- Page 1 Owner’s Manual INVERSION TABLE Customer Service 1.888.340.0482 Keys Fitness 4009 Distribution Drive Suite 250 Garland, TX 75041 www.keysfitness.com Read all precautions and instruc- tions in this manual before using this equipment. 215-00006 08/04 IT-2...
-
Page 2: Table Of Contents
Table of Contents Important Safety Information Before You Start Assembly Operation Exploded View Parts List Warranty 5-10 11-12... -
Page 3: Important Safety Information
35 or persons with pre-existing health problems. Read all instructions in this manual before using this product. Keys Fitness assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Start
Before You Start Before use, read instruction manual completely. It is extremely important to set the balance for your proper height and weight before use to avoid injury. Remove footwear before use. (You could slip out of your shoes and cause injury.) Both feet must be placed in the footrest. -
Page 5: Assembly
Assembly Hardware List... - Page 6 Assembly...
- Page 7 Assembly STEP 1 Spread the Front Support (1) and Rear Support (2) of the base apart as shown in Figure 1. Carefully push down on the two folding arms until they are fully lock in place. Figure 2 Figure 1 STEP 2 Slide the Nylon Covers (28) onto the top of the base assembly.
- Page 8 Assembly STEP 3 Slide the Adjustable Frame (3) into the tube of the Main Frame (4). Set your desired height using the Black Ball Pen (12) and secure in place with the Knob Bolt 3/4” (14). (Figure 3) Figure 4 Figure 3 Step 4 Insert the Foam Rod (9) through the holes at the...
- Page 9 Assembly Step 5 Insert Front Adjustable Frame (5) into the top of the Adjustable Frame (3). Pull the rope down and hook the end of the spring onto the Hex Bolt M6*48mm (33) as shown in Figure 5b. Figure 5a Figure 5b...
- Page 10 Assembly Step 6 Slide a Pivot Arm (7) into each brace located on the left and right side of the Main Frame (4). Carefully set Unit A into the notches at the top of Unit B. Connect the Long Strap (30) to the Short Strap (29) as shown in Figure 6b.
-
Page 11: Operation
Operation NYLON STRAPS: The straps have been included to restrict the angle of the inversion. PIVOT ARMS: The pivot arms also allow for a greater or lesser inversion degree. To adjust the position simply pull out on the pivot arm until the post is out of the hole. -
Page 12: General Precautions
1. Make sure there is enough room for the inversion table to rotate completely. 2. Keys Fitness recommends you have someone with you while you use the machine for the first few times. 3. Make sure the Adjustable Frame is properly set to your height and secured by the Black Ball Pen and the Knob Bolt. -
Page 13: Exploded View
Exploded View... -
Page 14: Parts List
Parts List REF# KEYS PART# DESCRIPTION IT-2 PARTS LIST 223-00570 FRONT SUPPORT 223-00571 REAR SUPPORT 223-00572 ADJUSTABLE FRAME 223-00573 MAIN FRAME 219-00260 FRONT ADJUSTABLE FRAME 219-00261 FOOT FRAME 219-00262 CONNECT BUSHING 219-00263 SIDE ADJUSTABLE FRAME 219-00264 FOAM ROD 219-00265 FOOT FORM BRACKET 210-00080 HOOK 210-00081... -
Page 15: Warranty
Product. To obtain warranty service, you must contact a Keys authorized retailer, service technician or Keys Fitness at our phone numbers located in this manual. Any parts determined to be defective must be returned to Keys to obtain warranty service. You must prepay any shipping charges, export taxes, custom duties and taxes, or any other charges associated with transportation of the parts or Product. - Page 16 Customer Service 1.888.340.0482 Keys Fitness 4009 Distribution Drive Suite 250 Garland, TX 75041 www.keysfitness.com...
