© 2012 CASIO COMPUTER CO., LTD.
MO1212-EA
About This Manual
Depending on the model of your watch, digital display text appears
either as dark fi gures on a light background, or light fi gures on a dark
background. All examples in this manual are shown using dark fi gures
on a light background.
Button operations are indicated using the letters shown in the
illustration.
Note that the product illustrations in this manual are intended for
reference only, and so the actual product may appear somewhat
different than depicted by an illustration.
E-2
Contents
E-2
About This Manual
E-3
Things to check before using the watch
E-7
Mode Reference Guide
E-12 Timekeeping
E-13 Confi guring Home City Settings
E-13
To confi gure Home City settings
E-14
To change the daylight saving time (summer time) setting
E-15 Confi guring Current Time and Date Settings
E-15
To change the current time and date settings
E-18 Hand Home Position Adjustment
E-18
To adjust home positions
E-20 Using the Digital Compass
E-20
To perform a digital compass operation
E-23
To perform bidirectional calibration
E-25
To perform magnetic declination correction
E-26
To store a direction angle reading in Bearing Memory
E-30
To set a map and fi nd your current location
E-31
To fi nd the bearing to an objective
E-32
To determine the direction angle to an objective on a map and head in that direction
(Bearing Memory)
E-4
E-47 Illumination
E-47
To turn on illumination manually
E-47
To change the illumination duration
E-49
To enable or disable the auto light switch
E-51 Button Operation Tone
E-51
To enable or disable the button operation tone
E-52 Troubleshooting
E-56 Specifi cations
E-6
Operation Guide 5303
Congratulations upon your selection of this CASIO watch.
Applications
This watch has built-in sensors that measure direction and temperature.
Measurement results are indicated by the watch's hands and digital displays. These features make this
watch useful when hiking, mountain climbing, or when engaging in other such outdoor activities.
The measurement functions built into this watch are not intended for taking measurements that
require professional or industrial precision. Values produced by this watch should be considered
as reasonable representations only.
When engaging in mountain climbing or other activities in which losing your way can create a
dangerous or life-threatening situation, always use a second compass to confi rm direction readings.
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss
suffered by you or any third party arising through the use of this product or its malfunction.
Things to check before using the watch
1. Check the Home City and the daylight saving time (DST) setting.
Use the procedure under "To confi gure Home City settings" (page E-13) to confi gure your Home City and
daylight saving time settings.
Important!
Proper World Time Mode data depends on correct Home City, time, and date settings in the
Timekeeping Mode. Make sure you confi gure these settings correctly.
2. Set the current time.
See "Confi guring Current Time and Date Settings" (page E-15).
The watch is now ready for use.
E-35 Taking Temperature Readings
E-35
To take temperature readings
E-37
To calibrate the temperature sensor
E-38 Specifying Temperature Unit
E-38
To specify the temperature unit
E-39 Using the Stopwatch
E-39
To enter the Stopwatch Mode
E-39
To perform an elapsed time operation
E-39
To pause at a split time
E-40
To measure two fi nishes
E-41 Checking the Current Time in a Different Time Zone
E-41
To enter the World Time Mode
E-41
To view the time in another time zone
E-42
To specify standard time or daylight saving time (DST) for a city
E-43
To swap your Home Time and World Time Cities
E-44 Using the Alarm
E-44
To enter the Alarm Mode
E-45
To set an alarm time
E-45
To test the alarm
E-46
To turn an alarm and the Hourly Time Signal on and off
E-46
To stop the alarm
Mode Reference Guide
Your watch has 6 "modes". The mode you should select depends on what you want to do.
To do this:
View the current date in the Home City
Confi gure Home City and daylight saving time (DST) settings
Confi gure time and date settings
Determine your current bearing or the direction from your current
location to a destination as a direction indicator and angle value
Determine your current location using the watch and a map
Determine the temperature at your current location
Use the stopwatch to measure elapsed time
View the current time in one of 48 cities (31 time zones) around the globe World Time Mode
Set an alarm time
Warning!
Enter this mode:
Timekeeping Mode
Digital Compass Mode
Thermometer Mode
Stopwatch Mode
Alarm Mode
ENGLISH
E-1
E-3
E-5
See:
E-12
E-20
E-35
E-39
E-41
E-44
E-7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5303 and is the answer not in the manual?

Questions and answers

Summary of Contents for Casio 5303

  • Page 1 • Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss suffered by you or any third party arising through the use of this product or its malfunction.
  • Page 2: Confi Guring Home City Settings

    Operation Guide 5303 Selecting a Mode • The mode pointer indicates the watch’s current mode. • The illustration below shows which buttons you need to press to navigate between modes. To return to the Timekeeping Mode from any other mode, hold down D for about two seconds.
  • Page 3: Hand Home Position Adjustment

    Operation Guide 5303 2. Press D to move the fl ashing in the sequence shown below to select the other settings. 4. After all of the settings are the way you want, press A to exit the setting screen. Note...
  • Page 4 Operation Guide 5303 2. Place the watch on a level surface facing any direction you want, and press C to calibrate the fi rst To perform magnetic declination correction 1. In the Digital Compass Mode, hold down A. direction. Magnetic declination direction Magnetic declination direction •...
  • Page 5: Taking Temperature Readings

    Operation Guide 5303 To determine the direction angle to an objective on a map and head in that direction (Bearing Memory) 3. In any mode (except a setting mode), press C to take a digital North North Bearing Memory Bearing Memory 1.
  • Page 6: Checking The Current Time In A Different Time Zone

    Operation Guide 5303 To measure two fi nishes Checking the Current Time in a Different Time Zone You can use the World Time Mode to view the current time in one of 31 time zones (48 cities) around the globe. The city that is currently selected in the World Time Mode is called the “World Time City”.
  • Page 7: Button Operation Tone

    If ERR disappears after about one second, try performing the calibration again. circuitry. When this happens, ERR (error) will appear on the lower display and sensor operations will be • If ERR keeps appearing, contact your original dealer or nearest authorized CASIO distributor to have disabled. the watch checked.
  • Page 8: Specifications

    Operation Guide 5303 Specifi cations Stopwatch: Measuring unit: 1/100 second Measuring capacity: 23:59' 59.99" Accuracy at normal temperature: ±15 seconds a month Measuring modes: Elapsed time, split time, two fi nishes Digital Timekeeping: Hour, minutes, seconds, p.m. (P), month, day, day of the week...
