clothes. Press POWER button. There will be an eight (8) second delay after pressing the POWER button before data can be entered. -
Page 11: Program And Operating Instructions 10
INCLINE PROGRAM MODE Plug treadmill into a surge protector outlet. Attach the Red Safety Key on to the treadmill console. Stand on the treadmill and straddle belt. Attach safety key clip to your clothes. Press POWER button. There will be an eight (8) second delay before data can be entered. The TIME window will flash. -
Page 12: Program Descriptions And Profiles
1 2 3 4 5 6 7 8 9 1 0 The Warm Up Program is designed to gradually increase the treadmill Speed and Elevation in the first segment (warm up) and gradually decrease the treadmill Speed and Elevation in the last segment (cool down). -
Page 13: Belt Adjustments And Tension
¼ turn in the clockwise direction. Next, run the treadmill at 2.5 mph. You should see the belt start to correct itself by moving back towards the center. Repeat the above procedure until the walking belt is centered. -
Page 14: Change To Mph Or Km/H
All treadmills are calibrated at the factory for British Units (miles per hour). To change the display to read in kilometers, follow the steps described here: 1) Turn power OFF on the console. (Do not unplug treadmill) Attach the magnet safety key to the con- sole. -
Page 15: Troubleshooting Guide
(Refer to “Power Requirements” on page 8) 3 Check the circuit breaker located on the front of the treadmill. If the switch protrudes, it has tripped. Wait five minutes and then press the switch back in. -
Page 16: Parts And Diagrams
Left Side Extrusion Rail Right Side Extrusion Rail Treadmill Belt Front Roller Assembly Rear Roller Treadmill Deck End Cap (L/R) Elevation Motor (acuator) Bottom Motor Pan Small Fan Motor Poly V Belt Motor Hood Cover Top 15&16 Console Assembly Please review the following drawing below to familiarize yourself with the listed parts. This man- ual covers several treadmills, so the one pictured below may not be identical to your particular model. -
Page 17: Warranty Registration (Mail In Form)
Keys. Keys reserves the right to change manufacturers of any part to cover any existing warranty. To obtain warranty service, you must contact a Keys authorized service technician or Keys Fitness at our phone numbers located in this manual. Any parts determined to be defective must be returned to Keys to obtain warranty service.
