Summary of Contents for Monterey 400 Sport

  • Page 3: Welcome

    Dear Valued Customer, Welcome to the Monterey Life! We would like to extend to you our “Thank You” for choosing a Monterey boat! You have made an investment in our product and we are confident you will enjoy many years of boating pleasure. Your new boat has been built to the standards set forth by the United States Coast Guard and National Marine Manufacturers Associa- tion.

  • Page 4: Boat Information

    MONTEREY BOATS Please fill out the following information section and leave it in your Monterey owner’s manual. This information will be important for you and Monterey service personnel to know, if you may need to call them for technical assistance or service.

  • Page 5: Specifications

    SPECIFICATIONS MONTEREY BOATS HULL LENGTH OVERALL ___________________________________________ 41 0” / 12.5 m WEIGHT DRY _______________________________________________ 22,000 lbs / 9,979 kg WEIGHT WITH WATER AND FUEL ______________________________ 26,345 lbs / 1,1950 kg BEAM ____________________________________________________________ 12’ 6” / 3.8 m DEADRISE _______________________________________________________________ 17 DRAFT ____________________________________________________________ 45”...

  • Page 6: Certifications & Specifications

    To be in compliance with European directives for recreational boats as published by the International Organization for Standardization (ISO) in effect at the time this boat was manufactured, we are providing the following information. Manufacturer: Name SEABRING MARINE INDUSTRIES, INC., d.b.a. Monterey Boats Address 1579 SW 18th St. Zip Code: Williston, FL...

  • Page 7: Introduction & Important Information

    REMEMBER - IT IS YOUR RESPONSIBILITY TO ENSURE THAT YOUR BOAT IS SAFE FOR YOU AND YOUR PASSENGERS. Your Monterey Boats Dealer will assist you in fill- ALWAYS EXERCISE GOOD COMMON SENSE WHEN INSTALLING ing in the hull number and other data required on EQUIPMENT AND OPERATING THE BOAT.
  • Page 8 Monterey Dealer. Should a problem lem, then contact Monterey within 15 days. It is develop that is related to faulty workmanship or the boat owner’s responsibility to deliver the materials, as stated in the Limited Warranty, you boat to the dealer for warranty service.

  • Page 9: Warranty

    After three (3) years but up to four (4) years from the date of original retail purchase, MONTEREY BOATS will pay 65% of the repair costs. After four (4) years but up to five (5) years from the date of original retail purchase, MONTEREY BOATS will pay 35% of the repair costs.
  • Page 10 MONTEREY BOATS. This warranty is further subject to the exclusions, limitations, conditions and provisions noted below.
  • Page 11 All general, special, indirect, incidental and/or consequential damages are excluded from this warranty and are totally disclaimed by MONTEREY BOATS. It is the intent of the parties that the Owner’s sole and exclusive remedy is the repair or replacement of the product or its allegedly defective component parts and that no other legal or equitable remedies shall be available to said owner.

  • Page 12: Safety Information

    MONTEREY BOATS Your Monterey owner’s manual has been written to include a number of safety instructions to assure the safe operation and maintenance of your boat. These instructions are in the form of DANGER, WARNING, and CAUTION statements. The following definitions apply:...

  • Page 13: Owner's / Operator's Information

    OWNER’S / OPERATOR’S INFORMATION MONTEREY BOATS Registration and Numbering regarding accident reporting, please call the Boat- Federal law requires that all undocumented ves- ing Safety Hotline, 800-368-5647. sels equipped with propulsion machinery be regis- tered in the State of principal use. A certificate of Education number will be issued upon registering the boat.

  • Page 14: New Boat Delivery

    Final Delivery inspections are documented to ensure trouble free operation and returned to Monterey Boats. At the time of new boat delivery, your Monterey Dealer will ask you to sign the completed Inspection Report at the same time as the Warranty Registrations for the boat and other accessory equipment. By signing these documents, you acknowledge that you have reviewed and understand all information.

  • Page 15: Table Of Contents

    SPECIFICATIONS ..................................5 CERTIFICATIONS & SPECIFICATIONS ............................ 6 INTRODUCTION & IMPORTANT INFORMATION ........................7 WARRANTY ....................................9 MONTEREY BOATS LIFETIME LIMITED WARRANTY......................9 SAFETY INFORMATION ................................12 OWNER’S / OPERATOR’S INFORMATION ..........................13 NEW BOAT DELIVERY ................................14 Chapter 1: PROPULSION SYSTEM 1.1 General ....................................
  • Page 16 TABLE OF CONTENTS MONTEREY BOATS Chapter 5: FRESH WATER SYSTEM 5.1 General ....................................57 5.2 Fresh Water System Operation ............................57 5.3 Water Heater ..................................58 5.4 Shore Water Connection ..............................58 5.5 Shower Operation ................................59 5.6 Fresh Water System Maintenance ............................59...
  • Page 17 TABLE OF CONTENTS MONTEREY BOATS Chapter 11: SAFETY EQUIPMENT 11.1 General ....................................97 11.2 Engine Alarms ..................................97 11.3 Neutral Safety Switch ................................. 97 11.4 Required Safety Equipment ..............................98 11.5 Automatic Fire Extinguishing System ..........................99 11.6 Carbon Monoxide Monitoring System ..........................101 11.7 First Aid ....................................
  • Page 18 TABLE OF CONTENTS MONTEREY BOATS Appendix C: BOATING ACCIDENT REPORT .............................. 139 Appendix D: GLOSSARY OF TERMS ................................143 Appendix E: TROUBLESHOOTING GUIDE ..............................149 ...

