• The configuration of your watch may differ somewhat from that shown in the illustration.
To set the day
1. Pull the crown out to the first click.
2. Set the day by rotating the crown.
3. Push the crown back in to the normal position.
• Avoid changing the date setting while the current time is between 9:00 p.m. and
1:00 a.m.
Using the Stopwatch
Stopwatch minutes
(2 minutes)
Stopwatch hours
(3 hours)
Stopwatch seconds
(37 seconds)
The stopwatch lets you measure elapsed time up to 4 hours, 59 minutes,
59.95 seconds.
To measure elapsed time
1. Press B to enter the Stopwatch Mode.
2. Press A to start the stopwatch.
3. Press A to stop the stopwatch.
• You can resume the measurement operation by pressing A again.
4. Check the elapsed time.
• The example above shows an elapsed time of 3 hours, 2 minutes,
37.80 seconds.
• Press B to reset the stopwatch.
To return the function of the stopwatch 1/20 second hand to the timekeeping
second hand (indicating the current seconds count), press B again. This will enter
the Timekeeping Mode.
• If the starting positions of the stopwatch second hand and 1/20 second hand
become misaligned, use the following procedures to adjust the position of the
stopwatch second hand so it points to 12 o'clock and the 1/20 second hand so it
points to .0 when the stopwatch is reset.
To adjust the positions of the stopwatch hands
1. Press B to reset the stopwatch, and check the alignment of the stopwatch second
hand and 1/20 second hand.
2. Pull out the crown to the second click.
3. Press A to move the stopwatch second hand.
4. If the stopwatch 1/20 second hand is aligned correctly, proceed to step 5. If the
stopwatch 1/20 second hand is also misaligned, press B to move the stopwatch
1/20 second hand.
5. After making the adjustments you want, push the crown back in to its normal position.
• Note that pulling the crown out also stops the timekeeping second hand. After
performing the above procedure, you should also adjust the timekeeping setting.
I For a watch with an elapsed time bezel
Rotate the elapsed time bezel to align the
minute hand.
After certain amount of time elapsed, read the graduation on
the elapsed time bezel which the minute hand points to.
The elapsed time is indicated.
• Some water resistant models are equipped with a screw lock
• With such models, you must unscrew the crown in the
direction noted in the illustration to loosen it before you can
pull it out. Do not pull too forcibly on such crowns.
• Also note that such watches are not water resistant while
their crowns are loosened. Be sure to screw the crowns back
in as far as they will go after making any setting.
Accuracy at normal temperature: ± 20 seconds a month
Display: 3 analog hands (timekeeping hour and minutes, stopwatch seconds),
4 dials (timekeeping 24-hour, timekeeping seconds/stopwatch 1/20 second,
stopwatch hours, stopwatch minutes), day
Stopwatch function: Measuring capacity: 4:59'59.95''
Measuring unit: 1/20 second
Measuring mode: Elapsed time
Battery: One silver oxide battery (Type: SR927W)
Approximately 2 years on type SR927W
Operation Guide 5183
To set the time
1. Pull the crown out to the second
First click
• At this time, the second hand will
(Setting day)
move to 60 (0) (reset position)
and stop there.
2. Set the hands by rotating the
crown. Rotate the crown to move
the hands clockwise. Move the
Second click
minute hand four or five minutes
(Setting time)
past the time you want to set, and
then back it up to the proper
(Normal position)
• Carefully set the time, making
sure to distinguish between AM
and PM.
3. Push the crown back in to the
normal position to restart
Stopwatch 1/20 second
(.8 second)
• This hand moves right and left
to indicate the 1/20 second
count during the first 60
mark with the
Elapsed time bezel
