TracVision
Second Receiver
Installation Instructions
The following pages explain how to connect a second receiver to
the TracVision A5 system.
Before You Begin
Before you connect the second receiver, be sure to install the
original receiver and test the system for proper operation, as
described in the TracVision A5 Installation Guide. Once you've
tested the system in a single-receiver configuration, follow the
instructions below to install the second receiver.
Kitpack Contents
The kitpack that was packaged with your second receiver
contains various hardware and other materials that you will need
to install the receiver. Ensure the box contains all of the items
listed below.
Part
Receiver
Remote control
RF converter
Brackets
#8-32 x
5
⁄
" screws
1 6
#6 x
1
⁄
" self-drilling screws
2
#8 washers
DC power cable
Audio/video cables
AAA batteries
Splitter, RF signal
Short RF cable
Long RF cable
54-0221 Rev. C
®
A5
Part #
02-1287-01
72-0148
02-1344
20-0931
14-0041-65
14-0357-08
14-0226-08
32-0760
32-0763
15-0015
19-0341
32-0753-07
32-0753-72
Second Receiver Installation Instructions
Second Receiver
Serial Number
Qty.
1
1
1
2
4
6
4
1
1
2
1
1
1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TracVision A5
Summary of Contents for TracVision A5
-
Page 1: Installation Instructions
Before you connect the second receiver, be sure to install the original receiver and test the system for proper operation, as described in the TracVision A5 Installation Guide. Once you’ve tested the system in a single-receiver configuration, follow the instructions below to install the second receiver. - Page 2 The diagram on the following page shows the complete wiring of a two-receiver configuration. Refer to this figure when connecting the second receiver to the TracVision A5 system. These instructions are for a basic wiring configuration. If the vehicle’s entertainment system is wired differently, use these instructions as a guide and connect the cables as needed to suit the vehicle’s particular configuration.
- Page 3 Second Receiver Installation Instructions 54-0221 Rev. C...
- Page 4 TracVision A5 8. Follow the instructions in Section 3-2, “Mounting the Receiver,” in the TracVision A5 Installation Guide to mount the second receiver inside the vehicle. 9. Check the cable connections at both receivers to ensure none have come loose. In particular, be sure to inspect the short video cable, connecting between the “To...
- Page 5 Advanced Program Guide ™ is prepared. Installation Searching for satellite signal... The TracVision antenna searches for and locks onto the satellite. The receiver then starts downloading the program guide and the following message appears: ® If your satellite dish is ready for DIRECTV service, please wait until your ™...
- Page 6 (such as channels 100 and 201) are viewable until you activate the second receiver. Activating the Receiver(s) Before you can start watching satellite TV via a TracVision A5 receiver, the receiver must be activated. You will need the second receiver’s serial number to activate it.
- Page 7 TracVision remote control. For details, refer to Section 3-2, “Programming the Remote Control to Operate Other Components,” in the TracVision A5 User’s Guide. Programming a Replacement Remote Control to Operate the Second Receiver To operate the second receiver, you must use a remote control that is programmed with the second receiver’s remote ID.