  • Page 19: Propulsion System

    MONTEREY BOATS PROPULSION SYSTEM 1.1 General The Monterey 400 Sport Yacht is designed to be powered with Volvo’s Inboard Power System (IPS) and diesel engines. Volvo provides an owner’s in- formation manual with its product. It is important that you read the manual(s) very carefully and become familiar with the proper care and opera- tion of the engine and drive system.

  • Page 20: Engine Cooling System

    This system is standard with all diesel engines on the 400 Sport Yacht. The Diesel and gas engines can be damaged and the engine owner’s manual provides additional infor-...

  • Page 21: Engine And Helm Instrumentation

    ENGINE CAN RESULT IN ENGINE SEIZURE. IF instrumentation is unique to the type of inboard AN UNUSUALLY HIGH TEMPERATURE READING motors installed on your Monterey. Some or all OCCURS, SHUT THE ENGINE OFF IMMEDIATELY. of the following gauges and instruments may be T H E N I N V E S T I G AT E A N D C O R R E C T T H E PROBLEM.
  • Page 22 Propulsion System MONTEREY BOATS Voltmeter The voltmeter displays the voltage for the battery and the charging system. The normal voltage is 11 to 12.5 volts with the engines off, and 13 to 14.5 volts with the engine running. Hour Meter The hour meter keeps a record of the operating time for the engine.
  • Page 23 Propulsion System MONTEREY BOATS Compass The compass is on top of the console. To adjust the compass for your area, read the instructions on “Compass Compensation” given to you in the literature packet. The compass cannot be ad- justed accurately at the factory because it must be compensated for the influence of the electrical equipment and electronics unique to your boat.
  • Page 24 Propulsion System MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...

  • Page 25: Chapter 2: Helm Control Systems

    Chapter 2: MONTEREY BOATS HELM CONTROL SYSTEMS 2.1 General The helm controls consist of three systems: the engine throttle and shift controls, the steering system, and the trim tab control switches. These systems provide the operator with the ability to control the direction and attitude of the boat from the helm station.

  • Page 26: Steering System

    Synchronizing in this section for more information regarding engine synchronization. IPS Electronic Steering System Your Monterey is equipped with an electronic These features and others not mentioned require steering system that is supplied with the IPS en- specific procedures to activate and operate them gine package that provides precise and responsive properly.

  • Page 27: Trim Tabs

    Helm Control Systems MONTEREY BOATS steering system occur, the controlling software will sense the failure and limit the engine RPM as a safety precaution. The failed unit can and should be manually turned to the straight ahead position for improved handling while steering the boat with only one drive.

  • Page 28: Control Systems Maintenance

    Always raise the tabs to the necessary do not attempt to address the problem full bow up position in these conditions. yourself. You should contact your Monterey dealer or Monterey Customer Service for assistance. When running at high speeds be sure that the tabs are in the full “UP”...
  • Page 29 Helm Control Systems MONTEREY BOATS If your boat will be left in the water for extended periods, it will be necessary to monitor the zinc anodes on the trim tab planes that prevent gal- vanic corrosion. Galvanic corrosion is the corro- sion process occurring when different metals are submerged in an electrolyte.
  • Page 30 Helm Control Systems MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...

  • Page 31: Fuel System

    MONTEREY BOATS FUEL SYSTEM 3.1 General The fuel system used in Monterey boats is de- signed to meet or exceed the requirements of the U.S. Coast Guard and the Boating Industry Association in effect at the time of manufacture. All fuel systems have been factory inspected and pressure tested in accordance with regulations in effect at the time of manufacture.

  • Page 32: Diesel Engine Fuel System

    3.2 Diesel Engine Fuel System The fuel system on the 400 Sport Yacht has two fuel tanks, one tank for each engine. Diesel en- gines circulate much more fuel than they consume and there are no selector valves for the supply or return fuel lines.

  • Page 33: Generator Fuel System

    Fuel System MONTEREY BOATS Note: Diesel fuel systems may need to be primed after servicing. Refer to the engine owner’s manual for informa- tion on priming the fuel system. 3.3 Generator Fuel System The generator fuel system is much like the pri- mary engine fuel system.

  • Page 34: Fueling Instructions

    Fuel System MONTEREY BOATS 3.4 Fueling Instructions FUEL IS VERY FLAMMABLE AND CAN CAUSE A FIRE OR EXPLOSION. BE CAREFUL WHEN FILLING THE FUEL TANK. NO SMOKING. NEVER FILL THE TANK WHILE THE ENGINES ARE RUNNING. FILL THE FUEL TANK IN AN OPEN AREA. DO NOT FILL THE TANK NEAR OPEN FLAMES.

  • Page 35: Fuel System Maintenance

    Replace as necessary. Spray the valves, tank fuel gauge senders and ground connections with Please contact your Monterey dealer or engine a metal protector. manufacturer for additional information regarding fuels and additives. Frequently inspect and lubricate the fuel fill cap O-ring seal with Teflon or silicone grease.
  • Page 36 MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...

