TracVision A5 Instructions

TracVision
Remote Control Instructions
The following pages explain how to quickly start using your
replacement TracVision A5 remote control.

Installing the Remote Control Batteries

To install the remote control's batteries, follow the steps below.
1. Remove the battery compartment cover, located on
the back of the remote control.
2. Insert two "AAA"-size batteries as shown,
observing the correct polarity.
3. Replace the battery compartment cover.
Programming the Remote Control to Operate
a Second Receiver (If Applicable)
The replacement remote control is programmed to work with the
receiver that came with your TracVision antenna. If you have a
second receiver installed, and you need to use the replacement
remote control to operate that second receiver (and not the
original receiver), follow the steps below to program the
replacement remote control.
If you will be using the replacement remote control to
operate the original receiver, you do NOT need to
program the remote control.
1. Press and hold the SAT button.
2. At the same time, press the MUTE button for two
seconds.
3. Release both buttons. The SAT button should
remain lit. If it doesn't, repeat Steps 1 and 2.
4. Using the numeric keypad, enter "002".
5. Press the SAT button to lock in the code.
6. Press the SELECT button twice.
7. The remote control should now be programmed to
operate the second receiver.
54-0223 Rev. B
® A5 Replacement
Replacement Remote Control Instructions
PWR
DVD VCR AUX TV SAT
GUIDE
MENU FAV
TURBO
INFO CLEAR
VOL CH P
A
G
E
PREV
MUTE
CH
DIRECTOR
PROG VIDEO
SEARCH AUDIO
1 2 3
4 5 6
7 8 9
0
INPUT
PLAY
REW FF
STOP
REC PAUSE
1
