a male and female XLR connector on either end of the cable. Also
remember that DMX cable must be daisy chained and cannot be split.
Notice:
Be sure to follow figures two and three when making your own
DMX512
cables. Do not use the ground lug on the XLR connector. Do not con-
DMX+,DMX-,COMMON
nect the cable's shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR's outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
DMX512 OUT
3-PIN XLR
XLR Male Socket
1 Ground
2 Cold 2 Cold
REMOTE
INPUT OUTPUT
CONTROL
INPUT
3 Hot
Figure 3
Special Note: Line Termination.
POWER
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
Termination reduces signal errors and
avoids signal transmission problems
1 1
DMX512 IN
and interference. It is always advisable
3 3
3-PIN XLR
to connect a DMX terminal, (Resistance
2 2
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
ADJ Products, LLC - www.adj.com - Inno Spot Elite Instruction Manual Page 8
SOUND
POWER
COMMON
DMX +
1 1
DMX512 IN
3 3
3-PIN XLR
DMX -
2 2
XLR Female Socket
XLR Pin Configuration
1 Ground
Pin 1 = Ground
REMOTE
INPUT OUTPUT
SOUND CONTROL
Pin 2 = Data Compliment (negative)
INPUT
3 Hot
Pin 3 = Data True (positive)
When longer runs of cable are
Figure 4
REMOTE
INPUT OUTPUT
CONTROL SOUND
INPUT
Inno Spot Elite
Set Up
5-Pin XLR DMX Connectors.
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
POWER
fixtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Termination reduces signal errors and
avoids signal transmission problems
1
and interference. It is always advisable
3
2 to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
Data Compliment (- signal)
Figure 2
and PIN 3 (DMX +) of the last fixture.
Inno Spot Elite
POWER
With this feature you can connect the fixtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 4 fixtures maximum for 120V and 8 fixtures maxi-
mum for 240V. After the maximum fixtures has been reached you
will need to use a new power outlet. They must be the same fix-
tures. DO NOT mix fixtures.
ADJ Products, LLC - www.adj.com - Inno Spot Elite Instruction Manual Page 9
REMOTE
INPUT OUTPUT
CONTROL
INPUT
Some manufactures use 5-pin DMX-
POWER
3-Pin XLR to 5-Pin XLR Conversion
Conductor 3-Pin XLR Female (Out)
Ground/Shield Pin 1
Pin 2
Data True (+ signal) Pin 3
Not Used
Not Used
Set Up
5-Pin XLR Male (In)
Pin 1
Pin 2
Pin 3
Pin 4 - Do Not Use
Pin 5 - Do Not Use
Power Cord Daisy Chain