  • Page 37: Electrical System

    4.1 General the generator. The batteries themselves can be charged by the engines or by the battery charger Your Monterey is equipped with 120-volt AC and when hooked to shore power or when operating 12-volt DC electrical systems. The AC system the generator.
  • Page 38 Electrical System MONTEREY BOATS located in the 12-volt breaker panels in the cabin, “Off” position and then rotated into the “Auto” at the helm and in the breaker panel below the position. Once this has been done, the only time battery switches in the engine compartment.
  • Page 39 Electrical System MONTEREY BOATS Helm Circuit Breaker Panel Located in the Helm Station Below the Steering Wheel to the type of batteries in your boat and do not Note: If battery is fully discharged/dead mix the size, type or brand of marine batteries.
  • Page 40 Electrical System MONTEREY BOATS off/on and momentary start positions. To start the engine, make sure the shift lever is in the neutral position and your hand is on the throttle lever in the idle position. Turn the ignition key to the start position. When the engine starts,...
  • Page 41 Electrical System MONTEREY BOATS Note: Red lights have less effect on night Note: The bilge pumps will start automati- vision and should selected if you need cally when there is sufficient water to illuminate the bridge deck while in the bilge to activate the automatic navigating at night.
  • Page 42 Electrical System MONTEREY BOATS may be on your Monterey and the accessories they control: Trim Tab Switch Located in the helm. This switch controls the trim tabs located on the transom of the boat. Please refer to the Helm Control Systems chapter for detailed information on the operation of the trim tab controls.
  • Page 43 Electrical System MONTEREY BOATS Refer to the bow thruster owner’s manual for details on operating the bow thruster and using the control pad. Automatic Fire Extinguisher Indicator Panel and Override Switch The panel is equipped with lights that indicate the status of the automatic fire extinguishing system.
  • Page 44 Electrical System MONTEREY BOATS Constant Hot and Switched Circuit Breaker Panel Near Battery Switches in Engine Compartment Sump Pump Stereo Memory Provides protection and continuous power for the Provides protection and continuous power for the automatic float switch in the cabin sump pump.
  • Page 45 Electrical System MONTEREY BOATS Cabin DC Breaker Panel Port Charge - Stbd Charge tripped by an overload, a yellow lever near the The wires that supply DC charging current to the center of the breaker will point to the “Off”. Reset...
  • Page 46 Electrical System MONTEREY BOATS house battery circuit. The display is illuminated Cabin Refrigerator for easy night viewing and is controlled by buttons Supplies 12-volt electrical current directly to the on the face of the display. Refer to the owner’s refrigerator in the galley when AC current is not manual included with this manual for detailed being used.

  • Page 47: 120-Volt System

    Electrical System MONTEREY BOATS AC Shore Connections and Circuit Breakers, Phone and TV Connection and Shore Water Connection 4.3 120-Volt System dockside, 120-volt, 60 cycle, AC power should be utilized from dockside power, if available. A cord Boats designed to operate in the United States...
  • Page 48 Electrical System MONTEREY BOATS Recommended procedure for making a shore UNDETECTED FAULTS IN THE AC ELECTRICAL connection: SYSTEM COULD CAUSE THE WATER AROUND Turn the boat inlet AC main breakers, cabin panel THE BOAT TO BECOME ENERGIZED. THIS COULD AC main breakers and all AC accessory breakers CAUSE A SEVERE SHOCK OR EVEN DEATH to the “OFF”...
  • Page 49 Electrical System MONTEREY BOATS Generator Gauges and Monitor Generator Control Panel AC Breaker Panel only), the AC accessories can be activated. If the AC Volt, Amp and Frequency Monitor monitor indicates any voltage other than 120-volts Monitors AC volts supplied to the panel, load amps, or a frequency other than 60 Hz, do not activate AC frequency and Kilowatt load.
  • Page 50 Electrical System MONTEREY BOATS Note: All AC electrical outlets are provided OPERATING THE COMPONENTS OF THE AC with ground fault interrupts to pro- ELECTRICAL SYSTEM FROM A POWER SOURCE tect against electric shock. These THAT IS NOT THE CORRECT VOLTAGE AND/OR...
  • Page 51 Electrical System MONTEREY BOATS The charge to the engine batteries can be moni- tored by using the DC monitor in the cabin DC panel or by using the volt meters in the engine gauge cluster. To monitor the engine batteries with the volt meters, activate the charger and turn the engine battery switches on.

  • Page 52: Generator

    Electrical System MONTEREY BOATS Additional AC Switch Panels and Breakers Shore Power Inlet Breakers Located in the transom inlet connector compart- ment above the shore power inlet plugs. These breakers protect the AC system between the shore power inlet plugs and the cabin AC panel.

  • Page 53: Bonding System

    Electrical System MONTEREY BOATS • Lubricate the seal. a protector. Exterior light fixture bulbs should be removed and the metal contact areas coated with • Reassemble the strainer making sure that all a non-water soluble lubricant like Teflon or silicone fasteners are tight.
  • Page 54 Electrical System MONTEREY BOATS as required. Coating the battery posts and cable Generator Maintenance clamps with Teflon or silicone grease will protect The engine maintenance required on the genera- them and reduce corrosion. tor is similar in many ways to the main engines.

  • Page 55: Ac Line Load Estimator

    Electrical System MONTEREY BOATS 4.7 AC Line Load Estimator require and managing the electrical load on each circuit. An owner’s manual for each AC accessory Depending on the AC power load your boat re- installed on your boat at the factory has been quires and the power available from the shore included with your boat.
  • Page 56 MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...

