- Page 1 Owner’s Manual Questions? Call Us Toll Free Keys Fitness Helpline 1-888-340-0482 Model Name : ST-NB Manufactured Date : PO # : Model Name Decal Location 215-00105 09/06 Rev A ST-NB...
- Page 2 Table of Contents Important Safety Information Assembly Parts List Exploded View Warranty Information...
-
Page 3: Important Safety Information
Advanced: Complete 3 sets of 12 reps DISCLAIMER: Keys Fitness is not responsible for the misuse of any of its products or for any injury sustained while using any Keys Fitness product. The consumer uses any or all of Keys Fitness Products at their own risk. - Page 4 Assembly HARDWARE...
- Page 5 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 1 Connect the Uprights (#2) & (#12) to the Cross Bar (#01) using four Hex bolts M10X75 (#33) and eight D10 washers (#35), two Reinforcement and four M10 aircraft Nut (#36). Insert the Crutch (#3) into the Uprights (#2)&(#12) through rect.
- Page 6 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 2 Attach the back of the Main Frame (#5) to the Cross Bar (#1) with two bolts M10X75 (#33), four D10 Washers (#35) and two M10 air- craft nuts (#36).
- Page 7 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 3 Install the Leg Developer (#7) to bracket of Leg Developer Holder (#11) using one M10X75 Bolt (#32), two D10 Washers (#35), and one M10 aircraft nut (#36), Insert the Roller Foam Tube (#10) halfway into leg developer (#7).
- Page 8 Assembly NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 4 Attach the backrest support (#9) to the pivot on the Main Frame (#5) Align Backrest Pad (#13) to backrest support (#9) and secure with four M6X40 Bolts (#29), and four D6.5 washers (#31). Place the seat pad (#14) on bracket of the Main Frame (#5) and secure with four M6X15 Bolts (#30), and four D6.5 washers (#31).
-
Page 9: Parts List
202-00173 202-00174 202-00175 202-00177 202-00170 202-00171 202-00169 202-00168 ST-NB Parts List Rev B Description CROSS BAR, M-NBB (SILVER) RIGHT UPRIGHT, M-NBB (SILVER) CRUTCH, M-NBB BACKREST ADJ BAR, ST-NBB (NEW GAUGE) MAIN FRAME, M-NBB (SILVER) FRONST BASE FRAME, M-NBB (SILVER) LEG DEVELOPER M-SBA... -
Page 10: Exploded View
Exploded View 10 10... -
Page 11: Warranty
To contact us for customer service or replacement parts, call 1-888-340-0482. CUSTOMER SERVICE If you have any questions regarding this or any Keys Fitness product, or if we may be of assistance in any way, please do not hesitate to call our toll free number 1-888-340-0482. - Page 12 Keys Fitness Products, L.P. 4009 Distribution Drive, Suite 250 Garland, Texas 75041 Customer Service: 1-888-340-0482...
