MA1011-EA
About This Manual
Left Dial Hand
E-2
2. Check the Home City and the daylight saving time (DST) setting.
Use the procedure under "To confi gure summer time and other Home City settings"
(page E-24) to confi gure your Home City and daylight saving time settings.
Important!
Proper World Time setting depends on correct Home City, time, and date settings in
the Timekeeping Mode. Make sure you confi gure these settings correctly.
3. Set the current time.
See "Confi guring Current Time and Date Settings" (page E-27).
The watch is now ready for use.
E-4
E-27 Confi guring Current Time and Date Settings
E-27
To change the current time setting
E-31
To change the current date setting
E-35 Using the Stopwatch
E-36
To perform elapsed time measurement
E-36
To perform an elapsed time operation
E-40 Checking the Current Time in a Different Time Zone
E-41
To view the time in another time zone
E-42
To specify standard time or daylight saving time (DST) for a time
zone
E-44
To swap your Home City and World Time City
E-46 Using the Alarm
E-47
To change the alarm time setting
E-47
To turn the alarm on or off
E-47
To stop the alarm
E-6
Charging the Watch
The face of the watch is a solar cell that generates power from light. The generated
power charges a built-in rechargeable battery, which powers watch operations. The
watch charges whenever it is exposed to light.
Charging Guide
Whenever you are not
wearing the watch, leave
it in a location where it is
exposed to light.
Best charging
performance is achieved
by exposing the watch to
light that is as strong as
possible.
E-8
Operation Guide 5182
Button operations are indicated using the letters A
through D shown in the illustration.
Hand Functions
z Hour Hand
x Second Hand
c Minute Hand
v Left Dial Hand:
Indicates the current mode (TM, ST, WT, AL).
b Right Dial Hands: Indicate a time, in 24-hour format,
depending on the current mode.
n 24-hour Hand:
Indicates the current 24-hour timekeeping hour.
m Day
This User's Guide uses numbers shown above to identify
watch hands and indicators.
When wearing the watch,
make sure that its face is
not blocked from light by the
sleeve of your clothing.
The watch may enter a
sleep state (page E-14) if
its face is blocked by your
sleeve even only partially.
Congratulations upon your selection of this CASIO watch.
Note that the product illustrations in this manual are intended for reference only,
and so the actual product may appear somewhat different than depicted by an
illustration.
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any
damage or loss suffered by you or any third party arising through the use of this
product or its malfunction.
Things to check before using the watch
1. Hold down C at least two seconds to enter the Timekeeping Mode, and
then observe the movement of the x x Second Hand.
Is the x Second Hand moving smoothly at one-second intervals?
NO
Is the x Second Hand moving at
two-second intervals or is it stopped
completely?
YES
Power is low. Charge the watch by placing
it in a location where it is exposed to light.
For details, see "Charging the Watch"
(page E-8).
Contents
E-2
About This Manual
E-3
Things to check before using the watch
E-8
Charging the Watch
E-15
To recover from the sleep state
E-16 Mode Reference Guide
E-18
To determine the watch's current mode
E-18
To return to the Timekeeping Mode from any other mode
E-19
To select a mode
E-20
To select a setting mode
E-23 Timekeeping
E-24 Confi guring Home City Settings
E-24
To confi gure summer time and other Home City settings
E-48 Adjusting Home Positions
E-49
To adjust home positions
E-54 Troubleshooting
E-58 Specifi cations
Warning!
Leaving the watch in bright light for charging can cause it to become quite hot.
Take care when handling the watch to avoid burn injury. The watch can become
particularly hot when exposed to the following conditions for long periods.
On the dashboard of a car parked in direct sunlight
Too close to an incandescent lamp
Under direct sunlight
Important!
Keep the watch in an area normally exposed to bright light when storing it for long
periods. This helps to ensure that power does not run down.
Storing the watch for long periods in an area where there is no light or wearing it in
such a way that it is blocked from exposure to light can cause power to run down.
Make sure that the watch is exposed to bright light whenever possible.
ENGLISH
E-1
YES
The watch is charged suffi ciently.
For details about charging, see
"Charging the Watch" (page E-8).
NEXT
Go to step 2.
E-3
E-5
E-7
E-9

Advertisement

Table of Contents
loading

  Summary of Contents for Casio 5182

  • Page 1 Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss suffered by you or any third party arising through the use of this product or its malfunction.
  • Page 2: Mode Reference Guide

    Operation Guide 5182 Power Levels Level Hand Movement Function Status You can get an idea of the watch’s power level by Normal. All functions enabled observing the movement of the x x Second Hand in the x x Second Hand moves at two-second Timekeeping Mode.
  • Page 3: Confi Guring Home City Settings

    Operation Guide 5182 x x Second Hand moves to 1 o’clock, indicating the Home Setting Modes City Setting Mode. See “To confi gure summer time and The watch has a number of setting modes that you can use to confi gure its settings. In the Timekeeping Mode, hold down A until the setting mode you want is selected as other Home City settings”...
  • Page 4: Using The Stopwatch

    Operation Guide 5182 A to return to regular To change the current date setting After the time setting is the way you want, press timekeeping. A as shown under “Setting Modes” This will cause the x x Second Hand to move automatically to 12 o’clock and (page E-20) to enter the “Time Setting”...
  • Page 5: Checking The Current Time In A Different Time Zone

    Operation Guide 5182 Checking the Current Time in a Different Time Zone To view the time in another time zone C to rotate the v v Left Dial Hand until WT is located next to the pointer ( ). You can use the World Time Mode to view the current time in one of 29 time This indicates the World Time Mode.
  • Page 6: Troubleshooting

    Operation Guide 5182 Each press of C in the home position adjustment mode will cycle through the v v Left Dial Hand is in the After confi rming that the correct home position, press C. This will switch to adjustment settings as shown below.
  • Page 7 Operation Guide 5182 City Code Table City Code Table UTC Offset/ UTC Offset/ City Code City City Code City GMT Differential GMT Differential PAGO PAGO (PPG) Pago Pago –11 JEDDAH (JED) Jeddah HONOLULU (HNL) Honolulu –10 TEHRAN (THR) Tehran +3.5...