  • Page 57: Chapter 5: Fresh Water System

    DIESEL FUEL IS ACCIDENTALLY PUMPED INTO THE WATER OR WASTE TANK, DO NOT ATTEMPT TO PUMP IT OUT YOURSELF. CONTACT YOUR DEALER OR THE MONTEREY BOATS CUSTOMER SERVICE DEPARTMENT FOR ASSISTANCE IN HAVING THE FUEL PROFESSIONALLY REMOVED AND COMPONENTS OF THE FRESH WATER SYSTEM REPLACED AS NECESSARY.

  • Page 58: Water Heater

    The shore water connection allows the direct WATER INLET CONNECTOR WITH ANOTHER connection of the water system to a shore side TYPE WITHOUT CONSULTING MONTEREY BOATS water supply. This provides the system with a CUSTOMER SERVICE OR YOUR DEALER. THE USE...

  • Page 59: Shower Operation

    Fresh Water System MONTEREY BOATS 5.5 Shower Operation There is a shower located in each head compart- ment and at the transom on the port side, near the transom door. Each shower has hot and cold water and a retractable shower head with an on/ off valve.
  • Page 60 Fresh Water System MONTEREY BOATS • Add a commercially available potable water conditioner to the water tank to keep it fresh. Note: The freshwater system must be prop- erly winterized prior to winter lay-up. Refer to the section on winterizing for more information.

  • Page 61: Chapter 6: Raw Water System

    15 M.P.H. The water pressure from the scoop will force the trapped air through the pump and allow it to prime. If this procedure doesn’t work, contact your Monterey dealer. Closing the thru-hull ball valves before the boat is hauled from the water will help to eliminate air locks in raw water systems.

  • Page 62: Raw Water System Maintenance

    Raw Water System MONTEREY BOATS 6.3 Raw Water System Maintenance • Thoroughly flush the screen and the inside of the strainer to remove foreign matter. The following items should be done routinely to help maintain your raw water system: •...

  • Page 63: Chapter 7: Drainage Systems

    Chapter 7: MONTEREY BOATS DRAINAGE SYSTEMS 7.1 General Most water is drained by gravity to overboard thru-hull fittings located in the hull sides above the waterline. You should check the drain system frequently to ensure it is free flowing and that the hoses on the thru-hull fittings are secure and not leaking.

  • Page 64: Cockpit And Deck Drains

    Drainage System MONTEREY BOATS whenever the boat is hauled out of the water and installed just prior to launching. It is important to check the drain plug regularly to make sure it is tight. A LOOSE DRAIN PLUG WILL ALLOW SEAWATER TO ENTER THE BILGE AND COULD CAUSE THE BOAT TO SINK.

  • Page 65: Cabin Drains

    Drainage System MONTEREY BOATS tant to inspect the drain frequently to remove any the sinks from draining and could cause damage accumulated debris. to the holding tank. It will also cause unpleasant odors in the cabin. Note: The overboard macerator discharge 7.4 Cabin Drains...
  • Page 66 MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...

  • Page 67: Chapter 8: Ventilation System

    Chapter 8: MONTEREY BOATS VENTILATION SYSTEM 8.1 Cabin Ventilation Ventilation to the cabin area is provided by three deck hatches. Additionally, there is a 12-volt exhaust blower in each head compartment that provides forced ventilation to that area whenever the blower is activated by the switch on the head compartment wall.

  • Page 68: Windshield Ventilation

    Ventilation System MONTEREY BOATS Disconnect the tabs to store the screen and the sunshade or to open and close the hatch. Port Windows Opening port windows are located in V-berth and main salon. Each window opens to provide ven- tilation into the cabin area and is equipped with a removable screen.

  • Page 69: Engine Compartment Ventilation

    While a 8.4 Engine Compartment Ventilation CO detector enhances your protection from CO All Monterey inboard boats are equipped with an poisoning, it does not guarantee it will not occur. engine compartment ventilation system consisting Do not use the carbon monoxide detector as a of intake ducts and exhaust blowers.

  • Page 70: Maintenance

    Ventilation System MONTEREY BOATS breaker panel. The blowers are located in the vent • The opening cabin deck hatches and the cabin hoses on the port and starboard side of the en- door are made of acrylic plastic glass. Acrylic gine compartment.

  • Page 71: Chapter 9: Exterior Equipment

    The anchor line is stored in the rope locker and routed out the locker through the windlass to the roller and connected to the anchor MONTEREY BOATS ARE NOT EQUIPPED WITH chain. A cleat or chain binder is provided on the HARDWARE DESIGNED FOR TOWING PURPOSES.
  • Page 72 The rope locker is not designed for anchor storage and Monterey recommends that extra anchors be stored in a storage compartment as far aft as pos- sible such as below the aft sun island or cockpit lounge seat.
  • Page 73 Exterior Equipment MONTEREY BOATS reset” breaker in the helm switch breaker panel. The main circuit for the windlass is protected by a heavy duty circuit breaker near the engine com- partment breaker panel. After the anchor is set, the windlass must not be left to take the entire force from the anchor line.
  • Page 74 Exterior Equipment MONTEREY BOATS the cushion is properly installed prior to leaving the dock or mooring. The cushion is large and somewhat awkward, making it difficult to install once the boat is underway. If it is not secured properly, the cushion could be caught by the wind and blown overboard or into the cockpit, causing damage to the boat or injury to passengers.
  • Page 75 Exterior Equipment MONTEREY BOATS MOVING PROPELLERS ARE DANGEROUS. THEY CAN CAUSE DEATH, LOSS OF LIMBS, OR OTHER SEVERE INJURY. DO NOT USE THE SWIM PLATFORM OR SWIM LADDER WHILE THE ENGINES ARE RUNNING. STOP THE ENGINES IF DIVERS OR SWIMMERS ARE ATTEMPTING TO BOARD.

