Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 225 lbs.
This Product is Produced Exclusively by
2040 N. Alliance, Springfield, MO 65803
www.staminaproducts.com
Customer Service
1 (800) 375-7520
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: 45-0901
STAMINA PRODUCTS
MADE IN CHINA
©
2010 Stamina Products, Inc.
2010, 09
Advertisement
Table of Contents
Related Manuals for Stamina Calm T901
Summary of Contents for Stamina Calm T901
- Page 1 CAUTION: Weight on this product should not exceed 225 lbs. This Product is Produced Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N. Alliance, Springfield, MO 65803 Customer Service © 2010 Stamina Products, Inc. 1 (800) 375-7520 2010, 09 www.staminaproducts.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Instructions ........2 Storage ............13 Before You Begin ........4 Conditioning Guidelines ......14 Equipment Warning, Caution & Notice Labels ... 5 Warm-Up and Cool-Down ......15 Hardware Identification Chart ....6 Product Parts Drawing ......16 Assembly Instructions ........ -
Page 3: Customer Service
Monday - Thursday, 7:30 A.M. - 5:00 P.M., Central Time. Friday, 8:00 A.M. - 3:00 P.M., Central Time. TELEPHONE ONLINE MAIL CUSTOMER SERVICE CUSTOMER SERVICE CUSTOMER SERVICE STAMINA PRODUCTS, INC. Tel: 1 (800) 375-7520 Fax: (417) 889-8064 customerservice@staminaproducts.com ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071... -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for choosing the Calm® T901 Although Stamina constructs its products with Treadmill. We take great pride in producing this the finest materials and uses the highest standards quality product and hope it will provide many hours... -
Page 5: Equipment Warning, Caution & Notice Labels
EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the Calm® T901 Treadmill. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels. Label is larger than actual size CAUTION LABEL(47) MAINTENANCE DECAL(48) -
Page 6: Hardware Identification Chart
HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed. - Page 8 ASSEMBLY INSTRUCTIONS STEP 3 Connect the LOWER EXTENSION WIRE(24) extending from the top of the LEFT UPRIGHT(2) to the UPPER EXTENSION WIRE(23) extending from the bottom of the U-SHAPED HANDRAIL(4). Push extra wires back into the LEFT UPRIGHT(2). Secure the U-SHAPED HANDRAIL(4) to the LEFT and RIGHT UPRIGHTS(2, 3) with BUTTON HEAD BOLTS(M8x1.25x35mm)(35) and ARC WASHERS(M8)(39).
- Page 9 ASSEMBLY INSTRUCTIONS STEP 4 Insert the LOCKING KNOB(5) through the LEFT UPRIGHT(2) and screw into the hole in the BASE FRAME(1) to lock the BASE FRAME(1) in position. STEP 5 Install two AAA batteries into the METER(21), the batteries are not included. See page 10 for detailed battery installation instructions.
-
Page 10: Operational Instructions
OPERATIONAL INSTRUCTIONS USING THE FITNESS METER POWER ON : Walking Belt movement or press the button. POWER OFF : Automatic shut off after four minutes of inactivity. MODE BUTTON: Press to select display functions, include SCAN, TIME, SPEED, DISTANCE, and CALORIES. Press and hold for three seconds to reset all functions to zero. -
Page 11: Belt Tension
OPERATIONAL INSTRUCTIONS TREADMILL ADJUSTMENTS When adjusted properly, the Calm® T901 Treadmill’s WALKING BELT(14) will roll smoothly around the BOARD(15) and over the front and rear rollers without catching or rubbing. For the belt to run smoothly, there are a few points that need to be noted BELT ALIGNMENT The WALKING BELT(14) must be in the center of the BOARD(15) to prevent it from rubbing against the flywheels. -
Page 12: Maintenance
3. Verify that all nuts and bolts are present and properly tightened. Replace missing nuts and bolts. Tighten loose nuts and bolts. 4. Verify that the CAUTION LABEL(47) is in place and easy to read. Call Stamina Products immediately at 1-800-375-7520 for a replacement CAUTION LABEL(47) if it is missing or damaged. -
Page 13: Storage
STORAGE 1. To store the Calm® T901 Treadmill, simply keep it in a clean dry place. 2. To avoid damage to the electronics, remove the batteries before storing the Calm® T901 Treadmill for one year or more. 3. To fold the Calm® T901 Treadmill for easy storage, follow this process. Refer to the illustrations below. a. -
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs. -
Page 15: Warm-Up And Cool-Down
WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your... -
Page 16: Product Parts Drawing
PRODUCT PARTS DRAWING FRONT Belt Guides BACK... -
Page 17: Parts List
PARTS LIST PART# PART NAME Base Frame Left Upright Right Upright U-Shaped Handrail Locking Knob Front Roller w/ Flywheels Front Shaft Bearing (6201) Bearing Spacer (ø13 x ø16 x 3mm) Rear Roller Bearing Housing Rear Shaft Adjustment Bracket Walking Belt Board Round Cap (38mm) Bumper Stand... -
Page 18: Warranty
To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520. -
Page 19: Fax/Mail Ordering Form
FAX/MAIL ORDERING FORM Please do not return the product. For your convenience, Stamina's Customer Service Department can be reached by email at customerservice@staminaproducts.com or toll free at 1-800-375-7520 (in the U.S.). Should a part be missing or a defective part found, please call us from 7:30 A.M. to 5:00 P.M. Central Time, Monday through Thursday and 8:00 A.M.
