Installation Guidelines; Removing And Replacing The Blower Modules; Required Tools And Equipment; Upper And Lower Blower Module Orientation - Cisco 12016 Replacement Instructions Manual

Blower module and air filter for cisco 12016, cisco 12416, and cisco 12816 router
Hide thumbs

Advertisement

Installation Guidelines

Installation Guidelines
The blower modules support online insertion and removal (OIR), so you can remove and install a blower
module while the system remains powered on without presenting an electrical hazard or damage to the
system. You can replace a blower module while the system maintains all routing information and ensures
session preservation.
Although the blower module supports OIR and can be replaced without interruption to system operation,
Caution
the system should not operate without a blower module for more than 3 minutes to prevent overheating.
Caution
You cannot mix blower types within the chassis. If you are replacing a blower module from an old system
(GSR16-BLOWER=) , you must replace both upper and lower blower modules with new, higher capacity
replacement blowers (12000/10/16-BLWER=). Although the blower modules can be replaced without
interruption to system operation, the system should not operate with mixed blower modules in the router
for more than 5 minutes.

Required Tools and Equipment

You need the following tools and equipment to install the blower module:

Removing and Replacing the Blower Modules

This section contains the procedure to remove and replace the upper or lower blower modules from the
chassis. Before beginning either of these procedures, be sure to read the
on page

Upper and Lower Blower Module Orientation

Illustrations in this procedure show the removal and replacement of the upper blower module. The
procedure to replace the lower blower module is the same except for the orientation of the blower
module.
Cisco 12016, Cisco 12416, and Cisco 12816 Router Blower Module and Air Filter Replacement Instructions
4
Number 2 Phillips screwdriver
3/16-inch flat-blade screwdriver
An electrostatic discharge (ESD) preventive wrist or ankle strap with connection cord
Vacuum cleaner (to clean the air filters)
4.
Heads-up orientation—Install the blower module in the upper bay in the "heads-up" orientation with
the three fan air intake openings face down.
Heads-down orientation—Install the blower module in the lower blower module bay in the
"heads-down" orientation with the three fan air intake openings face up.
"Installation Guidelines" section