  • Page 76: Cockpit

    Exterior Equipment MONTEREY BOATS 9.3 Cockpit No Red Dot General Red Dot Showing Showing Some of the hatches and doors in the cockpit are secured with special flush mounted, twist lock latches with handles that store flush in the latch.
  • Page 77 Exterior Equipment MONTEREY BOATS Wet bar The wet bar is equipped with a sink, optional elec- tric grill, cup holders, a refrigerator or optional ice maker and a storage area. The counter top and sink cover is made of Karadon. A grab rail on the wet bar provides a hand hold when moving about the cockpit.
  • Page 78 Exterior Equipment MONTEREY BOATS the AC power is disconnected and the Refrigerator breaker is activated on the cabin DC panel. When 120-volt AC current is provided by the Refrigerator circuit breaker on the 120-volt panel, the refrig- erator automatically switches to AC power.
  • Page 79 Exterior Equipment MONTEREY BOATS Cockpit Lounge Seat The cockpit lounge seat provides seating and the rear portion converts to a sun island . The sun is- land portion of the seat raises with cockpit deck to provide access to the engine compartment. There...
  • Page 80 Exterior Equipment MONTEREY BOATS Helm Seat The helm seat is equipped with a flip up bolster to provide more room between the seat and the helm. The bolster converts the seat to a leaning post style seat with a backrest and allows the operator to sit or stand at the helm.

  • Page 81: Hardtop And Enclosure

    Exterior Equipment MONTEREY BOATS to allow the latch to secure the door. When either door is open, it must be properly secured with the latch near the bottom door track and to the star- board side of the companionway. To latch the door...
  • Page 82 Attach the drop curtain to you should contact Monterey Customer Service the zipper on the rear brow of the hard top and to make sure the equipment you would like to then to the zippers on the rear of the hardtop legs.

  • Page 83: Chapter 10: Interior Equipment

    Chapter 10: MONTEREY BOATS INTERIOR EQUIPMENT 10.1 Head Compartments and Marine Toilets Aft Head Compartment The aft head compartment is equipped with a sink with a hot and cold faucet. The sink faucet is equipped with a removable shower head. The...
  • Page 84 Interior Equipment MONTEREY BOATS Marine Head System Your boat is equipped with a VacuFlush marine head system in each head compartment as stan- dard equipment. VacuFlush systems use a small amount of water (one pint to one quart) and vacuum which is generated by the 12-volt vacuum pumps to flush.
  • Page 85 Interior Equipment MONTEREY BOATS monitor panel in the forward head compartment. Please refer to the toilet manufacturer owner’s manual for more information on the operation of the marine head system. Holding Tank and Optional Macerator Dis- charge Pump The holding tank and vacuum generators are located in the engine compartment.

  • Page 86: Galley And Sink

    Interior Equipment MONTEREY BOATS in the system or the vacuum pump may require service. Always make sure to leave enough water in the bowl to cover the flush valve and bowl seal. Pe- riodically, lubricate the seal with Teflon grease.
  • Page 87 Interior Equipment MONTEREY BOATS Stove The galley is equipped with a dual burner elec- tric stove recessed into the counter top below a Karadon cover. A micro switch in the recess for the stove cover prevents the stove from activat- ing while the cover is in place.

  • Page 88: Main Salon

    Interior Equipment MONTEREY BOATS Microwave/Convection Oven A microwave/convection oven has heating ele- ments that allow it to function as a conventional convection oven or a microwave oven. It operates on AC power and is protected and activated by the Microwave breaker in the AC breaker panel.
  • Page 89 Interior Equipment MONTEREY BOATS hatch. Additional lighting is provided by 12-volt lights on either end of the dinette. Cabin Light Switches Most of the cabin lights are controlled by switches on the cabin walls. Other lights have switches on the light fixture. Some of the lights are controlled by electronic dimmer switches.

  • Page 90: Air Conditioners

    Safety Equipment chapters in this manual. This is especially essential since your boat is equipped with a generator. If you did not receive a manual for your carbon monoxide detectors, please contact the Monterey Boats Customer Service Department. ACTIVATION OF THE CARBON MONOXIDE DETECTOR INDICATES THE PRESENCE OF CARBON MONOXIDE (CO) WHICH CAN BE FATAL.

  • Page 91: Master Stateroom

    Interior Equipment MONTEREY BOATS or aft stateroom storage compartment and could make the cabin floor wet. You should always keep the cabin door closed when operating the air conditioner. If the cabin door is left open, it could cause the air conditioner units to run continuously and not cycle enough to defrost the coils on the condenser.

