Casio 5333 Operation Manual

MA1301-EA
Your watch may differ somewhat from the one shown in the illustration.
Second Hand
Stopwatch Second Hand
In the above sample illustration, the stopwatch shows an elapsed time of
20 minutes and 41.19 seconds.
Stopwatch functions
To adjust the time setting
When the second hand is at
12 o'clock, pull the
Crown
Click 2.
Rotate the Crown to change the
time setting.
Push the back in.
Crown
Note
Take care that you set the correct AM
or PM time.
When changing the time, move the
minute hand four or fi ve minutes past
your fi nal setting, and then back it up
to the setting you want.
Using the Stopwatch
The stopwatch measures elapsed time in 1/100-second increments up to
39 minutes, 59.99 seconds.
Elapsed time
A A
Start Stop
Split time
A B
Start Split
Two fi nishes
A B
Start Split
First runner
fi nishes.
Display time of
fi rst runner.
Important!
Do not operate the stopwatch with the crown pulled out.
Note
The stopwatch 1/100-second hand and stopwatch 1/10-second hand move for
the fi rst three minutes of an elapsed time measurement operation only. After that,
both hands stop at the 0 position.
Stopping the elapsed time operation will cause the two hands to move to
the 1/100-second and 1/10-second positions of the stopped elapsed time
measurement operation. Note, however, that the hands will not move when the
stopwatch is stopped if the cumulative elapsed time exceeds 120 minutes.
The stopwatch minute hand is a 40-minute retrograde dial. Every 40 minutes (at
the 41st or 81st minute), it reverts back to the 1 position.
The stopwatch second hand and stopwatch minute hand move for the fi rst 120
minutes of an elapsed time measurement operation. After that, the second hand
stops at the 0 position while the retrograde minute hand stops at the 40-minute
position.
Demo Mode
The stopwatch is equipped with a Demo Mode that you can activate by resetting
the stopwatch to all zeros, and then holding down the B button for at least two
seconds.
This will cause the stopwatch 1/100-second hand, stopwatch 1/10-second hand,
and stopwatch second hand to start moving at high speed. The stopwatch minute
hand will move back and forth between 0 and 40 minutes. Hand movement will
stop and the watch will exit the Demo Mode after about three seconds.
To stop hand movement and exit the Demo Mode manually, press the A or B
button.
Operation Guide 5333
Stopwatch 1/100-second Hand
Stopwatch 1/10-second Hand
Hour Hand Minute Hand
Click 1
A
B
Crown
Day Indicator
Stopwatch Minute Hand
To change the day indicator setting
Pull the out to Click 1.
Crown
out to
Rotate the Crown away from you
to set the day.
Push the back in.
Crown
Note
The day indicator setting uses a
31-day month. Make adjustments for
months of shorter lengths.
Avoid changing the day indicator
setting between the hours of 9 p.m.
and 1 a.m. Otherwise, the day
indicator may not change correctly
at midnight.
A A
Re-start Stop
B A
Split release Stop
A B
Stop Split release
Second runner Display time of
fi nishes. second runner.
Correcting the 0 Positions of the Hands
Perform the following procedure if the stopwatch hands do not return to their
0 (zero) positions when you reset the stopwatch.
Operational Flow
Use the A button to select the hand whose zero position you want to correct.
Each time you hold down A for about two seconds in the following procedure, it
cycles to the next hand to be corrected.
Use the B button in the following procedure to correct the 0 position of the
currently selected hand. Holding down B moves the current hand at high speed.
Click 2
Pull the
Crown
Hold down A for about two seconds. The
and
Stopwatch 1/10-second Hand
hand and 1/10-second hand setting mode.
If the hands do not align with the 0 position, use the B button to adjust them.
Hold down A for about two seconds, the
rotate to indicate the second hand setting mode.
If the hand does not align with the 0 position, use the B button to adjust it.
Hold down A for about two seconds, the
to indicate the minute hand setting mode.
If the hand does not align with the 0 position, use the B button to adjust it.
After all of the hands are the way you want, push the
Important!
Timekeeping stops while the crown is pulled out. Correct the current time setting
after performing the above operation.
Required Operation after Battery Replacement or Whenever the
Hand Movement is Not Normal
Perform the operation below after having the watch's battery replaced or whenever
hand movement seems to be abnormal.
Pull the
Crown
Hold down the A and B button at the same time for at least two seconds.
Push the Crown
The second hand should be moving normally at one-second intervals.
Important!
Timekeeping stops while the crown is pulled out. Correct the current time setting
after performing the above operation.
B
Reset
B Crown Operations
Some water-resistant models (100 meters, 200 meters)
Reset
have a screw-in crown. When you need to perform a crown
operation, rotate it towards you to unscrew it. Then pull the
crown out. Avoid applying undue force when pulling. The watch
B
loses its water resistance while the crown is unscrewed. After
performing a crown operation, fully screw the crown back in.
Reset
If your watch has a rotary bezel...
You can rotate the bezel to align its ▼ mark with the
minute hand. Then you will be able to tell how much
time has elapsed since aligning the ▼ mark.
Specifi cations
Accuracy: ±20 seconds average per month
Stopwatch: Measuring Capacity: 39'59.99" (40 minutes)
Measuring Unit: 1/100 second
Measurements: Elapsed time; split time; two fi nishes
Battery: One silver oxide battery (Type: SR927W)
Battery Life: Approximately 3 years (2 hours stopwatch operation per day)
Low Battery Indicator: Second hand moves in 2-second increments when power is
out to Click 2.
Stopwatch 1/100-second Hand
will rotate to indicate the 1/100-second
Stopwatch Second Hand
Stopwatch Minute Hand
Crown
out to Click 2.
back in.
Current
low.
will
will rotate
back in.
Crown
Loosen
Start
Elapsed time
