TracVision A5 Instructions Manual

Instructions for Adding One
or Two TracVision
Receivers to a TracVision
A5/M3 System
The following pages explain how to connect a second or third
TracVision A5/M3 12V receiver to the TracVision A5 or
TracVision M3 system. This kit supports the following wiring
configurations:
• Original TracVision A5/M3 12V receiver +
one (1) additional TracVision A5/M3 12V receiver
• Original TracVision A5/M3 12V receiver +
two (2) additional TracVision A5/M3 12V receivers
(requires two second receiver kits (02-1340))
If you need to connect more than two additional receivers, you
will need to purchase a multiple receiver kit (P/N 72-0181) and
an active multiswitch (P/N 19-0123).

Before You Begin

Before you connect your second or third TracVision A5/M3 12V
receiver, be sure to install the original TracVision A5/M3 12V
receiver first and test the system for proper operation, as
described in the Installation Guide. Once you've tested the system
in a single-receiver configuration, follow these instructions to
install your additional receiver(s).

Kit Contents

This expansion kit contains various hardware and other materials
that you will need to install the second or third receiver. Ensure
the box contains all of the items listed in the Contents List.

Connecting the Additional Receiver(s)

The diagrams on the following pages show the basic receiver-to-
receiver wiring for one or two additional TracVision A5/M3 12V
receivers. Refer to these figures when connecting the additional
TracVision A5/M3 12V receiver(s) to your TracVision A5 or
TracVision M3 system.