  • Page 92: Aft Stateroom

    Interior Equipment MONTEREY BOATS Hanging lockers are located on both sides of the stateroom door. Additional storage is located in storage compartments built into the rear of the hanging lockers. The light in the lockers is auto- matically activated when the door is opened and turned off when the door is closed.

  • Page 93: Entertainment System

    Interior Equipment MONTEREY BOATS secured in the open or closed position whenever the boat is away from the dock. The door moves easily and if it is not properly latched, the rock- ing motion of the boat will cause the door to slide back and forth which could damage the door and door track.
  • Page 94 Interior Equipment MONTEREY BOATS To watch dockside cable or over-the-air antenna, select A (dockside cable) or B (over-the-air) on the A/B switch and select CATV on the TV input. To watch a DVD, insert a DVD in the player, and select Composite on the TV input.

  • Page 95: Cabin Floors And Woodwork

    MONTEREY BOATS is selected. If you wish to listen to the sound on your home entertainment system in addition to or instead of your TV, select AV1. To watch over-the-air (antenna) TV: Press the “B” button on the A/B switcher. Press the Input button on your TV remote until CATV is selected.
  • Page 96 MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...

  • Page 97: Chapter 11: Safety Equipment

    If there is a problem with one of these systems, See your Monterey dealer for necessary control it will sound an alarm until the problem is found and cable adjustments. Please refer to the Helm and resolved.

  • Page 98: Required Safety Equipment

    All paddle or boat hook. Monterey boats must be equipped with at least one Type I, II or III PFD for each person on board, •...

  • Page 99: Automatic Fire Extinguishing System

    Safety Equipment MONTEREY BOATS Navigation Lights Bilge and Fuel Fires Recreational boats are required to display naviga- Fuel compartment and bilge fires are very danger- tion lights between sunset and sunrise and other ous because of the presence of gasoline or diesel periods of reduced visibility (fog, rain, haze, etc.)
  • Page 100 Safety Equipment MONTEREY BOATS perature in the engine compartment reaches a specific temperature, usually around 165 The boat is equipped with an indicator light at the helm. Under normal circumstances, whenever the ignition key is turned on, the green indicator light will glow.

  • Page 101: Carbon Monoxide Monitoring System

    FIRE EXTINGUISHING SYSTEM OWNER’S MANUAL, they are unable to save themselves by either PLEASE CONTACT YOUR DEALER OR THE MONTEREY CUSTOMER SERVICE DEPARTMENT. exiting the area or calling for help. Also, young children, elderly persons, and pets may be the first affected.

  • Page 102: First Aid

    Safety Equipment MONTEREY BOATS oxide gas. Refer to the Ventilation chapter for for treatment of serious injuries or illness. If you information on ventilating your boat properly while are within VHF range of a Coast Guard Station, underway and other precautions while at anchor make the initial contact on channel 16 and follow or in a slip.

  • Page 103: Caution And Warning Labels

    Safety Equipment MONTEREY BOATS 11.9 Caution and Warning Labels Located on Dash ...
  • Page 104 MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...

  • Page 105: Chapter 12: Operation

    BOATS OPERATION 12.1 General in accordance with the sea conditions, boat traffic Before you start the engines on your Monterey, and weather conditions. you should have become familiar with the vari- ous component systems and their operation and Remember, it is the operator’s responsibility have performed a “Precruise System Check.”...
  • Page 106 Operation MONTEREY BOATS Overtaking Situations When one motor boat is overtaking another mo- tor boat, the boat that is being passed has the right of way. The overtaking boat must make the adjustments necessary to provide clearance for a safe passage of the other vessel. The boats should sound the appropriate signals.
  • Page 107 Operation MONTEREY BOATS ...

  • Page 108: Pre-Cruise Check

    Operation MONTEREY BOATS Note: Storms and wave action can cause • Test the automatic and manual bilge pump switches to make sure the system is working buoys to move. You should not rely properly. on buoys alone to determine your position.

  • Page 109: Operating Your Boat

    • Your Monterey is a heavy boat that will pro- • Alcohol and any drugs can severely reduce duce a large wake at certain speeds. You are...

  • Page 110: Docking, Anchoring And Mooring

    Operation MONTEREY BOATS 12.5 Docking, Anchoring and Mooring Note: For more instructions on safety, equipment and boat handling, enroll Docking and Dock Lines in one of the several free boating Maneuvering the boat near the dock and securing courses offered.
  • Page 111 Operation MONTEREY BOATS it is docked. Keep the engines running until the lines are secured. Backing into a Slip Approach the slip with the stern against the wind After Bow Spring Cleat or current and the drives straight ahead. Use the...

  • Page 112: Controls, Steering, Or Propulsion System Failure

    Investigate and correct the problem if you can. Turn the engines off before going into the engine THE MOORING CLEATS ON MONTEREY BOATS compartment to make repairs. If you are unable ARE NOT DESIGNED OR INTENDED TO BE USED FOR TOWING PURPOSES.

  • Page 113: Flooding Or Capsizing

    Operation MONTEREY BOATS You must always make sure the helm is properly WHEN TOWING OPERATIONS ARE UNDERWAY, manned and is never left unattended while trolling. HAVE EVERYONE ABOARD BOTH VESSELS STAY If you are fishing in an area that is crowded with...

  • Page 114: Trash Disposal

    ENGINE(S) ARE RUNNING. STOP THE ENGINE(S) 12.13 Transporting Your Boat IF DIVERS OR SWIMMERS ARE ATTEMPTING TO Your Monterey is a large boat and should only be BOARD. ALWAYS PROPERLY STORE THE LADDER BEFORE STARTING THE ENGINE(S). trailered by professionals that have the knowledge and equipment to move large boats without caus- ing damage.

  • Page 115: Chapter 13: Routine Maintenance

    Bottom Painting The anodes are less noble than copper based Your Monterey hull is manufactured using state-of- alloys, aluminum and stainless steel. They will the-art materials and processes. A layer of super deteriorate first, protecting the more noble engine tough, Ashland “AME”...
  • Page 116 Routine Maintenance MONTEREY BOATS Anodes Transom Anodes plenty of fresh water. Remove any stains • Do not attempt to remove stains and scratch- quickly. Gelcoat is microscopically porous, so es. Chalking, stains, and minor scratches can long term staining may become permanent.
  • Page 117 Routine Maintenance MONTEREY BOATS Stainless Steel Hardware YOUR STAINLESS STEEL CAN BE DAMAGED BY Marine grade stainless steel components such as EXPOSURE TO ACIDS AND OTHER CORROSIVE hardware, cleats, eyes and rails offer superior AGENTS FOUND IN MANY CLEANING PRODUCTS.
  • Page 118 Routine Maintenance MONTEREY BOATS GEMLUX MAINTENANCE INSTRUCTIONS Cleaning Agents Method Comments Apply with a sponge Once your stainless is Routine Cleaning Soap and Water or soft cloth. Dry area free of discoloration completely. and/or bleeding, spray GEMLUX Passivation S o l u t i o n d i r e c t l y onto stainless.

  • Page 119: Upholstery, Canvas And Enclosures

    Meguiar’s Mirror Glaze #17 that your boat may have a fault in the aluminum frame. You should also contact Monterey Boats Note: Clear plastic (Isinglass) is subject Customer Service. to ultraviolet (sunlight) degrada- tion over time.
  • Page 120 Routine Maintenance MONTEREY BOATS immediate damage or slow deterioration. Lotions, the outer edge of the stain towards the center sun tan oil, waxes and polishes, etc., contain oils in order to prevent spreading. Rinse with soap and dyes that can cause stiffening and staining and water.
  • Page 121 Take care not to extend the area of Fixx Coating ® contamination beyond its original boundary. Monterey Boats uses OMNOVA white, smoother Rinse with clean water. and embossed pleated vinyl material with PreFixx top coating. All other accent embossed white and Additional Warnings for Vinyl Fabrics colored vinyl requires different care and mainte- •...
  • Page 122 Routine Maintenance MONTEREY BOATS such as nail polish remover, without damaging Method 1 the PreFixx protective finish (when recommended Use one of the following cleaners with a soft cloth cleaning instructions are followed). or damp sponge. Rinse area with fresh water, and then dry with a clean, lint-free cloth.
  • Page 123 • If canvas gets wet during use, remove side cur- road. Your Monterey Dealer will assist you in tains and open the windshield vent so seams finding a suitable cover (not available from can dry out.

  • Page 124: Cabin Interior

    Routine Maintenance MONTEREY BOATS Note: Your Monterey boat is basically and CARBON MONOXIDE IS A LETHAL, TOXIC GAS open vehicle. Therefore, in spite of THAT IS COLORLESS AND ODORLESS. IT IS A well-designed and well-fitting canvas DANGEROUS GAS THAT WILL CAUSE DEATH IN enclosures, your boat is not water- CERTAIN LEVELS.

  • Page 125: Bilge And Engine Compartment

    Routine Maintenance MONTEREY BOATS and minor impact marks, can be repaired with a The age of fuel can affect engine performance. light abrasive cleanser and a Scotch-Brite pad. Chemical changes occur as the fuel ages that can ® For heavier damage, light sanding and machine...
  • Page 126 MONTEREY BOATS • Operate the thru-hull valves once a month and service as required. Note: All drains and pumps must be proper- ly winterized before winter lay-up. NEVER USE HARSH CHEMICAL DRAIN CLEANERS IN MARINE DRAIN SYSTEMS. PERMANENT DAMAGE TO THE HOSES AND FITTINGS MAY RESULT.

  • Page 127: Chapter 14: Seasonal Maintenance

    Chapter 14: MONTEREY BOATS SEASONAL MAINTENANCE 14.1 Lay-up and Storage Before Hauling: Your dealer or the engine manufacturer can • Pump out the head and holding tank. Flush provide additional information on fuel degrada- tion and fuel additives recommended for your the holding tank using clean water and a de- engine.
  • Page 128 ONLY EXPERIENCED PROFESSIONAL BOAT Preparing The Boat For Storage YARD PERSONNEL TO LIFT, BLOCK OR CRADLE • Remove the bilge drain plug. YOUR BOAT. HULL DAMAGE RESULTING FROM IMPROPER CRADLE AND BLOCKING SUPPORT WILL VOID THE MONTEREY HULL WARRANTY. Proper Cradle Support ...

  • Page 129: Winterizing

    Seasonal Maintenance MONTEREY BOATS 14.2 Winterizing • Thoroughly wash the fiberglass exterior, es- pecially the antifouling portion of the bottom. Fresh Water System Remove as much marine growth as possible. The entire fresh water system must be completely Lightly wax the exterior fiberglass compo- drained.
  • Page 130 The air dures located in your engine owner’s conditioning system and cabin fresh water show- manuals or contact a Monterey deal- ers share the same sump system. Note: The air conditioning, engine control...

  • Page 131: Recommissioning

    Seasonal Maintenance MONTEREY BOATS Reactivating The Boat After Storage: PLACING AN ELECTRIC OR FUEL BURNING • Apply a fresh coat of bottom paint on the hull HEATING UNIT IN THE BILGE AREA CAN BE and drives. P OT E N T I A L LY H A Z A R D O U S A N D I S N OT RECOMMENDED.
  • Page 132 MONTEREY BOATS • Carefully monitor the gauges and check for leakage and abnormal noises. Monitor the temperature gauges closely until they stabilize at normal operating temperature to ensure that the cooling pumps are operating prop- erly. • Operate the boat at slow speeds until the en- gine temperature stabilizes and all systems are operating normally.

  • Page 133: General Maintenance Schedule And Log

    Appendix A: MONTEREY BOATS GENERAL MAINTENANCE SCHEDULE AND LOG MAINTENANCE & & & & & & & & ...

  • Page 134: Maintenance Schedule

    Maintenance Schedule MONTEREY BOATS Service/Repairs Date Hours Dealer ...
  • Page 135 Maintenance Schedule MONTEREY BOATS Service/Repairs Date Hours Dealer ...
  • Page 136 Maintenance Schedule MONTEREY BOATS Service/Repairs Date Hours Dealer ...

  • Page 137: Float Plan

    FLOAT PLAN Monterey Boats recommends filling out a float plan each time you use your boat for an offshore day trip or a long cruise. Leave this information with a responsible person ashore, like a close friend or relative that you know well.
  • Page 138 MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...
  • Page 139 Appendix C: MONTEREY BOATS                                      ...
  • Page 140 Accident Report MONTEREY BOATS                                    ...
  • Page 141 MONTEREY BOATS                                                 ...
  • Page 142 MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...

  • Page 143: Glossary Of Terms

    Appendix D: MONTEREY BOATS GLOSSARY OF TERMS ft: In, near, or toward the stern of a boat. Boat Hook: Short shaft of wood or metal with a hook fitting at one end shaped to aid in extending Aground: A boat stuck on the bottom.
  • Page 144 Glossary of Terms MONTEREY BOATS Cockpit: An open space, usually in the aft deck, Flying Bridge: A control station above the level of outside of the cabin. the deck or cabin. Companionway: Opening in the deck of a boat to Flukes: The broad portions of an anchor which dig provide access below.
  • Page 145 Glossary of Terms MONTEREY BOATS Inboard/outboard: Also stern drive or I/O. A boat Moored: A boat secured with cables, lines or an- with an inboard engine attached to an outboard chors. drive unit. Mooring: An anchor permanently embedded in the bottom of a harbor that is used to secure a eel: A plate or timber plate running lengthwise boat.
  • Page 146 Glossary of Terms MONTEREY BOATS Spring Line: A line that leads from the bow aft or aw Water Cooled: Refers to an engine cooling from the stern forward to prevent the boat from system that draws seawater in through a hull fit- moving ahead or astern.
  • Page 147 Glossary of Terms MONTEREY BOATS Trough: The area of water between the crests of A structure generally parallel to the Wharf: waves and parallel to them. shore. Twin-Screw Craft: A boat with two propellers on Working Anchor: An anchor carried on a boat for two separate shafts.
  • Page 148 MONTEREY BOATS THIS PAGE WAS LEFT BLANK INTENTIONALLY ...

  • Page 149: Troubleshooting Guide

    Appendix E: MONTEREY BOATS TROUBLESHOOTING GUIDE CAUSE AND SOLUTION PROBLEM CONTROL SYSTEMS • There is a problem with the electronic steering system at Steering is slow to respond and engine RPM has been the helm, EVC module or at the one of the drives. Have the reduced.

  • Page 150: Engine Problems

    Troubleshooting MONTEREY BOATS CAUSE AND SOLUTION PROBLEM ENGINE PROBLEMS • The raw water supply line to the pump is kinked. Replace An engine is running too hot. hose. • The engine raw water pump impeller is worn or damaged. Repair the pump.

  • Page 151: Accessory Problems

    Troubleshooting MONTEREY BOATS PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS • The air conditioner pump sea strainer is clogged. Clean the The air conditioner runs for a short time & then cuts out. strainer. • The raw water supply thru-hull valve is closed. Open the valve.
  • Page 152 Troubleshooting MONTEREY BOATS PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS • Impeller screen is plugged with debris. Clean screen at the Reduction in water flow from the bilge pump. base of the pump. • The discharge hose is pinched or clogged. Check discharge hose and clean or repair.
  • Page 153 Troubleshooting MONTEREY BOATS PROBLEM CAUSE AND SOLUTION ACCESSORY PROBLEMS • The circuit breaker is not activated. Turn on breaker. Head will not flush. • There is a vacuum leak at the flush valve or the waste hose. Repair the leak.
  • Page 154 MONTEREY BOATS ...
  • Page 155 MONTEREY BOATS 1579 S.W. 18th Street Williston, FL 32696 Phone 352-529-9181 Fax 352-529-9173 www.montereyboats.com P/N 63102400-00-MANU Rev. 4/2008...

Table of Contents
